SEMICONDUCTOR

TECHNICAL DATA

GENERAL PURPOSE APPLICATION.

SWITCHING APPLICATION.

FEATURES

・Excellent

Linearity

: h

(0.1mA)/h

(2mA)=0.95(Typ.).

KTA1504S

EPITAXIAL PLANAR PNP TRANSISTOR

・Complementary

to KTC3875S.

・Low

Noise : NF=1dB(Typ.), 10dB(Max.).

CHARACTERISTIC

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Collector Current

Base Current

Collector Power Dissipation

Junction Temperature

Storage Temperature Range

SYMBOL

CBO

CEO

EBO

stg

RATING

-50

-5

-150

-30

150

-55½150

UNIT

1. EMITTER

℃

2. BASE

3. COLLECTOR

SOT-23

Marking

Rank

Lot No.

Type Name

ELECTRICAL CHARACTERISTICS (Ta=25℃)

CHARACTERISTIC

Collector Cut-off Current

Emitter Cut-off Current

DC Current Gain

Collector-Emitter Saturation Voltage

Transition Frequency

Collector Output Capacitance

Noise Figure

SYMBOL

CBO

EBO

(Note)

CE(sat)

TEST CONDITION

=-50V, I

=-5V, I

=-6V, I

=-2mA

=-100mA, I

=-10mA

=-10V, I

=-1mA

=-10V, I

=0, f=1MHz

=-6V, I

=-0.1mA

f=1kHz, Rg=10kΩ

Note : h

Classification O:70½140 , Y:120½240 , GR(G):200½400

MIN.

TYP.

-0.1

4.0

1.0

MAX.

-0.1

400

-0.3

7.0

MHz

UNIT

2007. 6. 13

Revision No : 3

MAXIMUM RATING (Ta=25℃)

DIM

MILLIMETERS

2.93 + 0.20

1.30+0.20/-0.15

1.30 MAX

0.40+0.15/-0.05

2.40+0.30/-0.20

1.90

0.95

0.13+0.10/-0.05

0.00 ~ 0.10

0.55

0.20 MIN

1.00+0.20/-0.10

0.1 MAX

1/3
