CIT RELAY
™
FEATURES:
•
Low coil power consumption
•
High Sensitivity
•
Conforms to FCC part 68
•
PC board mounting
•
Small size, light weight
WJ103
Pending
12.5 x 7.5 x 10.0 mm
CONTACT DATA
Contact Arrangement
Contact Rating
Contact Resistance
Contact Material
Maximum Switching Power
Maximum Switching Voltage
Maximum Switching Current
1A = SPST N.O.
1C = SPDT
1A @ 24VDC;
.5A @ 125VAC
< 50 milliohms initial
Ag + Au
30W
125VAC, 60VDC
1 Amp
COIL DATA
Coil Voltage
VDC
Coil Resistance
Ω ±
10%
Pick Up Voltage
VDC (max)
75%
of rated voltage
Release Voltage
VDC (min)
10%
of rated voltage
Coil Power
W
Operate Time
ms
Release Time
ms
Rated
Max.
3
5
6
9
12
24
3.9
6.5
7.8
11.7
15.6
31.2
.15W
60
167
240
540
960
3840
.20W
45
125
180
405
720
2880
2.25
3.75
4.50
6.75
9.00
18.00
0.3
0.5
0.6
0.9
1.2
2.4
.15
.20
4.5
1.5
CAUTION:
1. The use of any coil voltage less than the rated coil voltage may compromise the operation of the relay.
2. Pickup and release voltages are for test purposes only and are not to be used as design criteria.
GENERAL DATA
Electrical Life @ rated load
Mechanical Life
Insulation Resistance
Dielectric Strength, Coil to Contact
Contact to Contact
Shock Resistance
Vibration Resistance
Terminal (Copper Alloy) Strength
Operating Temperature
Storage Temperature
Solderability
Weight
100K cycles, typical
5M cycles, typical
100MΩ min @ 500VDC
1000V rms min. @ sea level
500V rms min. @ sea level
100m/s
2
for 11ms
3.30mm double amplitude 10-40Hz
5N
-40
°C
to + 85
°C
-40
°C
to + 155
°C
230
°C ±
2
°C
for 10
±
0.5s
2.2g
CIT RELAY
Website:
www.citrelay.com
Tel: 763-535-2339
Fax: 763-535-2194
