LSJ174_TO-92 Overview

P-CHANNEL JFET

LSJ174
P-CHANNEL JFET
Linear Systems replaces discontinued Siliconix J174
The LSJ174 is a single P-Channel JFET switch
This p-channel analog switch is designed to provide low
on-resistance and fast switching. When used in
combination with the complimentary J/SST111 n-
channel family, the LSJ174 simplifies series-shunt
switching applications
.
Low Error Voltage
High-Speed Analog Circuit Performance
Negligible “Off-Error,” Excellent Accuracy
Good Frequency Response
Eliminates Additional Buffering
FEATURES
DIRECT REPLACEMENT FOR SILICONIX J174
LOW ON RESISTANCE
LOW GATE OPERATING CURRENT
FAST SWITCHING
ABSOLUTE MAXIMUM RATINGS
@ 25°C (unless otherwise noted)
Maximum Temperatures
Storage Temperature
Operating Junction Temperature
Maximum Power Dissipation
Continuous Power Dissipation
MAXIMUM CURRENT
Gate Current (Note 1)
MAXIMUM VOLTAGES
Gate to Drain Voltage
Gate to Source Voltage


r
DS(on)
≤ 85Ω
I
D(off)
= 10pA
t
(ON)
 25ns
LSJ174 Benefits:
‐55°C to +150°C
‐55°C to +135°C
350mW
I
G
 = ‐50mA
V
GDS
 = 30V
V
GSS
 = 30V


LSJ174 Applications:
Analog Switches
Choppers
Sample-and-Hold
Normally “On” Switches
Current Limiters

LSJ174 ELECTRICAL CHARACTERISTICS @ 25°C (unless otherwise noted)
SYMBOL
CHARACTERISTIC
MIN
TYP.
BV
GSS

Gate to Source Breakdown Voltage
30
‐‐
V
GS(F)

Gate to Source Forward Voltage
‐‐
‐0.7
V
GS(off)

Gate to Source Cutoff Voltage
‐‐
I
DSS

Drain to Source Saturation Current
‐20
‐‐
I
GSS

Gate Reverse Current
‐‐
0.01
I
G

Gate Operating Current
‐‐
0.01
I
D(off)

Drain Cutoff Current
‐‐
‐0.01
r
DS(on)

Drain to Source On Resistance
‐‐
‐‐




LSJ174 SWITCHING CHARACTERISTICS @ 25°C (unless otherwise noted)
SYMBOL
CHARACTERISTIC

UNITS
t
d(on)

t
r

t
d(off)

t
f

Turn On Time
Turn On Rise Time
Turn Off Time
Turn Off Fall Time
10
15
10
20


ns
Click To Buy

nA

Ω

CONDITIONS
V
GS
(L) = 0V
 V
GS
(H) = 10V

See Switching Circuit
MAX
‐‐
‐‐
10
‐135
‐‐
‐1
85

UNITS


CONDITIONS
I
= ‐1µA,   V
DS
 = 0V
                   I
= ‐1mA,   V
DS
 = 0V
V
DS
 = ‐15V, I
D
 = ‐10nA
V
DS
 = ‐15V, V
GS
= 0V
V
GS
= 20V,  V
DS
 = 0V
V
DG
= ‐15V,  I
D
 = ‐1mA
V
DS
 = ‐15V, V
GS
= 0V
V
GS
= 0V,  V
DS
 = ‐0.1V

Note 1 ‐  Absolute maximum ratings are limiting values above which LSJ174 serviceability may be impaired.

LSJ174 SWITCHING CIRCUIT PARAMETERS                                                                                                                                   SWITCHING CIRCUIT
TO-92 (Bottom View)
V
DD

‐10V

V
GG

20V

R
L

560Ω

R
G

100Ω

I
D(on)

‐15mA




Micross Components

Europe


Available Packages:






LSJ174 in TO-92
LSJ174 in bare die.



Tel: +44 1603 788967
Email:
chipcomponents@micross.com
Web:
http://www.micross.com/distribution
Please contact Micross for full
package and die dimensions
Information furnished by Linear Integrated Systems and Micross Components is believed to be accurate and reliable. However, no responsibility is assumed
for its use; nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise
under any patent or patent rights of Linear Integrated Systems.
Micross Components Ltd, United Kingdom, Tel: +44 1603 788967, Fax: +44 1603788920, Email:
chipcomponents@micross.com
Web:
www.micross.com/distribution.aspx
