SAW Components
SAW RF filter
L Band Tx
Series/type:
Ordering code:
Date:
Version:
B5143
B39172B5143U410
May 29, 2012
2.1
©
EPCOS AG 2012. Reproduction, publication and dissemination of this data sheet, enclosures
hereto and the information contained therein without EPCOS’ prior express consent is prohibited.
SAW Components
SAW RF filter
Data Sheet
Application
s
s
s
s
B5143
1650.75 MHz
RF filter for L Band system
Low amplitude ripple
Usable band width 48.5 MHz
No matching required for operation at 50
Ω
Features
Package size 3.0 x3.0 x 1.10 mm
3
Package code DCC6C
RoHS compatible
Approximate weight 0.037 g
Ceramic package for
Surface Mount Technology
(SMT)
s
Ni, gold-plated terminals
s
Electrostatic Sensitive Device
(ESD)
s
Filter surface passivated
s
s
s
s
s
Pin configuration
s
2
Input
s
5
Output
s
1, 3, 4, 6 Case ground
Please read
cautions and warnings and
important notes
at the end of this document.
2
May 29, 2012
SAW Components
SAW RF filter
Data Sheet
Characteristics
Temperature range for specification:
Terminating source impedance:
Terminating load impedance:
T = –20 ˚C to +85 ˚C
Z
S
=
50
Ω
Z
L
=
50
Ω
min.
Nominal frequency
Maximum insertion attenuation
1626.5 ... 1675.0
Amplitude ripple
(p-p)
1626.5 ... 1675.0
Return loss (input / output)
1626.5 ... 1675.0
Absolute attenuation
10 .0 ... 1518.0
1518.0 ... 1559.0
1576.5
1596.5
1606.5
1695.0
1705.0
1751.0
2400.0 ... 2500.0
f
N
α
max
MHz
∆α
MHz
—
1.3
2.2
—
2.6
3.5
—
typ.
@ 25 ˚C
1650.75
max.
—
B5143
1650.75 MHz
MHz
dB
dB
MHz
α
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
8.0
10.0
—
dB
35
35
31
22
15
10
22
31
32
39
39
40
29
20
25
48
42
38
—
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
dB
Maximum ratings
Operable temperature range
Storage temperature range
DC voltage
ESD voltage
Input power at 1626.5 -1675.0 MHz
1)
T
T
stg
V
DC
V
ESD
P
IN
–40/+85
–40/+85
3
50
1)
10
˚C
˚C
V
V
dBm
machine model, 1 pulse
CW
acc. to JESD22-A115A (machine model), 1 negative & 1 positive pulses.
Please read
cautions and warnings and
important notes
at the end of this document.
3
May 29, 2012
SAW Components
SAW RF filter
Data Sheet
Transfert function (S21 narrow band)
B5143
1650.75 MHz
Transfert function (S21 wide band)
Please read
cautions and warnings and
important notes
at the end of this document.
4
May 29, 2012
SAW Components
SAW RF filter
Data Sheet
Characteristics
Temperature range for specification:
Terminating source impedance:
Terminating load impedance:
T = –40 ˚C to +85 ˚C
50
Ω
Z
S
=
Z
L
=
50
Ω
min.
Nominal frequency
Maximum insertion attenuation
1626.5 ... 1675.0
Amplitude ripple
(p-p)
1626.5 ... 1675.0
Return loss (input)
1626.5
Return loss (output)
1626.5
f
N
α
max
MHz
∆α
MHz
—
1.3
2.7
—
2.6
4.3
—
typ.
@ 25 ˚C
1650.75
max.
—
B5143
1650.75 MHz
MHz
dB
dB
... 1675.0
MHz
6.0
10.0
—
dB
... 1675.0
MHz
α
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
7.0
10.0
—
dB
Absolute attenuation
10 .0 ... 1518.0
1518.0 ... 1559.0
1576.5
1596.5
1606.5
1695.0
1705.0
1751.0
2400.0 ... 2500.0
35
35
31
22
15
6.5
22
31
32
39
39
40
29
20
25
48
42
38
—
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
dB
Maximum ratings
Operable temperature range
Storage temperature range
DC voltage
ESD voltage
Input power at 1626.5 -1675.0 MHz
1)
T
T
stg
V
DC
V
ESD
P
IN
–40/+85
–40/+85
3
50
1)
10
˚C
˚C
V
V
dBm
machine model, 1 pulse
CW
acc. to JESD22-A115A (machine model), 1 negative & 1 positive pulses.
Please read
cautions and warnings and
important notes
at the end of this document.
5
May 29, 2012
