SAW Components
SAW Tx filter
Data sheet
Application
s
Low-loss RF filter for AWS systems, transmit path
B4307
1732.50 MHz
(Tx)
s
Usable passband: 45MHz
s
Unbalanced to unbalanced operation
s
No matching network required for operation at 50
Ω
Package size 1.4 x1.1 x 0.4
Package code QCS5P
RoHS compatible
Approximate weight 0.003 g
Package for
Surface Mount Technology
(SMT)
s
Ni, gold-plated terminals
s
AEC-Q200 qualified component family (operable
temperature range –40˚C to +85˚C)
s
Electrostatic Sensitive Device
(ESD)
s
s
s
s
s
mm
3
0.325
2 3
1
0.575
Features
0.25
bottom view
5
0.5 0.5
0.4
4
side view
1.4
1.1
top view
Pin configuration
s
1
s
4
s
2,3,5
Input, unbalanced
Output, unbalanced
Case-ground
1
4
2,5
3
Please read
cautions and warnings and
important notes
at the end of this document.
2
March 16, 2011
SAW Components
SAW Tx filter
Data sheet
Characteristics
Temperature range for specification:
Terminating source impedance:
Terminating load impedance:
T = –40 ˚C to +85 ˚C
Z
S
=
50
Ω
Z
L
=
50
Ω
min.
Center frequency
Maximum insertion attenuation
1710.0 ... 1755.0
Amplitude ripple
(p-p)
1710.0 ... 1755.0
VSWR
1710.0
... 1755.0
MHz
—
2.1
2.5
f
C
α
max
MHz
∆α
MHz
—
1.0
1.7
dB
—
1.9
2.7
dB
—
typ.
@ 25 ˚C
1732.50
max.
—
MHz
B4307
1732.50 MHz
Attenuation
100.0
1400.0
1610.0
1670.0
1790.0
1800.0
1930.0
2200.0
...
...
...
...
...
...
...
...
1400.0
1610.0
1670.0
1680.0
1800.0
1930.0
2200.0
5000.0
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
α
40
35
30
15
15
30
36
30
46
42
39
33
33
39
40
39
—
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
dB
Please read
cautions and warnings and
important notes
at the end of this document.
3
March 16, 2011
SAW Components
SAW Tx filter
Data sheet
B4307
1732.50 MHz
Maximum ratings
Operable temperature range T
Storage temperature range
DC voltage
ESD voltage
Input power at
1710 MHz ... 1755 MHz P
IN
1)
–40/+85
–40/+85
0
50
1)
10
˚C
˚C
V
V
dBm
T
stg
V
DC
V
ESD
machine model, 1 pulse
continuous wave
acc. to JESD22-A115A (machine model), 1 negative & 1 positive pulse.
Please read
cautions and warnings and
important notes
at the end of this document.
4
March 16, 2011
SAW Components
SAW Tx filter
Data sheet
Transfer function
B4307
1732.50 MHz
Transfer function
(wideband)
Please read
cautions and warnings and
important notes
at the end of this document.
5
March 16, 2011
