www.make-ps.com
E-mail:info@make-ps.com
Single & Dual Output
DC/DC Converter
1000WFR series
F
EATURES
•
•
•
•
•
•
Compact 0.4 Inch Profile Package
-25
o
C to +71
o
C Operating Temperature Range
±0.2% Line Regulation
Short Circuit Protection
Low Output Ripple and Noise
±0.5% Load Regulation
D
ESCRIPTIONS
The 1000WFR series is a family of 10W single and dual
output DC/DC converters that utilize a cost effective design
to achieve high levels of performance. Operating from wide
(2:1) input voltage ranges of 9 to 18, 18 to 36 or 36 to 72 Vdc;
providing outputs of 5, 9, 12, 15, ±12 or ±15 Vdc.
Standard features include an input Pi filter to reduce
reflected ripple current, efficiency as high as 80%, and
continuous output short circuit protection. Input/output
isolation is 500 Vdc minimum, output voltage accuracy is ±1%
and transient response is less than 500μSec.
I
NPUT
C
HARACTERISTICS
Input Voltage Range
Input Filter
Ripple Current
Reverse Voltage Protection
Unit/Comments
see Table 1
Pi Network Filter
see Model Selection Guide
Parallel Diode
T
ABLE
1 - I
NPUT
V
OLTAGE
R
ANGE VS
O
UTPUT
L
OAD
Nominal
Input (VDC)
12
24
48
Input Voltage Range (VDC) at:
20% Load
40% Load 60% Load
8.6 - 20.4
17.2 - 40.9
34.4 - 81.8
8.75 - 19.7
17.5 - 39.5
35.0 - 79.1
8.8 - 18.5
17.6 - 37.1
35.2 - 74.2
100% Load
9.0 - 18.0
18.0 - 36.0
36.0 - 72.0
O
UTPUT
C
HARACTERISTICS
Min Typ Max Unit/Comments
Voltage & Current Ratings
See Model
Selection Guide
±1.0 %
Output Voltage Accuracy
±1.0 %
Voltage Balance ( Dual
Outputs)
10 mV RMS
Ripple & Noise (20 MHz BW)
100 mV Pk-Pk
±0.2 %
Line Regulation
±0.5 %
Load Regulation
10
Minimum Load
% of Full Load
±0.02 % per
o
C
Temperature Coefficient @FL
Short Circuit Protection
Continuous, Current
Limit
Short Circuit Restart
Automatic Recover
500
μSec.
Transient Response
G
ENERAL
C
HARACTERISTICS
Switching Frequency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Min Typ Max Unit/Comments
kHz
80
120
VDC, 1 minute
500
Mohm, 500VDC
1000
pF
600
>> B-100
www.make-ps.com
E
NVIRONMENTAL
S
PECIFICATIONS
Operating Temp. Range
Storage Temp. Range
Relative Humidity
Cooling
Min
-25
-40
Typ Max
+71
+105
+95
Unit/Comments
o
C; Ambient
o
C
% Humidity; non-
condensing
Free-Air Convection
E-mail:info@make-ps.com
P
HYSICAL
C
HARACTERISTICS
Case Size
Weight
Case Material
Shield Connection
Unit/Comments
2.0 X 2.0 X 0.4 inches
(51.0 X 51.0 X 10.2 mm)
2.8 oz (79 grams)
Black Coated Metal
Six-Sided Continuous
O
UTLINE
D
RAWING
2.00 (50.8)
0.40
(10.2)
0.40
(10.2)
0.60
(15.2)
0.040±.005
(1.01) DIA.
3
+Vout
4
5
COM -Vout
BOTTOM
+Vin -Vin
1
2
2.00
0.80 (50.8)
(20.3)
SIDE
0.60
(15.2)
0.90
(22.9)
0.25 MIN.
(6.4)
0.40
(10.2)
0.20
(5.1)
P
IN
O
UT
C
HART
Pins
1
2
3
4
5
Single
+ Vin
- Vin
+ Vout
NC
- Vout
Dual
+ Vin
- Vin
+ Vout
Common
- Vout
NC = No Connection
Notes:
1. Unless otherwise specified dimensions are in inches (mm).
Tolerances
Inches
mm
X.XX = ±0.02
X.X = ±0.5
X.XXX= ±0.010
X.XX = ±0.25
All specifications are typical at nominal input, nominal load and 25
°
C unless otherwise specified.
External, low ESR, 10 microfarad (minimum) capacitor across input is recommended for operation.
>> B-101
