www.make-ps.com
E-mail:info@make-ps.com
100VFS series
Single & Dual Output
DC/DC Converter
F
EATURES
•
•
•
•
•
•
H
IGH
I
SOLATION
- 3000 VDC
Up to 81 % Efficiency
Single and Dual Output, 1 watt converter
Available in 5, 12, and 24 VDC Inputs
Miniature Package
SMT Technology
D
ESCRIPTIONS
The 100VFS 1 Watt DC/DC’s are specially designed to provide
ultra-high levels of isolation 3000VDC in a miniature SIP
package. The series consists of 27 models with input voltages
of 5V, 12V and 24V, and offers standard output voltages of
3.3V, 5V, 9V, 12V, 15V, ±5V, ±9V, ±12V, and ±15V for a wide choice.
The 100VFS series is an excellent selection for a variety of
applications including distributed power systems, mixed
analog/digital subsystems, portable test equipment, local
power networks and battery backed systems.
I
NPUT
C
HARACTERISTICS
Min Typ Max Unit/Comments
Input Voltage
5 VDC Input Models
VDC
4.5 5 5.5
12 VDC Input Models 10.8 12 13.2
VDC
24 VDC Input Models 21.6 24 26.4
VDC
Input Fuse Requirements
5 VDC Input Models
mA; Slow blow type
500
12 VDC Input Models
mA; Slow blow type
200
15 VDC Input Models
mA; Slow blow type
100
Reverse Polarity Input Current
0.3 Amp
Input Filter
Input Capacitor
O
UTPUT
C
HARACTERISTICS
Output Voltage Set Point
Output Voltage Balance
(Duals)
Line Regulation
Min Typ Max Unit/Comments
±1.0 ±3.0 % Output voltage at
nominal line & FL
±0.1 ±1.0 % Equal Output
Loads
±1.2 ±1.5 %; % Change /
Percentage change
in Input
voltage
See
% Output voltage
Model Selection measured from FL
Guide
to 20% load
65 100 mV p-p, Nom.Line
@FL, 20MHz B.W.,
using 1
μf
bypass
capacitor
150 mV p-p, Over Line,
Load & Temp., 20
MHz B.W.,
using 1
μf
bypass
capacitor
<0.5 Second, Momentary
±0.01 ±0.02 % per degree C
G
ENERAL
C
HARACTERISTICS
Switching Frequency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
MTBF (MIL-HBK-217F)
Min Typ Max Unit/Comments
kHz
70 100 120
VDC, 1 minute
3000
Mohm, 500VDC
10,000
60 100 pF, 100kHz, 1Volt
Million Hours,
2
+25
o
C, Ground
Benign
Load Regulation
Ripple/Noise
Ripple/Noise
Short Circuit Protection
Temperature Coefficient
>> B-9
www.make-ps.com
E
NVIRONMENTAL
S
PECIFICATIONS
Operating Temp. Range
Storage Temp. Range
Relative Humidity
Cooling
Min
-25
-40
Typ Max
+85
+125
+95
Unit/Comments
o
C; Ambient
o
C
% Humidity; non-
condensing
Free-Air Convection
E-mail:info@make-ps.com
P
HYSICAL
C
HARACTERISTICS
Case Size
5V & 12V Input
24V Input
Case Material
Flammability
Weight
5V & 12 V Input
24V Input
Unit/Comments
0.77 X 0.24 X 0.40 inches
(19.5 X 6.1 X 10.2 mm)
0.77 X 0.28 X 0.40 inches
(19.5 X 7.1 X 10.2 mm)
Non-Conductive Black Plastic
UL94V-0
2.2 Grams
2.6 Grams
O
UTLINE
D
RAWING
0.77 (19.5)
SIDE VIEW
0.300
(7.62)
0.08 (2.1)
0.73 (18.5)
0.40 (10.2)
0.02 (0.5)
0.13 (3.2)
0.100 (2.54)
TYP
BOTTOM VIEW
1 2
5 6 7
0.010 (0.25)
0.05 (1.3)
0.24 (6.1) - 5V & 12V
0.28 (7.1) - 24V
0.020 (0.50)
P
IN
O
UT
C
HART
Pins
1
2
5
6
7
Single
+ Vin
- Vin
- Vout
No Pin
+ Vout
Dual
+ Vin
- Vin
- Vout
Common
+ Vout
Notes:
1. Unless otherwise specified dimensions are in inches (mm).
Tolerances
Inches
mm
X.XX = ±0.02
X.X = ±0.5
X.XXX= ±0.010
X.XX = ±0.25
Pin :
±0.002
±0.05
All specifications are typical at nominal input, nominal load and 25
°
C unless otherwise specified.
External, low ESR, 10 microfarad (minimum) capacitor across output is recommended for operation.
>> B-10
