Miniature Threaded
Miniature Threaded L and C Circuit Filters
Ordering Information
Please state Part Number.
Supplied with nut as standard.
DLT4
Circuit Diagram
DLT4/C/-
Materials
Cases and nut: Brass, silver finish.
Feedthrough terminations: Copper alloy, tin lead or silver finish.
Case Dimensions
All dimensions in millimetres.
9 max.
Body
4 A/F
3 min.
3.2 max.
5.9 max.
27 max.
14 min.
DLT4/L/-
THD END
Voltage Rating
-55°C to +85°C.
200 V d.c.
+125°C
100 V d.c.
Linearly derate between 85°C and 125°C
Ø 1 x 0.5
Color
Coding
1.1
1.0
Ø 0.07
Color
Coding
Nut 4.76 A/F
Thread
Minimum Component
Pitch (with nut)
Minimum Component
Pitch (without nut)
Mounting Torque
6-32 UNC (2A)
6 mm
5 mm
0.3 Nm
Characteristics
Part Number
DLT4/C/330
DLT4/C/680
DLT4/C/1000
DLT4/C/4700
DLT4/C/10000
DLT4/C/22000
DLT4/L/330
DLT4/L/680
DLT4/L/1000
DLT4/L/4700
DLT4/L/10000
DLT4/L/22000
Cap. (pF)
Current Rating
(-20% +80%)
(A d.c.)
330
680
1000
4700
10000
22000
330
680
1000
4700
10000
22000
10
10
10
10
10
10
10
10
10
10
10
10
Typical Insertion Loss (dB) (50
Ω
system)
—
1
1
3
8
12
—
1
1
3
8
12
2
4
9
20
27
30
2
4
9
21
28
31
18
22
26
36
44
50
20
24
28
38
48
54
35
35
40
50
63
68
38
38
43
56
70
70
60
70
70
70
70
70
60
70
70
70
70
70
Color Code
1 MHz 10 MHz 100 MHz 1 GHz 10 GHz (hex end/thread end)
Green/White
Grey/White
Brown/White
Red/White
Black/White
Blue/White
Green/Red
Grey/Red
Brown/Red
Red/Red
Black/Red
Blue/Red
www.oxleygroup.com/emc
ODCSM40489/9/2006
