luXeon coB core range (Gen 3)
Uniform, high efficacy and easy to design array
The third generation of LUXEON CoB represents a new breakthrough
for arrays. The efficacies will be >160 lm/W for 70CRI and 80CRI
products. Due to its small Light Emitting Surface (LES) and industry-
leading thermal resistance, LUXEON CoB is easy to work with, enabling
simplified and less expensive luminaire designs. LUXEON CoBs are
hot-tested at 85°C—real world operating conditions—which means
additional testing can be minimized. LUXEON CoB LEDs are available
in 3-step MacAdam ellipse, ensuring uniform optical performance in
a wide range of applications.
Features and BeneFIts
Highest flux densities with industry’s smallest LES
3-step MacAdam ellipse color definition:
Freedom from Binning
for color
consistency from luminaire to luminaire
Up to 4x lower thermal resistance than competition, enabling smaller
heatsinks and higher lumens
Supported by a comprehensive optical, mechanical and electrical ecosystem
PrImary aPPlIcatIons
Architectural
Downlights
High Bay & Low Bay
Lamps
Outdoor
Specialty Lighting
Spotlights
DS162 LUXEON CoB Core Range (Gen 3) Product Datasheet ©2017 Lumileds Holding B.V. All rights reserved.
No. E352519
Table of Contents
General Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Lumen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Optical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
Electrical and Thermal Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Characteristic Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Spectral Power Distribution Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Forward Current Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Radiation Pattern Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15
Color Bin Definitions
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Packaging and Labeling Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Inner Box.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Outer Box
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
DS162 LUXEON CoB Core Range (Gen 3) Product Datasheet 20170622 ©2017 Lumileds Holding B.V. All rights reserved.
i
General Product Information
Product Test Conditions
LUXEON CoB Core Range (Gen 3) LEDs are tested and binned with a DC drive current specified below at a junction temperature,
T
j
, of 85°C:
200mA
200mA
300mA
450mA
600mA
900mA
1200mA
1600mA
1600mA
2100mA
2250mA
–
–
–
–
–
–
–
–
–
–
–
LUXEON CoB 1202s
LUXEON CoB 1202
LUXEON CoB 1203
LUXEON CoB 1204
LUXEON CoB 1205
LUXEON CoB 1208
LUXEON CoB 1211
LUXEON CoB 1216
LUXEON CoB 1812
LUXEON CoB 1321
LUXEON CoB 1825
Part Number Nomenclature
Part numbers for LUXEON CoB Core Range (Gen 3) follow the convention below:
L 2 C 5 –
A A B B C C C C D E E F F
Where:
A A
B B
C C C C
D
E E
F F
–
–
–
–
–
–
designates nominal CCT (22=2200K, 27=2700K, 30=3000K, 35=3500K, 40=4000K, 50=5000K,
56=5600K, 57=5700K, 65=6500K)
designates minimum CRI (70=70CRI, 80=80CRI, 90=90CRI)
designates product configuration (example: 1202, 1203, 1204, 1205, 1208, 1211, 1216, 1812, 1321, 1825)
designates options for product specification
designates light emitting surface (LES) size (06=6mm, 09=9mm, 13=13mm, 15=15mm,
19=19mm, 23=23mm, 29=29mm, 32=32mm)
designates options for product specification
Therefore, the following part number is used for a LUXEON CoB 1203, 3000K 80CRI, with a 9mm LES:
L 2 C 5 –
3 0 8 0 1 2 0 3
E
0 9
0 0
Lumen Maintenance
Please contact your local Sales Representative or Lumileds Technical Solutions Manager for more information about the
long-term performance of this product.
DS162 LUXEON CoB Core Range (Gen 3) Product Datasheet 20170622 ©2017 Lumileds Holding B.V. All rights reserved.
2
Environmental Compliance
Lumileds LLC is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON CoB Core
Range (Gen 3) is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment,
namely the RoHS Directive 2011/65/EU and REACH Regulation (EC) 1907/2006. Lumileds LLC will not intentionally add the
following restricted materials to its products: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB) or
polybrominated diphenyl ethers (PBDE).
Performance Characteristics
Product Selection Guide
Table 1. Product performance of LUXEON CoB Core Range (Gen 3) at specified test current, T
j
=85ºC .
Product
nomInal
cct
2200K
2700K
3000K
3500K
LUXEON
CoB
1202s
4000K
5000K
2200K
[5]
2700K
3000K
3500K
4000K
3000K
3500K
4000K
5000K
5700K
2200K
2700K
LUXEON
CoB
1202
3000K
3500K
4000K
5000K
2200K
[5]
2700K
3000K
3500K
4000K
mInImum
crI
[1, 2, 3]
80
80
80
80
80
80
90
90
90
90
90
70
70
70
70
70
80
80
80
80
80
80
90
90
90
90
90
lumInous FluX
[1]
(lm)
mInImum
675
797
837
854
863
863
589
662
689
725
742
923
923
968
968
942
703
830
876
893
899
899
625
690
729
752
772
tyPIcal
750
886
930
949
959
959
654
736
766
805
824
1026
1026
1075
1075
1047
781
922
973
992
999
999
694
766
810
836
858
tyPIcal
lumInous
eFFIcacy (lm/W)
109
128
135
138
139
139
95
107
111
117
119
149
149
156
156
152
113
134
141
144
145
145
101
111
117
121
124
test
current
(ma)
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
200
les
[4]
(mm)
6
6
6
6
6
6
6
6
6
6
6
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
Part numBer
L2C5-22801202E0600
L2C5-27801202E0600
L2C5-30801202E0600
L2C5-35801202E0600
L2C5-40801202E0600
L2C5-50801202E0600
L2C5-22901202E0600
L2C5-27901202E0600
L2C5-30901202E0600
L2C5-35901202E0600
L2C5-40901202E0600
L2C5-30701202E0900
L2C5-35701202E0900
L2C5-40701202E0900
L2C5-50701202E0900
L2C5-57701202E0900
L2C5-22801202E0900
L2C5-27801202E0900
L2C5-30801202E0900
L2C5-35801202E0900
L2C5-40801202E0900
L2C5-50801202E0900
L2C5-22901202E0900
L2C5-27901202E0900
L2C5-30901202E0900
L2C5-35901202E0900
L2C5-40901202E0900
Table 1 continued on next page.
1.
Lumileds maintains a tolerance of ±2 on CRI and ±6.5% on luminous flux measurements.
2.
Typical CRI is approximately 2 points higher than the minimum CRI specified, but this is not guaranteed.
3.
R9 value of 90CRI products is >50.
4. Light Emitting Surface (LES) is the inner diameter (phosphor area) inside the dam.
5.
AtmoSphere Technology creates the ideal ambiance for restaurants and other hospitality venues.
DS162 LUXEON CoB Core Range (Gen 3) Product Datasheet 20170622 ©2017 Lumileds Holding B.V. All rights reserved.
3
Table 1. Product performance of LUXEON CoB Core Range (Gen 3) at specified test current, T
j
=85ºC (continued) .
Product
nomInal
cct
3000K
3500K
4000K
5000K
5700K
6500K
2200K
2700K
LUXEON
CoB
1203
3000K
3500K
4000K
5000K
5700K
2200K
[5]
2700K
3000K
3500K
4000K
3000K
3500K
4000K
5000K
5700K
6500K
2200K
2700K
LUXEON
CoB
1204
3000K
3500K
4000K
5000K
5700K
2200K
[5]
2700K
3000K
3500K
4000K
mInImum
crI
[1, 2, 3]
70
70
70
70
70
70
80
80
80
80
80
80
80
90
90
90
90
90
70
70
70
70
70
70
80
80
80
80
80
80
80
90
90
90
90
90
lumInous FluX
[1]
(lm)
mInImum
1379
1379
1466
1466
1428
1391
1066
1258
1289
1315
1363
1363
1359
929
1045
1080
1140
1170
2124
2124
2258
2258
2199
2142
1641
1937
1980
2020
2098
2098
2093
1430
1609
1656
1755
1802
tyPIcal
1532
1532
1629
1629
1587
1546
1184
1398
1432
1461
1514
1514
1510
1032
1161
1200
1267
1301
2360
2360
2509
2509
2443
2380
1823
2152
2200
2244
2332
2332
2325
1589
1788
1840
1950
2003
tyPIcal
lumInous
eFFIcacy (lm/W)
148
148
157
157
153
149
114
135
138
141
146
146
146
100
112
116
122
126
151
151
160
160
156
152
117
138
141
144
149
149
148
102
115
118
125
128
test
current
(ma)
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
300
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
450
les
[4]
(mm)
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
9
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
13
Part numBer
L2C5-30701203E0900
L2C5-35701203E0900
L2C5-40701203E0900
L2C5-50701203E0900
L2C5-57701203E0900
L2C5-65701203E0900
L2C5-22801203E0900
L2C5-27801203E0900
L2C5-30801203E0900
L2C5-35801203E0900
L2C5-40801203E0900
L2C5-50801203E0900
L2C5-57801203E0900
L2C5-22901203E0900
L2C5-27901203E0900
L2C5-30901203E0900
L2C5-35901203E0900
L2C5-40901203E0900
L2C5-30701204E1300
L2C5-35701204E1300
L2C5-40701204E1300
L2C5-50701204E1300
L2C5-57701204E1300
L2C5-65701204E1300
L2C5-22801204E1300
L2C5-27801204E1300
L2C5-30801204E1300
L2C5-35801204E1300
L2C5-40801204E1300
L2C5-50801204E1300
L2C5-57801204E1300
L2C5-22901204E1300
L2C5-27901204E1300
L2C5-30901204E1300
L2C5-35901204E1300
L2C5-40901204E1300
Table 1 continued on next page.
1.
Lumileds maintains a tolerance of ±2 on CRI and ±6.5% on luminous flux measurements.
2.
Typical CRI is approximately 2 points higher than the minimum CRI specified, but this is not guaranteed.
3.
R9 value of 90CRI products is >50.
4. Light Emitting Surface (LES) is the inner diameter (phosphor area) inside the dam.
5.
AtmoSphere Technology creates the ideal ambiance for restaurants and other hospitality venues.
DS162 LUXEON CoB Core Range (Gen 3) Product Datasheet 20170622 ©2017 Lumileds Holding B.V. All rights reserved.
4
