300FR series
F
EATURES
•
•
•
•
•
Single & Dual Output
DC/DC Converter
Up to 64 % Efficiency
Single and Dual Output, 3 watt converter
Available in 5, 12, 24 and 48 VDC Inputs
Industry Standard Pinout
Short Circuit Protection
D
ESCRIPTIONS
The 300FR series 3 watt power modules are specially
designed to provide low output ripple and tight regulation in
a low-profile 24 pin DIP package. The series consists of 20
models with input voltages of 5V, 12V, 24V and 48V, and offers
regulated output voltages of 5V, 12V, 14V, ±12V and ±15.
The -25
o
C to +71
o
C operating temperature range makes it ideal
for data communication equipment, mobile battery driven
equipment, distributed power systems, telecommunication
equipment, mixed analog/digital subsystems, automatic test
instrumentation and industrial robot systems.
I
NPUT
C
HARACTERISTICS
Min Typ Max Unit/Comments
Input Voltage
5 VDC Input Models
4.5
12 VDC Input Models 10.8
24 VDC Input Models 21.6
48 VDC Input Models 43.2
Input Fuse Requirements
5 VDC Input Models
12 VDC Input Models
24 VDC Input Models
48 VDC Input Models
Reverse Polarity Input Current
Short Circuit Input Power
Input Filter
5
12
24
48
2000
1000
500
200
5.5
13.2
26.4
52.8
VDC
VDC
VDC
VDC
O
UTPUT
C
HARACTERISTICS
Output Voltage Set Point
Output Voltage Balance
(Duals)
Line Regulation
Min Typ Max Unit/Comments
±2.0 ±4.0 % Output voltage at
nominal line & FL
±1.0 ±3.0 % Equal Output
Loads
±0.2 ±0.5 % Output voltage
measured from
min. input line to
maximum
±0.2 ±0.5 % Output voltage
measured from FL
to 10% load
45 50 mV p-p, Nom.Line
@FL, 20MHz B.W.,
using 1
μf
bypass
capacitor
75 mV p-p, Over Line,
Load & Temp., 20
MHz B.W.,
using 1
μf
bypass
capacitor
%Rated Output Load
120
Continuous,
Automatic Recovery
±6 % deviation of Vout
for a 50% load
change
50
μS
for 50% load
change
±0.01 ±0.02 % per degree C
mA; Slow blow type
mA; Slow blow type
mA; Slow blow type
mA; Slow blow type
0.5 Amp
2500 mW
Pi Filter
G
ENERAL
C
HARACTERISTICS
Switching Frequency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
MTBF (MIL-HBK-217F)
Min Typ Max Unit/Comments
kHz
40 80
VDC, 1 minute
500
Mohm, 500VDC
1000
100 150 pF, 100kHz, 1Volt
Thousand Hours,
600
+25
o
C, Ground
Benign
Load Regulation
Ripple/Noise
Ripple/Noise
Overload Protection
Short Circuit Protection
Transient Response
Deviation
Transient Recovery Time
Temperature Coefficient
>> B-48
www.make-ps.com
E
NVIRONMENTAL
S
PECIFICATIONS
Operating Temp. Range
Operating Temp. Range
Storage Temp. Range
Relative Humidity
Cooling
Min
-25
-25
-40
Typ Max
+71
+90
+125
95
Unit/Comments
o
C; Ambient
o
C; Case
o
C
% Humidity; non-
condensing
Free-Air Convection
E-mail:info@make-ps.com
P
HYSICAL
C
HARACTERISTICS
Case Size
Case Material
Flammability
Weight
Unit/Comments
1.25 X 0.8 X 0.4 inches
(31.8 X 20.3 X 10.2 mm)
Black Coated Metal
UL94V-0
14 Grams
O
UTLINE
D
RAWING
1.25 (31.8)
0.15
(3.8)
SIDE VIEW
0.40
(10.2)
0.020 (0.50)
PIN DIA.
0.100
(2.54)
1 2 3
0.08 (2.0)
0.10
(2.5)
10 11 12
BOTTOM VIEW
24 23 22
15 14 13
0.600 0.80
(15.22) (20.3)
P
IN
O
UT
C
HART
Pins
Single
1
+ Vin
2
NC
3
NC
10
- Vout
11
+ Vout
12
- Vin
13
- Vin
14
+ Vout
15
- Vout
22
NC
23
NC
24
+ Vin
NC = No Connection
Dual
+ Vin
- Vout
Common
Common
+ Vout
- Vin
- Vin
+ Vout
Common
Common
-V out
+V in
Notes:
1. Unless otherwise specified dimensions are in inches (mm).
Tolerances
Inches
mm
X.XX = ±0.02
X.X = ±0.5
X.XXX= ±0.010
X.XX = ±0.25
Pin :
±0.002
±0.05
All specifications are typical at nominal input, nominal load and 25
°
C unless otherwise specified.
External, low ESR, 10 microfarad (minimum) capacitor across output is recommended for operation.
