315S5XFR Overview

Single & Dual Output DC/DC Converter

www.make-ps.com
E-mail:info@make-ps.com
300XFR series
Single & Dual Output
DC/DC Converter
F
EATURES
Up to 81% Efficiency
Single and Dual Output, 3 watt converter
Available in 5, 12, 24 and 48 VDC Inputs
2 - 1 Input Range
Industry Standard Pin out
Short Circuit Protection
D
ESCRIPTIONS
The 300XFR series power modules are high efficiency, low-
profile, 3 watt dc-dc converters that operate over input voltage
ranges of 4.5 - 9 VDC, 9 - 18 VDC, 18 - 36 VDC and 36 - 75 VDC
and provide precisely regulated output voltages of 5V, 12V, 15V,
±12V and ±15V.
The -40
o
C to +71
o
C operating temperature range makes it ideal
for data communication equipment, mobile battery driven
equipment, distributed power systems, telecommunication
equipment, mixed analog/digital subsystems, process/
machine control equipment, computer peripheral systems and
industrial robot systems.
I
NPUT
C
HARACTERISTICS
Min Typ Max Unit/Comments
Input Voltage
5 VDC Input Models
VDC
9
4.5 5
12 VDC Input Models
VDC
12 18
9
24 VDC Input Models
VDC
18 24 36
48 VDC Input Models
VDC
36 48 75
Under Voltage Shut Down
5 VDC Input Models
VDC
4
12 VDC Input Models
VDC
8.5
24 VDC Input Models
VDC
17
48 VDC Input Models
VDC
34
Input Fuse Requirements
5 VDC Input Models
mA; Slow blow type
1500
12 VDC Input Models
mA; Slow blow type
700
24 VDC Input Models
mA; Slow blow type
350
48 VDC Input Models
mA; Slow blow type
135
Reverse Polarity Input Current
1 Amp
Short Circuit Input Power
1000 1500 mW
Input Filter
Pi Filter
O
UTPUT
C
HARACTERISTICS
Output Voltage Set Point
Output Voltage Balance
Line Regulation
Min Typ Max Unit/Comments
±0.5 ±2.0 % Output voltage at
nominal line & FL
±0.5 ±2.0 % Equal Output
Loads
±0.2 ±0.5 % Output voltage
measured from
min. input line to
maximum
±0.2 ±0.5 % Output voltage
measured from FL
to 10% load
45 60 mV p-p, Nom.Line
@FL, 20MHz B.W.,
using 1
μf
bypass
capacitor
100 mV p-p, Over Line,
Load & Temp., 20
MHz B.W.,
using 1
μf
bypass
capacitor
Continuous,
Automatic Recovery
±3 ±5 % deviation of Vout
for a 25% load
change
300 500
μS
for 25% load
change
±0.01 ±0.02 % per degree C
Load Regulation
Ripple/Noise
G
ENERAL
C
HARACTERISTICS
Switching Frequency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
MTBF (MIL-HBK-217F)
Min Typ Max Unit/Comments
kHz
300
VDC, 1 minute
500
Mohm, 500VDC
1000
500 pF, 100kHz, 1Volt
Million Hours,
1
+25
o
C, Ground
Benign
Ripple/Noise
Short Circuit Protection
Transient Response
Deviation
Transient Recovery Time
Temperature Coefficient
