Single & Dual Output
DC/DC Converter
FEATURES:
●2:1Wide
Input Voltage.
●8
Watt 24PIN DIL Package.
●Efficiency
To 82%
●PI
Input Filter.
●1600Vdc
Isolation
●MTBF:>1,500,000
hrs
●Operating
Temperature:-40℃ TO +100℃
Series FKC08
8Watt | DC-DC Converter
APPLICATIONS:
●
Wireless Network
●
Telecom/Datacom
●
Industry Control System
●
Measurement Equipment
●
Semiconductor Equipment
M
ODEL
S
ELECTION
C
HART
Input
Voltage
Vdc
4.5-9
4.5-9
4.5-9
4.5-9
9-18
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
36-72
36-72
Part Number
FKC08-05S12
FKC08-05S15
FKC08-05D12
FKC08-05D15
FKC08-12S03
FKC08-12S05
FKC08-12S12
FKC08-12S15
FKC08-12D05
FKC08-12D12
FKC08-12D15
FKC08-24S03
FKC08-24S05
FKC08-24S12
FKC08-24S15
FKC08-24D05
FKC08-24D12
FKC08-24D15
FKC08-48S03
FKC08-48S05
FKC08-48S12
FKC08-48S15
FKC08-48D05
FKC08-48D12
Input
Current
No-Load
(mA TYP)
25
25
25
25
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
Full Load
(mA TYP)
Output
Voltage
Vdc
12
15
±12
±15
3.3
5
12
15
±5
±12
±15
3.3
5
12
15
±5
±12
±15
3.3
5
12
15
±5
±12
Output
Current
Full Load
(mA)
Efficiency
%TYP
83
83
83
83
85
85
85
85
85
85
85
85
85
85
85
85
85
85
85
85
85
85
85
85
1927
1927
1927
1927
784
784
784
784
784
784
784
392
392
392
392
392
392
392
196
196
196
196
196
196
666
533
±333
±266
2424
1600
666
533
±800
±333
±267
2424
1600
666
533
±800
±333
±267
2424
1600
666
533
±800
±333
FKC08-05S12/*** add Suffix SMD for SMD package
NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at
rated output load unless otherwise specified.
Temperature Derating Graph
OutPut Power(%)
100
Temperature Derating Graph
75
50
25
0
-40
75
85 100
Tolerance Envelope Graph
Tolerance Envelope
120%
Graph
Output Voltage(%)
110%
100%
90%
80%
70%
100%
110%
120%
20%
30%
40%
50%
60%
70%
80%
10%
90%
Nature Convection
Ambient Temperature(
℃
)
Output Current(%)
1/3
www.make-ps.com
Input Specifications
Parameters
Voltage Types
Filter
Conditions
Pi TYPE
Min
E-mail:info@make-ps.com
Typ
Max
2:1
Units
Output Specifications
Parameters
Voltage Tolerance
Short Circuit Protection
Conditions
Continuous
Single (F.L To 10% Load)
Dual (F.L To 1/4 Load)
BW=DC To 20MHz
50% load step change
Conditions
500Vdc
Non Condensing
Free air Convection
Min
Typ
Max
±2
±0.5
±0.5
±1.0
100
Units
%
%
%
%
mVp-p
us
Units
MΩ
KHz
℃
%
g
mm
Line Regulation
Load Regulation
Load Regulation
Ripple & Noise
Transient response setting time
350
Min
1000
-40
Typ
400
Max
100
95
General Specifications
Parameters
Isolation Resistance
Switching Frequency
Operating Temperature
Humidity
Cooling
Case material
Weight
Dimensions
Potting Material
Radiated Emissions
Radiated Emissions
EN55022
FCC 47 CFR Part 15 subpart A
Nickel Coated With Non-Conductive Base
16.2
31.6x20.1x10.0
Epoxy (UL94V-0 rated)
CLASS A
CLASS A
Suggest adding input external filter(C1,C2,L)to meet conducted emissions (En55022 class A)
12uH
L
C1
C2
+Vin
+Vout
Load
DC/DC
Converter
-Vin
-Vout
2.2uF/100V
2.2uF/100V
Part Number
Recommended Test Circuit
Vin
Cin
Single
Cout
GND
5V & 12V :Cin 100uF,25V
24V & 48V:Cin 10uF,100V
+Vout
100uF/25V
Vin
Cin
GND
100uF/25V
+Vout
COM
-Vout
Dual
Cout
Cout
100uF/25V
-Vout
12V :Cin 100uF,25V
24V & 48V:Cin 10uF,100V
2/3
www.make-ps.com
O
UTLINE
D
RAWING
31.80
20.30
E-mail:info@make-ps.com
Package Style and Pinning (mm)
10.20
3.8
2
20.30
2.54
5.10
15.20
DIP24 Package Style
Pin Connections
Pin #
1
2
3
9
11
14
16
22
23
Single
ON/OFF
-Vin
-Vin
NC
NC
+Vout
-Vout
+Vin
+Vin
Dual
ON/OFF
-Vin
-Vin
Com
-Vout
+Vout
Com
+Vin
+Vin
0.25 x 0.50
Rectangular Pin
9
11
1 2 3
Bottom View
23 22
16
14
NC = No Connection
Pin Pitch Tolerance ±0.35 mm
SMD Package Style
32.00
31.40
11.20
10.90
3.81
6.35
21.30
25.40
20.30
SMD Package Style
Same spec. as the original DIP spec. and pin
definition, excl. of the SMD type pin.
2.54
Pin Connections
Pin #
Single
1
ON/OFF
2
-Vin
3
-Vin
9
NC
11
NC
14
+Vout
16
-Vout
22
+Vin
23
+Vin
Others
NC
NC = No Connection
Dual
ON/OFF
-Vin
-Vin
Com
-Vout
+Vout
Com
+Vin
+Vin
NC
Pin area
0.1 x 0.50
1 2 3 4 5
0.50
9 10 11 12
2.54
1.60
2.40
23.40
Bottom View
24 23 22 21 20
16 15 14 13
26.54
24.14
1
Top View
Pin Pitch Tolerance ±0.35 mm
27.94
11 x 2.54
All specifications are typical at nominal input, nominal load and 25
°
C unless otherwise specified.
External, low ESR, 10 microfarad (minimum) capacitor across output is recommended for operation.
Make Power world-class design, development and manufacturing team stands ready to work with you to deliver the exact power
converter you need for your ready to work with you to deliver the exact power converter you need for your demanding, large volume
OEM applications. And ... we ll do it on time and within budget
Our experienced applications and design staffs; quick-turn prototype capability; highly automated, SMT assembly facilities;
and in-line SPC quality-control techniques combine to give us the unique ability to design and deliver any quantity of power
converters to the highest standards of quality and reliability.
We have compiled a large library of DC/DC designs that are currently used in a variety of telecom, medical, computer, railway,
aerospace and industrial applications. We may already have the converter you need.
Contact us. Our goal is to provide you the highest-quality, most cost-effective power converters available.
CUSTOM CAPABILITIES
3/3
This datasheet has been downloaded from:
www.EEworld.com.cn
