C0805C103K4RACAUTO datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> C0805C103K4RACAUTO

C0805C103K4RACAUTO: DescriptionCapacitor, Ceramic, Chip, General Purpose, 0.01uF, 16V, ±10%, X7R, 0805 (2012 mm), -55º ~ +125ºC, Bulk; CategoryPassive components capacitor; File Size1MB，25 Pages; ManufacturerKEMET; Websitehttp://www.kemet.com; Environmental Compliance

Download Datasheet Parametric View All

C0805C103K4RACAUTO Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	C0805C103K4RACAUTO	-	-	View	Buy Now

C0805C103K4RACAUTO Overview

Capacitor, Ceramic, Chip, General Purpose, 0.01uF, 16V, ±10%, X7R, 0805 (2012 mm), -55º ~ +125ºC, Bulk

C0805C103K4RACAUTO Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	KEMET
Parts packaging code	0805
package instruction	CHIP
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	0.01 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	0.78 mm
JESD-609 code	e3
length	2 mm
Installation features	SURFACE MOUNT
multi-layer	Yes
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
Package form	SMT
method of packing	TR, PUNCHED PAPER, 7 INCH
positive tolerance	10%
Rated (DC) voltage (URdc)	16 V
Guideline	AEC-Q200
size code	0805
surface mount	YES
Temperature characteristic code	X7R
Temperature Coefficient	15% ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
width	1.25 mm

Preview

Download Datasheet

View All

Surface Mount Multilayer Ceramic Chip Capacitors (SMD MLCCs)

X7R Dielectric, 6.3 – 250 VDC (Commercial Grade)

Overview

KEMET’s X7R dielectric features a 125°C maximum

operating temperature and is considered temperature

stable. The Electronics Components, Assemblies and

Materials Association (EIA) characterizes X7R dielectric as

a Class II material. Components of this classification are

fixed, ceramic dielectric capacitors suited for bypass and

decoupling applications or for frequency discriminating

circuits where Q and stability of capacitance characteristics

are not critical. X7R exhibits a predictable change in

capacitance with respect to time and voltage, boasting a

minimal change in capacitance with reference to ambient

temperature. Capacitance change is limited to ±15% from

−55°C to +125°C.

Benefits

• −55°C to +125°C operating temperature range

• Lead (Pb)-free, RoHS, and REACH Compliant

• Temperature stable dielectric

• EIA 0402, 0603, 0805, 1206, 1210, 1808, 1812, 1825, 2220,

and 2225 case sizes

• DC voltage ratings of 6.3 V, 10 V, 16 V, 25 V, 35 V, 50 V,

100 V, 200 V, and 250 V

• Capacitance offerings ranging from 10 pF to 47 μF

• Available capacitance tolerances of ±5%, ±10% and ±20%

• Non-polar device, minimizing installation concerns

• 100% pure matte tin-plated termination finish allowing for

excellent solderability

• SnPb termination finish option available upon request

(5% Pb minimum)

Click image above for interactive 3D content

Open PDF in Adobe Reader for full functionality

Applications

Typical applications include decoupling, bypass, filtering and transient voltage suppression.

One world. One KEMET

Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com

C1002_X7R_SMD • 11/8/2018
