TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01844
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
Website: http: //www.microsemi.com
SWITCHING DIODE
– METALLURGICALLY BONDED
– HERMETICALLY SEALED
– DOUBLE PLUG CONSTRUCTION
Qualified per MIL-PRF-19500/241
DEVICES
LEVELS
1N3595AUR-1
LL3595A
MLL3595A
JAN
JANTX
JANTXV
MAXIMUM RATING AT 25°C
Operating Temperature:
Storage Temperature:
Surge Current A, sine 1S:
Surge Current A, sine 1µS:
Total Power Dissipation:
Operating Current:
D.C. Reverse Voltage (VRWM):
-65°C to +175°C
-65°C to +175°C
500mA
4A
500mW
150mA, T
A
= +25°C
125V
DC ELECTRICAL CHARACTERISTICS
V
F
Ambient
(°C)
25
25
25
25
25
25
I
F
mA
1
5
10
50
100
200
Min
V
0.52
0.60
0.65
0.74
0.79
0.83
Max
V
0.70
0.765
0.80
0.88
0.92
1.00
Ambient
(°C)
25
150
I
R
V
R
Min
V (dc) µA
125
-
125
-
V
BR
I
R
µA
100
DO-213AA
Min
V
150
Max
V
-
Max
µA
0.002
3
Ambient
(°C)
-55
AC ELECTRICAL CHARACTERISTICS AT 25°C
Min
Capacitance @ 0V
T
RR
@ I
F
= 10mA
V
R
= 35V
-
-
Max
8.0
3.0
Unit
pF
µsec
LDS-0073 Rev. 2 (100246)
Page 1 of 2
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01844
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
Website: http: //www.microsemi.com
PACKAGE DIMENSIONS
NOTE:
1. Dimensions are in inches.
2. Millimeters are given for general information only.
3. Dimensions are pre-solder dip.
4. Referencing to dimension S, minimum clearance of glass body to
mounting surface on all orientations.
5. In accordance with ASME Y14.5M, diameters are equivalent to
φx
symbology.
Ltr
BD
BL
ECT
S
Dimensions
Inches
Millimeters
Min
Max
Min
Max
.063
.067
1.60
1.70
.130
.146
3.30
3.70
.016
.022
0.41
0.55
.001 Min
0.03 Min
Notes
DESIGN DATA
Case:
Hermetically sealed glass package per MIL-PRF-19500/241 DO-213AA outline
Lead Material:
Copper clad steel
Lead Finish:
Tin / Lead
Thermal Impedance (Z
θJX
):
70°C/W maximum
Polarity:
Cathode end is banded
FIGURE 1. Physical dimensions - 1N3595UR-1, 1N3595AUR-1 (DO-213AA)
LDS-0073 Rev. 2 (100246)
Page 2 of 2
