TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http: //www.microsemi.com
SWITCHING DIODE
– METALLURGICALLY BONDED
– HERMETICALLY SEALED
– DOUBLE PLUG CONSTRUCTION
Qualified per MIL-PRF-19500/403
DEVICES
QUALIFIED LEVELS
1N4500
JAN
JANTX
MAXIMUM RATING AT 25°C
Operating Temperature:
Storage Temperature:
Surge Current A, sine 1S:
Surge Current A, sine 1μS:
Leakage Current: 100nA
DC ELECTRICAL CHARACTERISTICS
V
F
Ambient
(°C)
25
25
25
25
25
I
F
mA
.250
1
10
20
300
Min
V
0.47
0.52
0.64
0.67
--
Max
V
0.56
0.60
0.72
0.77
1.10
DO-35
Ambient
(°C)
25
I
R
V
R
V(dc)
75
Min
μA
--
Max
nA
100
Ambient
(°C)
25
V
BR
I
R
μA
100
Min
V
80
Max
V
--
-65°C to +175°C
-65°C to +200°C
0.5A
4A
75V, T
A
= +25°C
NOTE:
(1) Derate 2.0mAdc/°C for TA > =25°C
AC ELECTRICAL CHARACTERISTICS AT 25°C
Min
Capacitance @ 0V
I
F
= I
R
= 10mA
R
L
= 100 ohms
--
--
Max
4.0
6.0
Unit
pF
ns
LDS-0154 Rev. 1 (100198)
Page 1 of 2
TECHNICAL DATA SHEET
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 620-2600 / Fax: (978) 689-0803
Website: http: //www.microsemi.com
PACKAGE DIMENSIONS
NOTES:
1.
Metric equivalents (to the nearest .01mm) are
give for general information only and are based
upon 1 inch = 25.4mm.
Both leads shall be within the specified limits
(see 3.3.1).
The maximum diameter of dimension B shall
apply for dimension A.
The minimum diameter for dimension B shall
apply over at least .075 (1.91mm) of dimension
A.
The specified lead diameter applies in the zone
between .050 (1.27mm) and 1.00 (25.4mm)
from the diode body to the end of the lead.
Outside of this zone the lead diameter shall not
exceed diameter B.
Dimensions
Ltr
Min
A
B
C
D
Inches
Max
.160
.075
1.500
.022
Millimeters
Min
Max
4.06
1.99
25.40
38.10
.46
.56
Note
2.
3.
4.
1.000
.018
3, 4
2
5, 2
5.
FIGURE 1: Physical dimensions diode: TYPE 1N4500
DESIGN DATA
Case:
Hermetically sealed glass package per MIL-PRF-19500/403. DO-35 outline.
Lead Material:
Copper clad steel
Lead Finish:
Tin / Lead
Marking:
70°C/W maximum
Polarity:
Cathode end is banded.
LDS-0154 Rev. 1 (100198)
Page 2 of 2
