TABLE OF CONTENTS
1
2
3
PART NUMBERING SYSTEM ............................................................................................................................................4
MAIN FEATURES..................................................................................................................................................................5
MECHANICAL SPECIFICATION ......................................................................................................................................6
3.1
3.2
4
4.1
4.2
4.3
4.4
4.5
4.6
5
6
MECHANICAL CHARACTERISTICS..........................................................................................................................6
MECHANICAL DRAWING...........................................................................................................................................7
ABSOLUTE MAXIMUM RATINGS.............................................................................................................................8
ELECTRICAL CHARACTERISTICS............................................................................................................................8
INTERFACE PIN ASSIGNMENT .................................................................................................................................9
BLOCK DIAGRAM......................................................................................................................................................10
POWER SUPPLY CIRCUIT.........................................................................................................................................10
TIMING CHARACTERISTICS....................................................................................................................................11
ELECTRICAL SPECIFICATION ........................................................................................................................................8
OPTICAL SPECIFICATION ..............................................................................................................................................14
BACKLIGHT SPECIFICATION........................................................................................................................................16
6.1
6.2
WHITE LED EDGE BACKLIGHT CHARACTERISTICS .........................................................................................16
CCFL BACKLIGHT CHARACTERISTICS ................................................................................................................16
7
QUALITY ASSURANCE SPECIFICATION ....................................................................................................................17
7.1
CONFORMITY .............................................................................................................................................................17
7.2
DELIVERY ASSURANCE...........................................................................................................................................17
7.2.1
Delivery inspection standards...................................................................................................................................17
7.2.2
Zone definition ..........................................................................................................................................................18
7.2.3
Visual inspection .......................................................................................................................................................18
7.2.4
Standard of appearance inspection...........................................................................................................................19
8
9
RELIABILITY SPECIFICATION......................................................................................................................................21
HANDLING PRECAUTIONS .............................................................................................................................................22
Page
2 / 22
DENSITRON TECHNOLOGIES plc. – PROPRIETARY DATA – ALL RIGHTS RESERVED
1 PART NUMBERING SYSTEM
LM
066
-
BACKLIGHT TYPE
3 =
Module without Backlight or with EL Backlight
4 =
Module with LED Backlight
6 =
Module with CCFL Backlight
POLARIZER TYPE
B = Transflective: light background
E = Transmissive: dark background
BACKLIGHT COLOR
G = Yellow-Green (Standard)
W = White LED
None if CCFL Backlight
FLUID TYPE AND POWER SUPPLY
D = Standard temperature range with external negative voltage
operation
S = Standard temperature range with on-board negative voltage
generation
H = Wide temperature range with external negative voltage operation
W = Wide temperature range with on-board negative voltage generator
TEMPERATURE COMPENSATION CIRCUIT
N = Without on board temperature compensation circuit
C = With on board temperature compensation circuit
B
G
Y
F
=
=
=
=
COLOR FOR STN FLUID
STN Blue background (available for E polarizer type only)
STN Blue Pixels on Gray background for B polarizer types only
STN Blue Pixels on Yellow background for B polarizer types only
FSTN Black Pixels or background depending on B or E polarizer type
ADDITIONNAL OPTIONS
12 = it is mentioned if top view angle is needed
HL = High Luminosity for White LED Backlight if avaible
“LM” AT THE BEGINNING OF THE PART NUMBER IS
REPLACED BY “TS” IF THE MODULE HAS A TOUCH PANNEL
Page
4 / 22
DENSITRON TECHNOLOGIES plc. – PROPRIETARY DATA – ALL RIGHTS RESERVED
