ISC-1812
Vishay Dale
Wirewound, Surface Mount, Molded, Shielded Inductors
FEATURES
• Molded construction provides superior strength
and moisture resistance
• Tape and reel packaging for automatic handling,
2000/reel, EIA-481
• Compatible with vapor phase and infrared reflow
soldering
• Shielded construction minimizes coupling to other
components
• Compliant to RoHS Directive 2002/95/EC
• Halogen-free according to IEC 61249-2-21 definition
STANDARD ELECTRICAL SPECIFICATIONS
IND.
(μH)
0.1
0.1
0.2
0.2
0.2
0.3
0.3
0.4
0.5
0.6
0.7
0.8
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
270.0
330.0
390.0
470.0
560.0
680.0
820.0
1000.0
TEST
FREQ.
SRF DCR
(MHz)
MIN. MAX.
L & Q Q MIN. (MHz)
()
25.2
30
460
0.23
25.2
30
400
0.26
25.2
30
390
0.29
25.2
30
350
0.32
25.2
30
310
0.36
25.2
30
280
0.40
25.2
30
240
0.45
25.2
30
215
0.60
25.2
30
205
0.75
25.2
30
195
0.80
25.2
30
165
0.95
25.2
30
155
1.20
7.96
30
140
0.35
7.96
30
120
0.38
7.96
30
100
0.40
7.96
30
90.0
0.43
7.96
30
80.0
0.46
7.96
30
67.0
0.49
7.96
30
61.0
0.55
7.96
30
56.0
0.59
7.96
30
50.0
0.62
7.96
30
40.0
0.69
7.96
30
32.0
0.75
7.96
30
30.0
0.82
2.52
50
25.0
0.90
2.52
50
22.0
1.00
2.52
50
18.0
1.10
2.52
50
15.0
1.24
2.52
50
14.0
1.36
2.52
50
13.0
1.56
2.52
50
12.0
1.72
2.52
50
11.0
1.89
2.52
50
9.0
2.10
2.52
50
8.0
2.34
2.52
50
7.6
2.60
2.52
50
7.2
2.86
0.796
50
7.0
3.25
0.796
50
6.0
3.64
0.796
50
5.0
4.16
0.796
40
4.5
5.72
0.796
40
4.2
6.30
0.796
40
4.0
6.90
0.796
40
3.7
7.54
0.796
40
3.5
8.20
0.796
40
3.3
9.20
0.796
40
2.8
10.50
0.796
40
2.6
12.00
0.796
40
2.2
13.50
0.252
40
2.0
16.00
RATED DC
CURRENT
(mA)
(1)
552
519
491
468
441
418
394
342
306
296
271
242
447
429
418
403
390
378
357
344
336
333
306
292
279
265
252
238
227
212
202
192
183
173
164
156
147
139
130
111
105
101
96
92
87
82
76
72
66
TOL.
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 20 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
± 10 %
ELECTRICAL SPECIFICATIONS
Inductance Range:
0.10 μH to 1000 μH
Inductance Tolerance:
± 20 % for 0.10 μH to 0.82 μH
± 10 % for 1.0 μH to 1000 μH
standard
± 10 %, ± 5 %, ± 3 % available
Operating Temperature:
- 55 °C to + 125 °C
Coilform Material:
Non-magnetic for 0.10 μH to 0.82 μH
Powdered iron for 1.0 μH to 22 μH
Ferrite for 27 μH to 1000 μH
TEST EQUIPMENT
• H/P 4342A Q meter with Vishay Dale test fixture or equivalent
• H/P 4191A RF impedance analyzer (for SRF measurements)
• Wheatstone bridge
DIMENSIONS
in inches [millimeters]
0.126 ± 0.008
[3.200 ± 0.203]
0.177 ± 0.008
[4.500 ± 0.203]
0.126 ± 0.008
[3.200 ± 0.203]
0.037 ± 0.008
[0.940 ± 0.203]
0.006 [0.152]
Ref. Typ.
0.030 ± 0.004
[0.762 ± 0.102]
Typ.
+ 0.004
- 0.008
+ 0.102
[1.270
- 0.203
]
0.050
Typ.
0.124 [3.15]
Ref.
Guidelines for
Parallel Component
Printed Circuit
Mounting Pads on
ISC-1812 Chip
Inductors
0.158
[4.0]
0.181
[4.6]
0.024
[0.6]
(1)
0.158
[4.0]
0.059
[1.5]
0.118 [3.0]
0.059
[1.5]
Note
(1)
Recommended minimum spacing between components
PART MARKING
- Vishay Dale
- Inductance value
- Date code
www.vishay.com
1
Note
(1)
Rated DC current based on the maximum temperature rise, not
to exceed 40 °C at + 85 °C ambient
Document Number: 34061
Revision: 24-Feb-11
