CS-18S23O-T Overview

RF Coaxial Relay

CS-18S23O-T Parametric

Parameter Name	Attribute value
Maker	Teledyne Technologies Incorporated
Reach Compliance Code	compliant
ECCN code	EAR99
Relay type	RF COAXIAL RELAY

Preview

Download Datasheet

View All

Elite

CS-18

Normally Open

High Power DC-12GHz Multi - Throw Switch

SP3T to SP6T versions only

The CS-18 Switch is a broadband multi-position coaxial switch designed to switch RF

signals from one input port to any one of 3 through 6 output ports. It is readily adapted to any

50 Ohms transmission line system. The standard actuator gives individual solenoid control of

each position and when de-energized, all positions are open. Standard actuator voltage is 28

VDC. The primary advantage of this switch over the min-

iature versions shown on previous pages is the higher

power handling capability.

Specifications

RF Contacts:

Actuator

Break before make

Voltage (VDC) 20

Current (mA)

Switching Time:

Connectors:

Weight:

20 msec max

600 480 270

SP7T and SP8T version available. See additional

datasheets

SMA (f), TNC(f)(max frequency 11GHz only)*, N Type (f)

9 oz. max (3 Position) 11 oz (6 Position)

Temperature Range:

-55

C to +85

C (Operating)

Shock:

Vibration:

Humidity:

Typical

Contact Life:

RF Power Handling

MIL-STD-202 Method 213, Condition D (500G Non Operating)

MIL-STD-202 Method 214, Condition D (10G RMS Non Operating)

Moisture Seal Available

Million

Cycles

3000

Typical Performance

Hig

800

400

Sta

dar

nne

Power CW (Watts)

ype

cto

nne

200

cto

Return Loss

0.01

0.1

1.0

4.0

Frequency GHz

26.5

Frequency GHz

12.0

0.0

Specifications

VSWR (max)

Insertion Loss (max)

Isolation (min)

DC-1 GHz 1-4 GHz

1.25:1

0.30 dB

70.0 dB

1.40:1

0.40 dB

60.0 dB

4-12 GHz (TNC 11GHz only)

0.4

1.70:1

0.50 dB

60.0 dB

IL dB

0.01

Frequency GHz

12.0

Specifications subject to change without notice.

www.teledynecoax.com

email: coax@teledyne.com

Tel: (800) 351-7368

10/2007

Isolation dB
