SBR10150
Elektronische Bauelemente
RoHS Compliant Product
A suffix of “-C” specifies halogen free
VOLTAGE 150 V
10.0 Amp Schottky Barrier Rectifiers
TO-220
3.8
φ
+.2
HOLE THRU
.248
(6.3)
.180
(4.6)
FEATURES
Low forward voltage drop
High current capability
High reliability
High surge current capability
Epitaxial construction
.108
(2.75)
.412
(10.5)
MAX.
.050
(1.27)
.595
(15.1)
MAX.
MECHANICAL DATA
Case: Molded plastic
Epoxy: UL94V-0 rate flame retardant
Lead: Lead solderable per MIL-STD-202
method 208 guaranteed
Polarity: As Marked
Mounting position: Any
Weight: 1.93 grams (approximate)
.051 MAX.
(1.3)
.040 MAX.
(1.0)
.100
(2.54)
.550
(14.0)
.158
(4.0) MIN.
MAX.
.120
(3.05)
1 2 3
PIN 1
PIN 3
+
CASE
PIN 2
Dimensions in millimeters
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating 25
°
C ambient temperature unless otherwise specified.
Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, de-rate current by 20%.
TYPE NUMBER
Maximum Recurrent Peak Reverse Voltage
Working Peak Reverse Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
SYMBOL
V
RRM
V
RSM
V
DC
I
F
I
FSM
V
F
I
R
C
J
R
θJA
dv / dt
T
J
T
STG
SBR10150
150
150
150
5
10
130
0.86
0.75
0.3
8
350
2.5
10000
-50 ~ +150
-65 ~ +175
UNITS
V
V
V
A
A
V
mA
pF
°
C /W
V /
μs
°
C
°
C
Per Leg
Per Device
Peak Forward Surge Current, 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Maximum Instantaneous
I
F
= 5 A, T
A
= 25°C, per leg
Forward Voltage
I
F
= 5 A, T
A
= 125°C, per leg
Maximum DC Reverse Current
T
A
= 25°C
at Rated DC Blocking Voltage
T
A
= 125°C
Typical Junction Capacitance
(Note 1)
Typical Thermal Resistance
(Note 2)
Voltage Rate Of Chance (Rated V
R
)
Operating Temperature Range T
J
Storage Temperature Range T
STG
NOTES:
1. Measured at 1MHz and applied reverse voltage of 5.0V D.C.
2. Thermal Resistance Junction to Case.
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
01-June-2008 Rev.
C
Page 1 of 2
SBR10150
Elektronische Bauelemente
VOLTAGE 150 V
10.0 Amp Schottky Barrier Rectifiers
RATINGS AND CHARACTERISTIC CURVES (SBR10150)
Typical Forward Current Derating Curve
7
Average Forward Current (A)
Typical Forward Characteristic
100
5
Instantaneous Forward Current (A)
10
125℃
1
75℃
0
20
50
100
Tc, Case Temperature (℃)
150
190
25℃
Typical Junction Capacitance
400
0.1
0.4
0.5
0.6
0.7
0.8
0.9
1.0
Forward Voltage (V)
Junction Capacitance (pF)
300
200
Typical Reverse Characteristic
100
1
0
0.1
1
10
Revise Voltage (%)
100
0.1
125℃
100℃
200
Reverse Curren
t(mA)
Maximum Non- Repetitive Forward
Surge Current
Peak Forwad surge Current (A)
75℃
0.01
160
Tj=25℃
120
80
40
8.3mS Single half
Sine Wave
JEDEC Method
50℃
25℃
0.001
0
0
10
100
0.0001
10
40
70
100
130
160
Number of Cycles at 60Hz
Reverse Voltage(V)
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
01-June-2008 Rev.
C
Page 2 of 2
