QPL RF INDUCTORS - SURFACE MOUNT
MLRF0603
TRADITIONAL
Pb
COMPLIANT
RoHS
Ceramic Wirewound, Open Construction, MIL-PRF-83446
M83446/36 Ceramic Core
Outgassing Tested per ASTM E-595 (*)
PART
NUMBER (1)
MLRF0603-0018K
MLRF0603-0033*
MLRF0603-0036*
MLRF0603-0039*
MLRF0603-0043*
MLRF0603-0047*
MLRF0603-0056*
MLRF0603-0068*
MLRF0603-0087*
MLRF0603-010*
MLRF0603-012*
MLRF0603-015*
MLRF0603-016*
MLRF0603-018*
MLRF0603-022*
MLRF0603-027*
MLRF0603-033*
MLRF0603-039*
MLRF0603-047*
MLRF0603-056*
MLRF0603-068*
MLRF0603-082*
MLRF0603-100*
MLRF0603-120*
MLRF0603-150*
MLRF0603-180*
MLRF0603-220*
MLRF0603-270*
MIL
DASH
NUMBER
01^K
24^*
02^*
03^*
25^*
04^*
26^*
05^*
27^*
06^*
07^*
08^*
28^*
09^*
10^*
11^*
12^*
13^*
14^*
15^*
16^*
17^*
18^*
19^*
20^*
21^*
22^*
23^*
L
nH
1.8
3.3
3.6
3.9
4.3
4.7
5.6
6.8
8.7
10
12
15
16
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
L
TEST
FREQ
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
200
200
200
150
150
150
150
150
150
25
Q
MIN
MIL-PRF-83446/36
22
22
22
22
22
22
22
30
30
31
35
35
35
35
38
40
40
40
38
38
37
34
34
32
28
25
25
16
Q
TEST
FREQ
CERAMIC CORE
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
200
200
200
150
150
150
150
150
150
25
SRF
MHz
MIN
6000
6000
6000
6000
6000
6000
5800
5800
5200
4800
4000
4000
3400
3100
3000
2800
2300
2200
2000
1900
1700
1700
1400
1300
990
990
700
600
NOTES:
DCR
OHMS
MAX
0.070
0.070
0.070
0.070
0.090
0.090
0.100
0.100
0.140
0.160
0.130
0.170
0.170
0.170
0.190
0.220
0.220
0.240
0.280
0.310
0.360
0.540
0.750
0.790
1.14
1.28
1.70
1.78
CURRENT
RATING
mA DC MAX
1000
1000
1000
1000
885
885
840
840
705
665
735
645
645
645
610
565
565
540
500
475
440
360
305
300
245
235
200
195
* Suffix “G” for 2% tolerance, “J” for 5% tolerance or “K” for 10% tolerance
(1) Add suffix letter “S” to order with tin/lead solder termination, otherwise gold termination will be provided
˄ For MIL-PRF termination finish codes refer to NOTES below
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 35°C temperature
rise at an ambient temperature of 90°C
• DWV 200 Vrms @ Sea Level
80 Vrms @ 70,000 Feet
0.071
(1.8) 0.071
MAX (1.8)
MAX
• Weight maximum 0.008 grams (0.000282
ounces)
RECOMMENDED FOOT PRINT
RECOMMENDED FOOT PRINT
0.047
(1.19) 0.047
MAX (1.19)
MAX
0.030
(0.762) 0.030
REF (0.762)
REF
* Meets a TML (Total Mass Loss) requirement of
1.0% maximum when tested in accordance with
ASTM E-595; this calculation does not include
WVR (Water Vapor Recovered)
Gold termination is code “A” finish of
MIL-PRF-83446
0.071
H:
(1.8) (1.02) MAX -H:
0.040
Code A
MAX 0.040 (1.02) MAX Code
0.043 (1.09) MAX - Code B -& F A
0.047
(1.19)
MAX
0.043 (1.09) MAX - Code B & F
0.030
0.018
(0.762)
(0.457) 0.018
REF
REF (0.457)
REF
RECOMMENDED FOOT PRINT
0.008
(0.20) 0.008
REF (0.20)
REF
0.025
(0.64) 0.025
(0.64)
0.040
(1.02) 0.040
(1.02)
0.050
(1.27) 0.050
(1.27)
Tin-Lead solder termination is code “B” or “F”
finish of MIL-PRF-83446
Example of ordering by Military number for
MLRF0603-047K: M83446/36-14AK
MLRF0603-047KS: M83446/36-14FK
TAPE AND REEL SPECS:
H:
0.040 (1.02) MAX - Code A
0.043 (1.09) MAX - Code B & F
0.018
(0.457)
REF
0.008
(0.20)
REF
0.050
(1.27)
in. (mm)
0.025
(0.64)
0.040
(1.02)
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
3000
4 mm
8 mm
7 in.
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
111114
