SMF103B: Description1.0 Amp Surface Mount Silicon 1.0 Amp Surface Mount Silicon; CategoryDiscrete semiconductor diode; File Size255KB，3 Pages; ManufacturerSECOS; Websitehttp://www.secosgmbh.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

SMF103B Overview

1.0 Amp Surface Mount Silicon 1.0 Amp Surface Mount Silicon

SMF103B Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	SECOS
package instruction	R-PDSO-C2
Reach Compliance Code	compli
ECCN code	EAR99
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.3 V
JEDEC-95 code	DO-214AA
JESD-30 code	R-PDSO-C2
Maximum non-repetitive peak forward current	30 A
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Maximum output current	1 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum repetitive peak reverse voltage	200 V
Maximum reverse recovery time	0.15 µs
surface mount	YES
Terminal form	C BEND
Terminal location	DUAL

Preview

Download Datasheet

View All

SMF101B ~ SMF107B

Elektronische Bauelemente

RoHS Compliant Product

A suffix of “-C” specifies halogen-free and RoHS Compliant

50 ~ 1000 V

1.0 Amp Surface Mount Silicon

Fast Recovery Rectifiers

FEATURES



Surface mount device

High surge current capability

Low reverse current

Component in accordance to RoHS 2002/95/EC

SMB

B

A

C

MECHANICAL DATA



Cases：DO-214AA(SMB)

Case Material：Molded Plastic. UL Flammability

Classification Rating 94V-0

Terminals：Lead Free Plating(Tin Finish)

Solderable Per MIL-STD-202, Method 208

Polarity：Cathode Band

Weight：0.095 grams(approximate)

H

D

G

E

F

REF.

A

B

C

D

Millimeter

Min.

Max.

1.91

2.11

4.06

4.70

3.30

3.94

2.13

2.44

REF.

E

F

G

H

Millimeter

Min.

Max.

-

0.203

5.08

5.59

0.76

1.27

0.15

0.31

MAXIMUM RATINGS (T

A

=25℃ unless otherwise noted)

PART NUMBERS

PARAMETERS

Maximum repetitive peak

reverse voltage

Maximum RMS voltage

Maximum DC blocking voltage

Maximum average

forward rectified current

Peak Forward Surge Current, 8.3ms

single half sine-wave superimposed on

rated load

Maximum Instantaneous

Forward Voltage @ 3.0A

Maximum DC Reverse

Current at Rated DC

Blocking Voltage

@ TA=25°C

@TA=100°C

I

R

C

J

Trr

R

θJL

R

θJA

T

STG

, T

J

150

25

°C / W

80

-55 ~ 150

°C

SYMBOL

SMF

101B

50

35

50

SMF

102B

100

70

100

SMF

103B

200

140

200

SMF

104B

400

280

400

1.0

80

SMF

105B

600

420

600

SMF

106B

800

560

800

SMF

107B

1000

700

1000

UNITS

V

RRM

V

RMS

V

DC

I

F

I

FSM

V

A

V

F

1.30

10

100

50

250

500

V



A

pF

ns

Typical Junction Capacitance (NOTE1)

Maximum Reverse

Recovery Time (NOTE2)

Thermal Resistance,

Junction to Lead (Note 3)

Thermal Resistance,

Junction to Ambient (Note 3)

Storage and Operating

Temperature Range

NOTES:

1. Measured at 1.0MHz and applied reverse voltage of 4.0V D.C.

2. Measured with IF=0.5A, IR=1A, IRR=0.25A

3. Rating applies when surface mounted on the minimum pad size recommended, PC Board with 7.0 X 7.0mm copper pad.

http://www.SeCoSGmbH.com/

Any changes of specification will not be informed individually.

06-Jul-2010 Rev. C

Page 1 of 2
