MULTILAYER FERRITE
MCI
SPEER ELECTRONICS, INC.
INDUCTOR
MULTI LAYER FERRITE INDUCTORS
• Monolithic structure for closed magnetic path elimates
crosstalk and provides high reliability in a wide range of
temperature and humidity ranges
• Standard EIA Packages: 0603, 0805, 1206
• Nickel Barrier with solder overcoat for excellent
soderability
• Magnetically Shielded
TYPE
0603
0805
1206
L
0.063±0.006
(1.600.15)
0.079±0.008
(2.00±0.20)
0.126±0.008
(3.20±0.20)
W
0.031±0.006
(0.80)0.15)
0.049±0.008
(1.25±0.20)
0.063±0.010
(1.60±0.20)
H
0.031±0.006
(0.800.15)
0.035±0.008
(0.90±0.20)
0.043±0.008
(1.10+0.20)
P
0.014±0.006
(0.360.15)
0.020±0.0100
(0.51±0.25)
0.020±0.010
(0.51±0.25)
CHIP
INDUCTORS
DIMENSIONS [In (mm)]
ORDERING & SPECIFYING INFORMATION*
MCI
Type
0603
Size Code
0603
0805
1206
H
Material
Permability
Code:
H
J
TE
Packaging
TE: 7” Embossed Plastic
TED: 13: embossed
Plastic
None: Bulk
R10
Nominal
Inductance
047=0.04
µ
H
R10=0.100µH
J
Tolerance
J:
±5%
K:
±10%
M:
±20%
*Please Note: KSE’s Part Numbers Do Not Contain any Spaces or Hyphens.
TELEPHONE:
814-362-5536
70
FAX:
814-362-8883
MULTILAYER FERRITE
MCI
SPEER ELECTRONICS, INC.
INDUCTOR
STANDARD APPLICATIONS continued
TYPE
MCI1206HTER12*
MCI1206HTER15*
MCI1206HTER18*
MCI1206HTER22*
MCI1206HTER27*
MCI1206HTER33*
MCI1206HTER39*
MCI1206HTER47*
MCI1206HTER56*
MCI1206HTER68*
MCI1206HTER82*
MCI1206JTE1R0*
MCI1206JTE1R2*
MCI1206JTE1R5*
MCI1206JTE1R8*
MCI1206JTE2R2*
MCI1206JTE2R7*
MCI1206JTE3R3*
MCI1206JTE3R9*
MCI1206JTE4R7*
MCI1206JTE5R6*
MCI1206JTE6R8*
MCI1206JTE10R*
Ind.
L(µH)
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
10
Min
Q
20
20
20
20
20
20
25
25
25
25
25
45
45
45
45
45
45
45
45
45
45
45
45
LQ Test
Frequency
(MHz)
25
25
25
25
25
25
25
25
25
25
25
10
10
10
10
10
10
10
10
10
4
4
2
S.R.F.
DC.
Allowable Operating
Mhz
Res DC Current Temp
Type (max.)Ω Max. (mA)
220
200
185
170
150
145
135
125
115
105
100
75
65
60
55
50
45
41
38
35
32
29
24
0.30
0.30
0.40
0.40
0.50
0.60
0.50
0.60
0.70
0.80
0.90
0.40
0.50
0.50
0.50
0.60
0.60
0.70
0.80
0.90
0.9
0.9
1.0
250
250
250
250
250
250
200
200
150
150
150
100
100
50
50
50
50
50
50
50
25
25
25
-25ºC
to
85ºC
CHIP
INDUCTORS
TE: Embossed Plastic *Add Tolerance Character (J,K,M)
Other values available upon request
TE: Embossed Plastic *Add Tolerance Character (J,K,M)
Other values available upon request
TELEPHONE:
814-362-5536
72
FAX:
814-362-8883
MULTILAYER FERRITE
MCB/MCP/MCI/MHI
SPEER ELECTRONICS, INC.
INDUCTOR
ENVIRONMENTAL & MECHANICAL CHARACTERISTICS
PARAMETER
Operating Temperature
Storage Temperature
-55
0
C+125
0
C
40
0
C @ 70% Humidity.
Sealed plastic bags withdesiccant
shall be used to reduce the potential
of oxidation on the terminations dur-
ing storage
Flux:
5-10 sec dip
After Flux:
Air dry for 15 sec
Preheat:
1 50
0
C
±1
0ºC
Preheat Time:
60 sec
Solder Temp:
260ºC
±5ºC
Dip Time:
10
±1
sec
Flux:
5-10 sec dip
After Flux:
Air dry for 15 sec
Solder Temp:
245ºC
±5
0
C
Dip Time:
5
±0.5
sec
The bead shall be subjected to
the following 5 steps for the period of
time shown below. The 5 steps
constitute one (1) rotation.
4 rotations shall be carried out.
1) Flux:
5-10 sec
2) After Flux:
Air dry for 15 sec
3) Solder Temp:
230ºC
±5ºC
4) Dip Time:
5
±0.5
sec
5 )Cool:
Air cool for 60 seconds
REQUIREMENT
TEST METHOD
Resistance to
Solder Heat
Change in Impedance:
Relative
to value before test
±20%.
Appearance: There shall be no cracking
Solder Coverage:
More than 75% of the terminal
electrode shall be covered with solder.
CHIP
INDUCTORS
Solderability
Solder Coverage:
More than 95% of the
termination shall be covered with solder.
Leach Resistance
Appearance:
There shall be no visible signs
of physical or mechanical damage (i.e. no cracks).
Terminations:
Termination must not be leached
away for more than 5%.
Insulation Resistance
Solvent Resistance
Insulation Resistance:
Mm 1G ohms
Change in Impedance:
Relative to value
before test
±10%.
Cleaning by:
Washer:
Ultrasonic washer
(100W)
Solvent:
Isopropyl alcohol
Time:
3 minutes
Type
0402
0603
0805
1206
Type
0402
0603
0805
1206
W(kgf)
0.5
1 .0
1.5
W(kgf)
1.4
1.8
2.3
Time
NA
30 sec
±2
sec
30 sec
±2
sec
30 sec
±2sec
Time
NA
60 sec
60 sec
60 sec
Terminal Strength
(hanging test)
Appearance:
The terminal electrode shall not
break off, nor shall there be damage to the body.
Terminal Strength
(push test)
Appearance:
There shall be no evidence of
mechanical degradations to terminals or body.
TELEPHONE:
814-362-5536
76
FAX:
814-362-8883
MULTILAYER FERRITE
MCB/MCP/MCI/MHI
SPEER ELECTRONICS, INC.
INDUCTOR
ENVIRONMENTAL & MECHANICAL CHARACTERISTICS
Item
Bending Strength
Requirement
Appearance:
There shall be no physical or
mechanical damage.
Impedance:
Relative to initial value before
test
±10%
Appearance:
There shall be no physical or
mechanical damage.
Impedance: Relative to initial value
before test
±10%
Impedance:
Relative to initial value
±10%.
Conditions
Board: 90x40x1 .6mm
Bend:
1mm
Time:
5 sec
Mechanical Shock
Vibration
`
Only endurance conditioning by
sweeping shall be made. The entire
frequency range from 10-2,000Hz
return to10Hz in 20 minutes (this
shall constitute one cycle).
Amplitude:1.5mm
The test shall have a 1 SC peak and
Shall be applied for a period of 4
hours (12 cycles) in each of 3 m
mutually perpendicular directions (a t
total of 36 cycles within a total of 12
hours).
Step
Temperature
1-start
-40ºC
±200
2-hold
-40ºC
±200
3-transfer
4-hold
+1050º
±200
5-transfer
Time
30 mm
±5
mm
0.5 mm max.
30 mm
±5
mm
0.5 mm max.
Thermal Shock
Appearance:
There shall be no physical or
mechanical damage.
Impedance:
Relative to initial value
±20%.
DCR: The DOR shall not exceed initial
specified value.
Testing of the parts will be made at 0 hours,
250 hours and 500 hours. Before testing, t
he parts shall be allowed to cool to room
temperature for 24 hours.
Steps 1 thru 5 constitute one complete
cycle and the test shall consist of a
total of 500 cycles.
Temperature:
85ºC
±200
Relative Humidity:
85%
Time:
1,000 hours total
Apply:
1 OO%rated current
Load Humidity
Appearance:
There shall be no physical or
mechanical damage.
Impedance:
Relative to initial value
±15%.
Measurements shall be taken at 0 hours,
250 hours, 500 hours and 1,000 hours and
shall meet the conditions stated above.
Life Test
Appearance:
There shall be no physical or
mechanical damage
Impedance:
Relative to initial value
±15%
Measurements shall be taken at 0 hours,
250 hours, 5OO hours and 1,000 hours and
shall meet the conditions stated above.
Temperature:
85ºC
±2ºC
Time:
1,000 hours total
Apply:
100% rated current
TELEPHONE:
814-362-5536
77
FAX:
814-362-8883
CHIP
INDUCTORS
Force:
5OC
Time:
11 msec
There shall be 3 shocks in each of -
6 directions (18 shocks total).me
