TAK CHEONG
SEM IC O N DU C TO R
500 mW DO-35 Hermetically
Sealed Glass Zener Voltage
Regulators
Absolute Maximum Ratings
Parameter
Power Dissipation
Storage Temperature Range
Operating Junction Temperature
Lead Temperature (1/16” from case for 10 seconds)
T
A
= 25°C unless otherwise noted
Value
500
-65 to +200
+200
+230
Units
mW
°C
°C
°C
AXIAL LEAD
DO35
DEVICE MARKING DIAGRAM
L
ZLx
xxT
L
: Logo
Device Code
: TCZLxxxT
VZ Tolerance (T) : B =
±2%
C =
±5%
These ratings are limiting values above which the serviceability of the diode may be impaired.
Specification Features:
Zener Voltage Range 2.4 to 75 Volts
DO-35 Package (JEDEC)
Through-Hole Device Type Mounting
Hermetically Sealed Glass
Compression Bonded Construction
All external surfaces are corrosion resistant and leads are readily solderable
Cathode indicated by polarity band
Cathode
Anode
ELECTRICAL SYMBOL
Electrical Characteristics
Device Type
Min
TCZL2V4B
TCZL2V7B
TCZL3V0B
TCZL3V3B
TCZL3V6B
TCZL3V9B
TCZL4V3B
TCZL4V7B
TCZL5V1B
TCZL5V6B
TCZL6V2B
TCZL6V8B
TCZL7V5B
TCZL8V2B
TCZL9V1B
TCZL10B
TCZL11B
TCZL12B
TCZL13B
TCZL15B
TCZL16B
TCZL18B
TCZL20B
TCZL22B
TCZL24B
November 2005 / A
2.35
2.65
2.94
3.23
3.53
3.82
4.21
4.61
5.00
5.49
6.08
6.66
7.33
8.04
8.92
9.80
10.78
11.76
12.74
14.70
15.68
17.64
19.60
21.56
23.52
T
A
= 25°C unless otherwise noted
V
Z
@ I
ZT
Z
ZT
@ I
ZT
I
ZT
(Volts)
(Ω)
(mA)
Max
Nom
Max
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
2.45
2.75
3.06
3.37
3.67
3.98
4.39
4.79
5.20
5.71
6.32
6.94
7.63
8.36
9.28
10.20
11.22
12.24
13.26
15.30
16.32
18.36
20.40
22.44
24.48
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
94
94
89
89
84
84
84
75
56
37
9
14
14
14
14
18
18
23
28
28
37
42
51
51
65
I
ZK
(mA)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Z
ZK
@ I
ZK
(Ω)
Max
564
564
564
564
564
564
564
470
451
376
141
75
75
75
94
141
141
141
160
188
188
212
212
235
235
I
R
@ V
R
(µA)
Max
45
18
9
4.5
4.5
2.7
2.7
2.7
1.8
0.9
2.7
1.8
0.9
0.63
0.45
0.18
0.09
0.09
0.09
0.045
0.045
0.045
0.045
0.045
0.045
V
R
(Volts)
1
1
1
1
1
1
1
2
2
2
4
4
5
5
6
7
8
8
8
10.5
11.2
12.6
14.0
15.4
16.8
Page 1
TCZL2V4B/C through TCZL75B/C Series
®
TAK CHEONG
SEM IC O N DU C TO R
Electrical Characteristics
Device Type
Min
T
A
= 25°C unless otherwise noted
V
Z
@ I
ZT
Z
ZT
@ I
ZT
(Volts)
I
ZT
(Ω)
(mA)
Max
Nom
Max
75
75
75
84
122
141
160
169
188
202
226
240
I
ZK
(mA)
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Z
ZK
@ I
ZK
(Ω)
Max
282
282
306
329
329
353
353
376
400
423
447
470
I
R
@ V
R
(µA)
Max
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
0.045
V
R
(Volts)
18.9
21.0
23.0
25.2
27.3
30.1
33.0
35.7
39.2
43.4
47.6
52.5
TCZL27B
26.46
27
27.54
5
TCZL30B
29.40
30
30.60
5
TCZL33B
32.34
33
33.66
5
TCZL36B
35.28
36
36.72
5
TCZL39B
38.22
39
39.78
5
TCZL43B
42.14
43
43.86
5
TCZL47B
46.06
47
47.94
5
TCZL51B
49.98
51
52.02
5
TCZL56B
54.88
56
57.12
5
TCZL62B
60.76
62
63.24
5
TCZL68B
66.64
68
69.36
5
TCZL75B
73.50
75
76.50
5
V
F
Forward Voltage = 1 V Maximum @
I
F
= 100 mA for all types
Notes:
1.
2.
3.
The device numbers listed have a standard tolerance on the nominal zener voltage of
±2%.
Device tolerance of
±5%
is
indicated by a “C” instead of a “B”.
For detailed information on price, availability and delivery of nominal zener voltages between the voltages shown and tighter
voltage tolerances, contact your nearest Tak Cheong Electronics representative.
The zener impedance is derived from the 60-cycle ac voltage, which results when an ac current having an rms value equal to
10% of the dc zener current (I
ZT
or
I
ZK
) is superimposed to
I
ZT
or
I
ZK.
Electrical Symbol Definition
Symbol
V
Z
I
ZT
Z
ZT
I
ZK
Z
ZK
I
R
V
R
I
F
V
F
Parameter
Typical Characteristics
I
(mA)
Reverse Zener Voltage @
I
ZT
Reverse Current
Maximum Zener Impedance @
I
ZT
Reverse Current
Maximum Zener Impedance @
I
ZK
Reverse Leakage Current @
V
R
Breakdown Voltage
Forward Current
Forward Voltage @
I
F
(nA)
(mA)
V
Z
V
R
(V)
I
R
I
ZT
V
F
(mV)
I
F
V
Ordering Information
Device
TCZLxxxB
TCZLxxxB.TB
TCZLxxxB.TR
TCZLxxxB.T26B
TCZLxxxB
Package
Bulk
Tape and Ammo (52mm)
Tape and Reel
Tape and Ammo (26mm)
Quantity
10,000
5,000
10,000
5,000
Others (…contact Tak Cheong sales representatives)
Axial-Lead Tape Packaging Standards
This axial-lead component’s packaging requirements use in automatic testing and assembly equipment. And this standard practices for
lead-tape packaging of axial-lead components meets the requirements of EIA Standard RS-296-D “Lead-taping of Components on Axial
Lead Configuration for Automatic Insertion”.
November 2005 / A
Page 2
