HLMP-RL11-LPRDD datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> HLMP-RL11-LPRDD

HLMP-RL11-LPRDD: DescriptionSingle Color LED, Amber, Tinted, 4mm, PLASTIC PACKAGE-2; CategoryLED optoelectronic/LED photoelectric; File Size265KB，8 Pages; ManufacturerHP（Keysight）; Websitehttp://www.semiconductor.agilent.com/; Environmental Compliance

Download Datasheet Parametric View All

HLMP-RL11-LPRDD Overview

Single Color LED, Amber, Tinted, 4mm, PLASTIC PACKAGE-2

HLMP-RL11-LPRDD Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	HP（Keysight）
package instruction	PLASTIC PACKAGE-2
Reach Compliance Code	unknown
color	AMBER
color@wavelength	Amber
Configuration	SINGLE
Maximum forward current	0.05 A
Maximum forward voltage	2.4 V
Lens type	TINTED
Nominal luminous intensity	837.5 mcd
Installation features	RADIAL MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	100 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	6.3 mm
method of packing	AMMO PACK
peak wavelength	594 nm
Maximum reverse voltage	5 V
shape	OVAL
size	4 mm
surface mount	NO
Terminal pitch	2.54 mm
perspective	60 deg

HLMP-RL11-LPRDD Preview

4 mm Oval Precision Optical

Performance LED Lamps

Data Sheet

Features

• Well defined spatial radiation

pattern

• Viewing angle:

major axis 120°

minor axis 60°

• High luminous output

• Two red and amber intensity

levels

AlInGaP (bright) and

AlInGaP II (brightest)

• Colors

626/630 nm red

590/592 nm amber

526 nm green

470 nm blue

• Superior resistance to moisture

• UV resistant epoxy

Benefits

• Viewing angle designed for wide

field of view applications

• Superior performance for outdoor

environments

• Radiation pattern matched for red,

green, and blue for full color sign

Applications

• Full color signs

SunPower Series

Agilent HLMP-RG10, HLMP-SG10, HLMP-RL10, HLMP-SL10,

HLMP-RD11, HLMP-SD11, HLMP-RL11, HLMP-SL11,

HLMP-RM11, HLMP-SM11, HLMP-RB11, HLMP-SB11

Description

These Precision Optical Perfor-

mance Oval LEDs are specifically

designed for Full Color/Video and

Passenger Information signs. The

oval shaped radiation pattern

(60° x 120°) and high luminous

intensity ensure that these de-

vices are excellent for wide field

of view outdoor applications

where a wide viewing angle and

readability in sunlight are essen-

tial. These lamps have very

smooth, matched radiation pat-

terns ensuring consistent color

mixing in full color applications,

message uniformity across the

viewing angle of the sign.

High efficiency LED materials are

used in these lamps: Aluminum

Indium Gallium Phosphide

(AlInGaP) for Red and Amber

color and Indium Gallium Nitride

(InGaN) for Blue and Green.

There are two families of red and

amber lamps, AlInGaP and the

higher performance AlInGaP II.

Each lamp is made with an

advanced optical grade epoxy

offering superior high tempera-

ture and high moisture resistance

in outdoor applications. The

package epoxy contains both uv-a

and uv-b inhibitors to reduce the

effects of long term exposure to

direct sunlight.

Designers can select parallel

(where the axis of the leads is

parallel to the wide axis of the

oval radiation pattern) or perpen-

dicular orientation. Both lamps

are available in tinted version.

CAUTION:

The Blue and Green LEDs are Class 1 ESD sensitive. Please observe appropriate precautions during

handling and processing. Refer to Agilent Technologies Application Note AN-1142 for additional details.

Package Dimensions

21.0 MIN.

(0.827)

9.50 ± 0.50

(0.374 ± 0.007)

∅

4.0 ± 0.20

(0.157 ± 0.008)

6.30 ± 0.20

(0.248 ± 0.008)

1.0 MIN.

(0.039)

1.25 ± 0.20

(0.049 ± 0.008)

CATHODE

LEAD

2.54 ± 0.30

(0.100 ± 0.012)

0.80 MAX. EPOXY MENISCUS

(0.016)

+0.10

0.40 –0

+0.004

(0.016 –0.000)

0.44 ± 0.20

(0.017 ± 0.008)

+0.10

0.45 –0.04

+0.004

(0.018 –0.002)

21.0 MIN.

(0.827)

9.50 ± 0.50

(0.374 ± 0.007)

∅

4.0 ± 0.20

(0.157 ± 0.008)

6.30 ± 0.20

(0.248 ± 0.008)

1.0 MIN.

(0.039)

1.25 ± 0.20

(0.049 ± 0.008)

CATHODE

LEAD

2.54 ± 0.30

(0.100 ± 0.012)

0.80 MAX. EPOXY MENISCUS

(0.016)

+0.10

0.40 –0

+0.004

(0.016 –0.000)

0.44 ± 0.20

(0.017 ± 0.008)

+0.10

0.45 –0.04

+0.004

(0.018 –0.002)

DIMENSIONS ARE IN MILLIMETERS (INCHES).

Device Selection Guide for AlInGaP

Color and

Dominant

Wavelength

(nm) Typ.

Red 626

Amber 590

Luminous

Intensity

(mcd) at 20 mA

Min.

Max.

120

205

155

460

780

360

600

Part Number

HLMP-SG10-GK000

HLMP-RG10-GK000

HLMP-SG10-JM000

HLMP-RG10-JM000

HLMP-SL10-FJ000

HLMP-RL10-FJ000

HLMP-SL10-HL000

HLMP-RL10-HL000

Leads with

Stand-Offs

Yes

Leadframe

Orientation

Perpendicular

Parallel

Perpendicular

Parallel

Perpendicular

Parallel

Perpendicular

Parallel

Package

Drawing

Notes:

1. The luminous intensity is measured on the mechanical axis of the lamp package.

2. The optical axis is closely aligned with the package mechanical axis.

3. The dominant wavelength,

, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.

Device Selection Guide for AlInGaP II

Color and

Dominant

Wavelength

(nm) Typ.

Red 630

Amber 592

Luminous

Intensity

(mcd) at 20 mA

Min.

Max.

345

450

155

345

1330

1010

600

1330

Part Number

HLMP-SD11-LP000

HLMP-RD11-LP000

HLMP-SD11-LPT00

HLMP-RD11-LPT00

HLMP-SD11-MNT00

HLMP-SL11-HLR00

HLMP-SL11-LP000

HLMP-RL11-LP000

HLMP-SL11-LPR00

HLMP-RL11-LPR00

HLMP-SL11-LPV00

HLMP-RL11-LPV00

Leads with

Stand-Offs

Yes

Leadframe

Orientation

Perpendicular

Parallel

Perpendicular

Parallel

Perpendicular

Parallel

Perpendicular

Parallel

Perpendicular

Parallel

Package

Drawing

Notes:

1. The luminous intensity is measured on the mechanical axis of the lamp package.

2. The optical axis is closely aligned with the package mechanical axis.

3. The dominant wavelength,

, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.

Device Selection Guide for InGaN

Color and

Dominant

Wavelength

(nm) Typ.

Green 526

Blue 470

Luminous

Intensity

(mcd) at 20 mA

Min.

Max.

345

1330

270

Part Number

HLMP-SM11-LP000

HLMP-RM11-LP000

HLMP-SB11-EH000

HLMP-RB11-LP000

Leads with

Stand-Offs

Yes

Leadframe

Orientation

Perpendicular

Parallel

Perpendicular

Parallel

Package

Drawing

Notes:

4. The luminous intensity is measured on the mechanical axis of the lamp package.

5. The optical axis is closely aligned with the package mechanical axis.

6. The dominant wavelength,

, is derived from the CIE Chromaticity Diagram and represents the color of the lamp.

Part Numbering System

HLMP - x x xx - x x x xx

Mechanical Options

00: Bulk Packaging

DD: Ammo Pack

YY: Flexi-Bin; Bulk Packaging

ZZ: Flexi-Bin; Ammo Pack

Color Bin & V

Selections

0: No Color Bin Limitation

[1]

R: Amber Color Bins 1, 2, 4, 6, and 7 with V

Maximum of 2.6 V

T: Red Color with V

Maximum of 2.6 V

V: Amber Color Bins 1, 2, 4, and 6 with V

Maximum of 2.6 V

Maximum Intensity Bin

0: No Iv Bin Limitation

Minimum Intensity Bin

Refer to Device Selection Guide

Color

B: 470 nm Blue

D: 630 nm Red

G: 626 nm Red

L: 590/592 nm Amber

M: 526 nm Green

Package

R: 4 mm 60º x 120º Oval, Parallel

S: 4 mm 60º x 120º Oval, Perpendicular

Note:

1. For Amber color, ’0‘ includes color bins 1, 2, 4, and 6 only.

Absolute Maximum Ratings

= 25°C

Parameter

DC Forward Current

[1]

Peak Pulsed Forward Current

Average Forward Current

Reverse Voltage (I

= 100

µA)

Power Dissipation

LED Junction Temperature

Operating Temperature Range

Storage Temperature Range

Soldering Temperature

Note:

1. Derate linearly as shown in Figures 6 and 7.

Blue and Green

30 mA

100 mA

30 mA

120 mW

100°C

–40°C to +80°C

–40°C to +100°C

260° for 5 sec

Amber and Red

50 mA

100 mA

30 mA

120 mW

130°C

–40°C to +100°C

–40°C to +120°C

260° for 5 sec

Electrical/Optical Characteristics

= 25°C

Parameter

Typical Viewing Angle

[1]

Major

Minor

Forward Voltage

Red (λ

= 626 nm)

Red (λ

= 630 nm)

Amber (λ

= 590 nm)

Amber (λ

= 592 nm)

Blue (λ

= 470 nm)

Green (λ

= 526 nm)

Reverse Voltage

Amber and Red

Blue and Green

Peak Wavelength

Red (λ

= 626 nm)

Red (λ

= 630 nm)

Amber (λ

= 590 nm)

Amber (λ

= 592 nm)

Symbol

2θ

1/2

Min.

Typ.

120

1.9

2.0

2.02

2.15

3.5

PEAK

635

639

592

594

–

Peak of Wavelength of

Spectral Distribution

at I

= 20 mA

2.4

[2]

2.4

[2]

4.0

= 100

µA

= 20 mA

Max.

Units

deg

Test Conditions

LED Indicators

Parameter

Blue (λ

= 470 nm)

Green (λ

= 526 nm)

Spectral Halfwidth

Red (λ

= 626/630 nm)

Amber (λ

= 590/592 nm)

Blue (λ

= 470 nm)

Green (λ

= 526 nm)

Capacitance

All Colors

Thermal Resistance

All Colors

Luminous Efficacy

[3]

Red (λ

= 626 nm)

Red (λ

= 630 nm)

Amber (λ

= 590 nm)

Amber (λ

= 592 nm)

Blue (λ

= 470 nm)

Green (λ

= 526 nm)

Symbol

Min.

Typ.

467

524

Max.

Units

Test Conditions

∆λ

1/2

Wavelength Width at

Spectral Distribution

Power Point at I = 20 mA

Rθ

J-PIN

240

150

155

480

500

540

°C/W

lm/W

= 0, F = 1 MHz

LED Junction-to-Cathode

Lead

Emitted Luminous Power/

Emitted Radiant Power

Notes:

1. 2θ

1/2

is the off-axis angle where the luminous intensity is the on-axis intensity.

2. For options -xxRxx, -xxTxx, and -xxVxx, maximum forward voltage, V

, is 2.6 V.

3. The radiant intensity, I

, in watts per steradian, may be found from the equation I

= I

/η

, where I

is the luminous intensity in candelas and

the luminous efficacy in lumens/watt.

More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >
