10 Watts
MCPLG Series
Features:
•
•
•
•
•
•
Energy efficiency level V.
CEC 2008 and EISA 2007 compliant.
Output voltages from 5 to 24V dc.
No load input power < 0.3 W.
Compact dimensions.
UK and EU plug versions.
Specifications:
Input:
Input voltage
Input frequency
Maximum inrush current
Earth leakage current
Harmonic currents
Output:
Minimum load
Hold up time
Total regulation
Maximum ripple and noise
Short circuit protection
General:
Efficiency
Isolation
Energy efficiency
Environmental:
Operating temperature
Storage temperature
: 0°C to +40°C, no derating.
: -40°C to +85°C.
: 76% typical.
: 3000V ac input to output.
: Level V.
: No minimum load requirement.
: 5ms minimum.
: 5% maximum.
: 1% pk-pk, 20MHz BW.
: Trip and restart (hiccup mode).
:
:
:
:
:
90-264V ac.
47-63 Hz.
40 / 80A at 115 / 230V ac.
0.2mA typical at 240V ac, full load.
Meets EN61000-3-2, class A.
http://www.farnell.com
http://www.newark.com
http://www.element14.com
Page <1>
15/04/11 V1.1
10 Watts
MCPLG Series
Models and Ratings
Maximum Output
Power
Output Voltage
(V dc)
5
8W
6
7.5
9
10W
12
24
Notes:
All models meet Energy Star Level V.
Output Current
(A)
1.6
1.33
1.14
1.11
0.83
0.42
Model Number
UK
MCPLG5V10WUK
MCPLG6V10WUK
MCPLG7V10WUK
MCPLG9V10WUK
MCPLG12V10WUK
MCPLG24V10WUK
EU
MCPLG5V10WEU
MCPLG6V10WEU
MCPLG7V10WEU
MCPLG9V10WEU
MCPLG12V10WEU
MCPLG24V10WEU
Mechanical Details
EU Plug
UK Plug
Dimensions : Inches (Millimetres)
Notes :
Tolerance : ±0.04 (±1), except output cable length is +4, -0 (+100, -0).
Important Notice :
This data sheet and its contents (the "Information") belong to the members of the Premier Farnell group of companies (the "Group") or are licensed to it. No licence is granted for the use of
it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces
all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any error in or omission from it or for any use
made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted.
Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising)
is excluded. This will not operate to limit or restrict the Group's liability for death or personal injury resulting from its negligence. Multicomp is the registered trademark of the Group. © Premier Farnell plc 2011.
http://www.farnell.com
http://www.newark.com
http://www.element14.com
Page <2>
15/04/11 V1.1
