Relay
Contact Data
Contact form
Contact material
Contact rating
Maximum switching voltage
Maximum switching current
Maximum switching power
Minimum switching load
Maximum contact resistance
Life
Electrical
Mechanical
General Data
Minimum insulation resistance
Dielectric strength
Operate time
Release time
Operate temperature
Shock Resistance
Endurance
Misoperation
Vibration Resistance
Endurance
Misoperation
Humidity
: 10 to 55Hz, 1.5mm double amplitude.
: 10 to 55Hz, 1.5mm double amplitude.
: 35% to 95%RH, +40°C.
: 1000m/s
2
.
: 100m/s
2
.
: 1000MΩ 500V dc.
: 1500V ac, 1 min between open contacts
2500V ac, 1 min between coil and contacts.
: Maximum 15ms.
: Maximum 10ms.
: -30 to +85°C.
: 100,000 operations.
: 10,000,000 operations.
: 1 form A.
: Ag Alloy.
: 30A 250V ac/24V dc.
: 250V ac/24V dc.
: 30A.
: 7500VA, 720W.
: 5V dc, 100mA.
: 100mΩ (6V dc 1A).
Coil Data Chart
Nominal
Voltage
V dc
12
24
20°C
Operate
Voltage
≤
V dc
8.4
16.8
Release
Voltage
≥
V dc
1.2
900
640
2.4
Coil
Power
mW
Enclosure
Contact Form
Part Number
MC25154
1 form A
MC25155
Coil
Resistance
Ω
±10%
160
Plastic Sealed
Type
Page <1>
29/04/11 V1.1
Relay
Characteristic Chart Data
Maximum Switching Power
Life Curves
Important Notice :
This data sheet and its contents (the "Information") belong to the members of the Premier Farnell group of companies (the "Group") or are licensed to it. No licence is granted for the use of
it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces
all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any error in or omission from it or for any use
made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted.
Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising)
is excluded. This will not operate to limit or restrict the Group's liability for death or personal injury resulting from its negligence. Multicomp is the registered trademark of the Group. © Premier Farnell plc 2011.
Page <3>
29/04/11 V1.1
