CS80C86-2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> CS80C86-2

CS80C86-2: Description16-BIT, 8MHz, MICROPROCESSOR, PQCC44; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，36 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

CS80C86-2 Overview

16-BIT, 8MHz, MICROPROCESSOR, PQCC44

CS80C86-2 Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
Parts packaging code	QFN
Contacts	44
Reach Compliance Code	unknown
Address bus width	20
bit size	16
boundary scan	NO
maximum clock frequency	8 MHz
External data bus width	16
Format	FIXED POINT
Integrated cache	NO
JESD-30 code	S-PQCC-J44
low power mode	YES
Number of terminals	44
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
Package shape	SQUARE
Package form	CHIP CARRIER
Certification status	COMMERCIAL
speed	8 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	J BEND
Terminal location	QUAD
uPs/uCs/peripheral integrated circuit type	MICROPROCESSOR
