SLCFxxxJ(T2)(I)
128 MB to 8 GB CompactFlash Cards
GENERAL DESCRIPTION
The SimpleTech SLCFxxxJ(T2)(I) are CompactFlash Cards
with 128MB to 8GB of nonvolatile storage. The SLCFxxxJ(I)
cards are Type I CompactFlash Cards, and the SLCFxxxJT2(I)
cards are Type II CompactFlash Cards. The cards use a flash
memory controller that provides a fully compatible
CompactFlash interface for the flash memory.
SimpleTech OEM CompactFlash cards are the product of
choice in applications requiring high reliability and high
tolerance to shock, vibration, humidity, altitude, and
temperature. Because there are no moving parts to service or
maintain, CompactFlash cards are reliable alternatives to
mechanical hard disk drives for high availability and mission
critical applications.
While the inherent ruggedness and reliability of solid state
storage relative to rotating hard drives is intuitive, new
applications for OEM CompactFlash cards are emerging due
to the low cost per usable megabyte. Most applications using
embedded operating systems such as VxWorks™, Windows
XP/embedded™, and Linux™ don’t have multi-gigabyte
data storage requirements, and therefore a cost savings can
be realized when using this robust media.
FEATURES
• CFA 2.0 and ATA-4 Compatibility
• Support for PCMCIA I/O, Memory and True-IDE
Interfaces
• 128MB to 8GB Capacities
• Form Factors: CompactFlash Type I (SLCFxxxJ(I)) and
CompactFlash Type II (SLCFxxxJT2(I))
• Endurance Guarantee of 2,000,000 Write/Erase Cycles
• CIS (Card Information Structure) Programmed into 256
Bytes of Internal Memory
• Compatible with PC Card and Socket Services
(Release 2.1 or later)
• 5V or 3.3V Power Supply
• Completely Solid-State (No Moving Parts)
• Available in Commercial and Industrial Operating
Temperature Ranges
• Standard ECC Engine
• 7 Year Warranty
ORDERING INFORMATION
CompactFlash
Part Number*
CF Form Factor
Capacity
• SLCF128J(I) ........................ Type I ....................... 128 MBytes
• SLCF256J(I) ........................ Type I ....................... 256 MBytes
• SLCF512J(I) ........................ Type I ....................... 512 MBytes
•
•
•
•
•
•
•
•
SLCF1GBJ(I) ....................... Type I ........................... 1 GBytes
SLCF2GBJ(I) ....................... Type I ........................... 2 GBytes
SLCF3GBJ(I) ....................... Type I ........................... 3 GBytes
SLCF4GBJ(I) ....................... Type I ........................... 4 GBytes
SLCF5GBJ(I) ....................... Type I ........................... 5 GBytes
SLCF6GBJT2(I) ................. Type II .......................... 6 GBytes
SLCF7GBJT2(I) ................. Type II .......................... 7 GBytes
SLCF8GBJT2(I) ................. Type II ........................ 8 GBytesII
Adapters
Part Number
CF Form Factor
PC Card Form Factor
• SLCFAD ................... Type I .......................................... Type II
• SLCFADII ...... Type I or Type II ................................... Type
* Custom capacities available.
An “I” suffix added to the part number selects the
Industrial Operating Temperature range option. A part
number without the “I” suffix selects the Commercial
Operating Temperature range option.
An “-F” suffix, that is SLCFxxxJ(T2)(I)-F, provides the
media set to fixed storage for non-removable IDE
applications. Some operating systems, such as Windows
XP, require the storage media to be identified as a fixed
drive before the storage media can be used as a bootable
drive. SimpleTech offers the “-F” cards for these
applications.
Web:
www.simpletech.com
Document Part Number 61000-02805-111 March 2005
Page 1
SLCFxxxJ(T2)(I)
PACKAGE DIMENSIONS AND PIN LOCATIONS
CompactFlash Type I
COMPACTFLASH
Length .......................................... 1.433±.006 in (36.4±0.15 mm)
Width .......................................... 1.685±.004 in (42.80±0.10 mm)
Thickness (Type I) ........................... .130±.004 in (3.3±0.10 mm)
(including Label Area)
26
.063±.002
1
.040±.003
.130±.004
50
.039±.002
25
.040±.003
2X .472±.004
2X 1.015±.003
TOP
1.433±.006
.030±.003
1.640±.005
1.685±.004
.025±.003
2X .118±.003
.096±.003
(continued)
Document Part Number 61000-02805-111 March 2005
Page 2
SLCFxxxJ(T2)(I)
PACKAGE DIMENSIONS AND PIN LOCATIONS
CompactFlash Type II
COMPACTFLASH
(continued)
Length .......................................... 1.433±.006 in (36.4±0.15 mm)
Width .......................................... 1.685±.004 in (42.80±0.10 mm)
Thickness (Type II) ................................. .197 in (5.00 mm) max
(including Label Area)
26
.063±.002
1
.040±.003
.197 MAX
50
.039±.002
25
.040±.003
2X 1.015±.003
TOP
1.640±.005
1.685±.004
1.433±.006
(continued)
Document Part Number 61000-02805-111 March 2005
Page 3
SLCFxxxJ(T2)(I)
PACKAGE DIMENSIONS AND PIN LOCATIONS
COMPACTFLASH
(continued)
Adapter for CompactFlash Type I and II to PC Card Type II (Typical)
Length .................. 3.370±.008 in (85.6±0.20 mm)
Width .................... 2.126±.004 in (54.0±0.10 mm)
Thickness ............ .1968 in max. (5.0 mm max.)
.196
.130
2.126
Length of CF
1.433
1.738
.138
Document Part Number 61000-02805-111 March 2005
3.370
Page 4
SLCFxxxJ(T2)(I)
PIN ASSIGNMENTS
PC Card Memory Mode
Pin
Num
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Signal
Name
GND
D03
D04
D05
D06
D07
-CE1
A10
-OE
A09
A08
A07
VCC
A06
A05
A04
A03
A02
A01
A00
D00
D01
D02
WP
-CD2
-CD1
D11
D12
D13
D14
D15
-CE2
-VS1
-IORD
-IOWR
-WE
RDY/-BSY
VCC
-CSEL
-VS2
RESET
-WAIT
-INPACK
-REG
BVD2
BVD1
D08
D09
D10
GND
Pin
Type
Ground
I/O
I/O
I/O
I/O
I/O
I
I
I
I
I
I
Power
I
I
I
I
I
I
I
I/O
I/O
I/O
O
O
O
I/O
I/O
I/O
I/O
I/O
I
O
I
I
I
O
Power
I
O
I
O
O
I
I/O
I/O
I/O
I/O
I/O
Ground
PC Card I/O Mode
Pin
Num
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Signal
Name
GND
D03
D04
D05
D06
D07
-CE1
A10
-OE
A09
A08
A07
VCC
A06
A05
A04
A03
A02
A01
A00
D00
D01
D02
-IOIS16
-CD2
-CD1
D11
D12
D13
D14
D15
-CE2
-VS1
-IORD
-IOWR
-WE
IREQ
VCC
-CSEL
-VS2
RESET
-WAIT
-INPACK
-REG
-SPKR
-STSCHG
D08
D09
D10
GND
Pin
Type
Ground
I/O
I/O
I/O
I/O
I/O
I
I
I
I
I
I
Power
I
I
I
I
I
I
I
I/O
I/O
I/O
O
O
O
I/O
I/O
I/O
I/O
I/O
I
O
I
I
I
O
Power
I
O
I
O
O
I
I/O
I/O
I/O
I/O
I/O
Ground
COMPACTFLASH
True IDE Mode
Pin
Num
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Signal
Name
GND
D03
D04
D05
D06
D07
-CS0
A10
-SELATA
A09*
A08*
A07*
VCC
A06*
A05*
A04*
A03*
A02
A01
A00
D00
D01
D02
-IOCS16*
-CD2
-CD1
D11
D12
D13
D14
D15
-CS1
-VS1*
-IORD
-IOWR
-WE
INTRQ
VCC
-CSEL
-VS2*
-RESET
IORDY
Not Used
Not Used
-DASP
-PDIAG
D08
D09
D10
GND
Pin
Type
Ground
I/O
I/O
I/O
I/O
I/O
I
I
I
I
I
I
Power
I
I
I
I
I
I
I
I/O
I/O
I/O
O
O
O
I/O
I/O
I/O
I/O
I/O
I
O
I
I
I
O
Power
I
O
I
O
O
I
I/O
I/O
I/O
I/O
I/O
Ground
* Signals marked with an asterisk are not used in IDE Mode.
