Single Row Terminal Blocks
Kulka
®
599/799 GP Series
300 Volts AC/DC (Class B)
599 Series only
150 Volts AC/DC (Class C)
599 and 799 Series
599 GP 06 PSB
Specifications:
•
Base, Phenolic, 150
o
C (UL RTI)
•
Open Back Design (Insulator Strip Required
for Voltage Rating - see page 112)
•
JJ (GDI-30F) Material Available
•
Screws, #5-40 Binder Head, Phil-Slot, Brass
•
Terminals, Plated Brass
•
1-30 Poles
•
3/8” Centers
Kulka
®
Catalog #
599 GP 01 PSB
599 GP 02 PSB
599 GP 03 PSB
599 GP 04 PSB
599 GP 05 PSB
599 GP 06 PSB
599 GP 07 PSB
599 GP 08 PSB
599 GP 09 PSB
599 GP 10 PSB
599 GP 11 PSB
599 GP 12 PSB
599 GP 13 PSB
599 GP 14 PSB
599 GP 15 PSB
599 GP 16 PSB
599 GP 17 PSB
599 GP 18 PSB
599 GP 19 PSB
599 GP 20 PSB
599 GP 21 PSB
599 GP 22 PSB
599 GP 23 PSB
599 GP 24 PSB
599 GP 25 PSB
599 GP 26 PSB
599 GP 27 PSB
599 GP 28 PSB
599 GP 29 PSB
599 GP 30 PSB
mm = dim X 25.4
For electronic drawings or 2D/3D CAD data, submit
request at www.marathonsp.com/drawings.html
Ø .17
[4.2]
Single Row Terminal Blocks
•
Wire Range With Wire Binding Screw
#16 - #22 AWG – 15 Amps
•
799 Series (Riveted KTs) - shown at right,
see page 104 for KTs
•
UL Recognized File No. XCFR2.E47811
•
CSA Certified File No. LR19766
•
•
RoHS Compliant
799 Series
Dimensions
# of poles
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
A
1.03
1.41
1.78
2.16
2.53
2.91
3.28
3.66
4.03
4.41
4.78
5.16
5.53
5.91
6.28
6.66
7.03
7.41
7.78
8.16
8.53
8.91
9.28
9.66
10.03
10.41
10.78
11.16
11.53
11.91
B
0.75
1.12
1.50
1.88
2.25
2.63
3.00
3.38
3.75
4.13
4.50
4.88
5.25
5.63
6.00
6.38
6.75
7.13
7.50
7.88
8.25
8.63
9.00
9.38
9.75
10.13
10.50
10.88
11.25
11.63
Hardware Options:
(Hardware options may affect ratings - consult Customer Service)
CATALOG #
MSP
KULKA
KT28
KT29
KT30
KT34
KT35
KT36
3/4 ST
Z
J 600
600 RJ(S)
2002
2004
2020
2021
PRODUCT
DESCRIPTION
Full Quick Connect (0
o
Flat)
Full Quick Connect (45
o
Bend)
Full Quick Connect (90
o
Bend)
Half Quick Connect (0
o
Flat)
Half Quick Connect (45
o
Bend)
Half Quick Connect (90
o
Bend)
Half Solder
Lug over the Side (.312)
Line to Line Jumper
Multiple Position Jumper
Stud
Feed Thru Solder
Solder Pin
Solder Pin (Slotted Screw)
PAGE
REFERENCE
See page 104
See page 104
See page 104
See page 104
See page 104
See page 104
See page 106
Consult C/S
See page 107
See page 107
See page 109
See page 109
See page 109
See page 109
Quick Connects: .020” x .187”
See pages 104-115 for terminal block accessories
.41
[10.4]
"A"
"B"
.30
[7.6]
.14
[3.6]
.56
[14.3]
.38
[9.5]
.31
[7.9]
.25
[6.3]
.16
[4.0]
#5-40 x .25 [6.3]
BD HD SCREW
.22
[5.5]
96
Datasheets available at marathonsp.com
