Ordering number:EN1057B
PNP/NPN Epitaxial Planar Silicon Transistors
2SA1257/2SC3143
High-Voltage Switching, AF Power Amp,
100W Output Predriver Applications
Features
· Very small-sized package permitting the 2SA1257/
2SC3143-applied sets to be made small and slim.
· High breakdown voltage (V
CEO
≥160V).
· Small output capacitance.
Switching Time Test Circuit
Package Dimensions
unit:mm
2018A
[2SA1257/2SC3143]
( ) : 2SA1257
Specifications
Parameter
Collector-to-Base Voltage
Collector-to-Emitter Voltage
Emitter-to-Base Voltage
Collector Current
Collector Current Pulse
Collector Dissipation
Junction Temperature
Storage Temperature
I
C
=10I
B1
=–10I
B2
=10mA
(For PNP, the polarity is reversed)
Unit (resistance :
Ω,
capacitance : F)
C : Collector
B : Base
E : Emitter
SANYO : CP
Absolute Maximum Ratings
at Ta = 25˚C
Symbol
VCBO
VCEO
VEBO
IC
ICP
PC
Tj
Tstg
Conditions
Ratings
(–)180
(–)160
(–)5
(–)80
(–)150
200
125
–55 to +125
Unit
V
V
V
mA
mA
mW
˚C
˚C
Electrical Characteristics
at Ta = 25˚C
Parameter
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
Gain-Bandwidth Product
Output Capacitance
Base-to-Emitter Voltage
Collector-to-Emitter Saturation Voltage
Collector-to-Base Breakdown Voltage
Collector-to-Emitter Breakdown Voltage
Emitter-to-Base Breakdown Voltage
Turn-ON Time
Storage Time
Fall Time
Symbol
ICBO
IEBO
hFE
fT
Cob
VBE
VCB=(–)120V, IE=0
VEB=(–)4V, IC=0
VCE=(–)5V, IC=(–)10mA
VCE=(–)10V, IC=(–)10mA
VCB=(–)10V, f=1MHz
VCE=(–)5V, IC=(–)10mA
(–)180
(–)160
(–)5
(0.15)
0.18
(0.95)
1.00
(0.15)
0.20
60*
(130)
150
(2.4)
2.0
Conditions
Ratings
min
typ
max
(–)0.1
(–)0.1
270*
MHz
(3.2)
2.8
(–)1.5
(–)0.7
pF
V
V
V
V
V
µs
µs
µs
Unit
µA
µA
VCE(sat) IC=(–)30mA, IB=(–)3mA
V(BR)CBO IC=(–)10µA, IE=0
V(BR)CEO IC=(–)1mA, RBE=∞
V(BR)EBO
ton
tstg
tf
IE=(–)10µA, IC=0
See specified Test Circuit
See specified Test Circuit
See specified Test Circuit
* : The 2SA1257/2SC3143 are classified by 10mA h
FE
as follows :
60
G3
120
90
G4
180
135
G5
270
Marking 2SA1257 : G, 2SC3143 : K, h
FE
rank : 3, 4, 5
SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquaters
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
71598HA (KT)/7148MO/3187AT/D103KI, MT No.1057-1/4
2SA1257/2SC3143
