Not for New Design
TSOP12..
www.vishay.com
Vishay Semiconductors
IR Receiver Modules for Remote Control Systems
FEATURES
• Very low supply current
• Photo detector and preamplifier in one
package
• Internal filter for PCM frequency
• Improved shielding against EMI
• Supply voltage: 2.5 V to 5.5 V
• Improved immunity against ambient light
1
2
3
94 8691
• Insensitive to supply voltage ripple and noise
• Compliant to RoHS Directive 2011/65/EU and in
accordance to WEEE 2002/96/EC
Note
**
Please see document “Vishay Material Category Policy”:
www.vishay.com/doc?99902
MECHANICAL DATA
Pinning:
1 = GND, 2 = V
S
, 3 = OUT
DESCRIPTION
The TSOP12.. series are miniaturized receivers for infrared
remote control systems. A PIN diode and a preamplifier are
assembled on a lead frame, the epoxy package acts as an
IR filter.
The demodulated output signal can be directly decoded by
a microprocessor. The TSOP12.. is compatible with all
common IR remote control data formats.
This component has not been qualified according to
automotive specifications.
PARTS TABLE
CARRIER FREQUENCY
30 kHz
33 kHz
36 kHz
36.7 kHz
38 kHz
40 kHz
56 kHz
STANDARD APPLICATION (AGC2/AGC8)
TSOP1230
TSOP1233
TSOP1236
TSOP1237
TSOP1238
TSOP1240
TSOP1256
BLOCK DIAGRAM
16832
APPLICATION CIRCUIT
17170_5
2
30 kΩ
V
S
3
Input
AGC
Band
pass
Demo-
dulator
OUT
R
1
IR receiver
V
S
+ V
S
C
1
OUT
GND
V
O
µC
GND
Transmitter
with
TSALxxxx
1
PIN
Control circuit
GND
R
1
and C
1
are recommended for protection against EOS.
Components should be in the range of 33
Ω
< R
1
< 1 kΩ,
C
1
> 0.1 µF.
Rev. 2.5, 21-Feb-12
Circuit
1
Document Number: 82013
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Not for New Design
TSOP12..
www.vishay.com
Vishay Semiconductors
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Supply voltage (pin 2)
Supply current (pin 2)
Output voltage (pin 3)
Output current (pin 3)
Junction temperature
Storage temperature range
Operating temperature range
Power consumption
Soldering temperature
T
amb
85 °C
t
10 s, 1 mm from case
TEST CONDITION
SYMBOL
V
S
I
S
V
O
I
O
T
j
T
stg
T
amb
P
tot
T
sd
VALUE
- 0.3 to + 6
3
- 0.3 to (V
S
+ 0.3)
5
100
- 25 to + 85
- 25 to + 85
10
260
UNIT
V
mA
V
mA
°C
°C
°C
mW
°C
Note
• Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating only
and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this specification
is not implied. Exposure to absolute maximum rating conditions for extended periods may affect the device reliability.
ELECTRICAL AND OPTICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
PARAMETER
Supply voltage
Supply current (pin 2)
Transmission distance
Output voltage low (pin 3)
Minimum irradiance
Maximum irradiance
Directivity
E
v
= 0, V
S
= 3.3 V
E
v
= 40 klx, sunlight
E
v
= 0, test signal see fig. 1,
IR diode TSAL6200,
I
F
= 250 mA
I
OSL
= 0.5 mA, E
e
= 0.7 mW/m
2
,
test signal see fig. 1
Pulse width tolerance:
t
pi
- 5/f
0
< t
po
< t
pi
+ 6/f
0
,
test signal see fig. 1
t
pi
- 5/f
0
< t
po
< t
pi
+ 6/f
0
,
test signal see fig. 1
Angle of half transmission
distance
TEST CONDITION
SYMBOL
V
S
I
SD
I
SH
d
V
OSL
E
e min.
E
e max.
1/2
30
± 45
0.15
MIN.
2.5
0.27
0.35
0.45
45
100
0.35
TYP.
MAX.
5.5
0.45
UNIT
V
mA
mA
m
mV
mW/m
2
W/m
2
deg
TYPICAL CHARACTERISTICS
(T
amb
= 25 °C, unless otherwise specified)
1.0
0.9
Output Pulse Width
E
e
Optical Test Signal
(IR diode TSAL6200, I
F
= 0.4 A, 30 pulses, f = f
0
, t = 10 ms)
t
po
- Output Pulse Width (ms)
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
0.1
1
10
10
2
10
3
10
4
10
5
λ
= 950 nm,
Optical Test Signal, Fig.1
Input Burst Length
t
t
pi
*
* t
pi
V
O
V
OH
V
OL
t
d
1)
t
po
T
10/f
0
is recommended for optimal function
16110
Output Signal
1)
2)
7/f
0
<
t
d
<
15/f
0
t
pi
- 5/f
0
<
t
po
<
t
pi
+ 6/f
0
2)
t
20752
E
e
- Irradiance (mW/m
2
)
Fig. 1 - Output Active Low
Fig. 2 - Pulse Length and Sensitivity in Dark Ambient
Rev. 2.5, 21-Feb-12
2
Document Number: 82013
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Not for New Design
TSOP12..
www.vishay.com
Vishay Semiconductors
E
e min.
- Threshold Irradiance (mW/m
2
)
E
e
Optical Test Signal
4
Correlation with Ambient Light Sources:
2
3.5 10 W/m = 1.4 kLx (Std. illum. A, T = 2855 K)
10 W/m
2
= 8.2 kLx (Daylight, T = 5900 K)
3
2.5
2
1.5
1
0.5
0
0.01
Wavelength of Ambient
Illumination:
λ
= 950 nm
600 µs
t = 60 ms
Output Signal,
(see fig. 4)
600 µs
t
94 8134
V
O
V
OH
V
OL
t
on
t
off
t
20757
0.1
1
10
100
E
e
- Ambient DC Irradiance
(W/m
2
)
Fig. 3 - Output Function
Fig. 6 - Sensitivity in Bright Ambient
E
e min.
- Threshold Irradiance (mW/m
2
)
0.8
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
1
10
100
1000
f = 30 kHz
f = f
o
f = 20 kHz
f = 10 kHz
f = 100 Hz
T
on
, T
off
- Output Pulse Width (ms)
0.7
0.6
0.5
T
on
T
off
0.4
0.3
0.2
0.1
0
0.1
λ
= 950 nm,
Optical Test Signal, Fig. 3
1
10
100
1000
10 000
20759
E
e
- Irradiance (mW/m
2
)
20753
Vs
RMS
- AC Voltage on DC Supply Voltage (mV)
Fig. 4 - Output Pulse Diagram
Fig. 7 - Sensitivity vs. Supply Voltage Disturbances
1.2
1.0
0.8
0.6
0.4
0.2
0.0
0.7
16925
500
E
e min.
/E
e
- Rel. Responsivity
E - Max. Field Strength (V/m)
450
400
350
300
250
200
150
100
50
0
0
500
1000
1500
2000
2500
3000
f = f
0
± 5 %
Δ
f(3 dB) = f
0
/10
0.9
1.1
1.3
20747
f/f
0
- Relative Frequency
f - EMI Frequency (MHz)
Fig. 5 - Frequency Dependence of Responsivity
Fig. 8 - Sensitivity vs. Electric Field Disturbances
Rev. 2.5, 21-Feb-12
3
Document Number: 82013
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Not for New Design
TSOP12..
www.vishay.com
Vishay Semiconductors
0
°
10
°
20
°
1
0.9
30
°
Max. Envelope Duty Cycle
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
0
0
f = 38 kHz, E
e
= 2 mW/m²
20
40
60
80
100
120
0.6
95 11340p2
40
°
1.0
0.9
TSOP12..
0.8
50
°
60
°
70
°
80
°
0.6
0.7
0.4
0.2
0
0.2
0.4
20773-1
Burst Length (number of cycles/burst)
d
rel
- Relative Transmission Distance
Fig. 9 - Max. Envelope Duty Cycle vs. Burst Length
Fig. 12 - Horizontal Directivity
E
e min.
- Threshold Irradiance (mW/m
2
)
0.3
0.25
0.2
0
°
10
°
20
°
30
°
40
°
1.0
50
°
60
°
70
°
80
°
0.6
95 11339p2
0.15
0.1
0.05
0
- 30
- 10
10
30
50
70
90
0.9
0.8
0.7
0.4
0.2
0
0.2
0.4
0.6
20755
T
amb
- Ambient Temperature (°C)
d
rel
- Relative Transmission Distance
Fig. 10 - Sensitivity vs. Ambient Temperature
Fig. 13 - Vertical Directivity
S (λ)
rel
- Relative Spectral Sensitivity
1.2
1.0
0.8
0.6
0.4
0.2
0
750
0.2
E
e min.
-
Sensitivity
(mW/m
2
)
0.18
0.16
0.14
0.12
0.1
0.08
0.06
0.04
0.02
0
850
950
1050
1150
20756
2
2.5
3
3.5
4
4.5
5
5.5
6
94 8408
λ
- Wavelength (nm)
V
S
-
Supply
Voltage (V)
Fig. 11 - Relative Spectral Sensitivity vs. Wavelength
Fig. 14 - Sensitivity vs. Supply Voltage
Rev. 2.5, 21-Feb-12
4
Document Number: 82013
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Not for New Design
TSOP12..
www.vishay.com
SUITABLE DATA FORMAT
The TSOP12.. series is designed to suppress spurious
output pulses due to noise or disturbance signals. Data and
disturbance signals can be distinguished by the devices
according to carrier frequency, burst length and envelope
duty cycle. The data signal should be close to the
band-pass center frequency (e.g. 38 kHz) and fulfill the
conditions in the table below.
When a data signal is applied to the TSOP12.. in the
presence of a disturbance signal, the sensitivity of the
receiver is reduced to insure that no spurious pulses are
present at the output. Some examples of disturbance
signals which are suppressed are:
• DC light (e.g. from tungsten bulb or sunlight)
• Continuous signals at any frequency
• Strongly or weakly modulated noise from fluorescent
lamps with electronic ballasts (see figure 15 or figure 16)
16920
Vishay Semiconductors
IR Signal
0
5
10
15
20
Time (ms)
Fig. 15 - IR Signal from Fluorescent Lamp
with Low Modulation
IR Signal
0
16921
5
10
15
20
Time (ms)
Fig. 16 - IR Signal from Fluorescent Lamp
with High Modulation
TSOP12..
Minimum burst length
After each burst of length
a minimum gap time is required of
For bursts greater than
a minimum gap time in the data stream is needed of
Maximum number of continuous short bursts/second
Recommended for NEC code
Recommended for RC5/RC6 code
Recommended for Sony code
Recommended for Thomson 56 kHz code
Recommended for Mitsubisi code (38 kHz, preburst 8 ms, 16 bit)
Recommended for Sharp code
Suppression of interference from fluorescent lamps
Note
• For data formats with short bursts please see the datasheet for TSOP11.., TSOP13.
10 cycles/burst
10 to 70 cycles
10 cycles
70 cycles
> 4 x burst length
1800
yes
yes
yes
yes
yes
yes
Most common disturbance signals are suppressed
Rev. 2.5, 21-Feb-12
5
Document Number: 82013
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
