2SC6026MFV
TOSHIBA Transistor
Silicon NPN Epitaxial Type (PCT Process)
2SC6026MFV
General-Purpose Amplifier Applications
0.22 ± 0.05
Unit: mm
1.2 ± 0.05
0.32 ± 0.05
0.80 ± 0.05
•
•
•
•
High voltage and high current
: V
CEO
= 50 V, I
C
= 150 mA (max)
Excellent h
FE
linearity :
h
FE
(I
C
= 0.1 mA)/h
FE
(I
C
= 2 mA) = 0.95 (typ.)
0.8 ± 0.05
1.2 ± 0.05
0.4
Complementary to 2SA2154MFV
0.4
High h
FE
:
h
FE
= 120 to 400
1
1
3
2
Absolute Maximum Ratings
(Ta = 25°C)
Characteristic
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
60
50
5
150
30
150*
150
−55
to 150
Unit
V
V
V
mA
mA
mW
°C
°C
0.5 ± 0.05
VESM
1.BASE
2.EMITTER
3.COLLECTOR
―
―
2-1L1A
JEDEC
JEITA
TOSHIBA
Note: Using continuously under heavy loads (e.g. the application of
Weight: 1.5 mg (typ.)
high temperature/current/voltage and the significant change
in temperature, etc.) may cause this product to decrease in
the reliability significantly even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are
within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
* : Mounted on FR4 board (25.4 mm
×
25.4 mm
×
1.6mmt)
Mount Pad Dimensions (Reference)
0.5
0.45
1.15
0.4
0.45
0.4
0.4
Unit: mm
Start of commercial production
2005-02
1
2014-03-01
0.13 ± 0.05
2SC6026MFV
