Part Number:
8073
Magnet Wire, (1) 14 AWG Solid BC, Heavy-Armored Poly-Thermaleze
Product Description
One 14 AWG solid bare copper conductor, heavy-armored poly-thermaleze insulation.
Technical Specifications
Physical Characteristics (Overall)
Conductor
AWG Stranding
14
Solid
Material
No. of Conductors
BC - Bare Copper 1
1
14 AWG
Conductor Count:
Conductor Size:
Insulation
Material
Polyester
Polyester-Imide or Polyester-Amide-Imide Overcoated
w/Polyamide-Imide
Outer Jacket Material
Material
Max. Diameter
Nominal Diameter
0.0682 in
No Jacket 0.0682 mm
Construction and Dimensions
Min Increase in OD:
0.003 in
Electrical Characteristics
Conductor DCR
Nominal Conductor DCR
2.5 Ohm/1000ft
Current
Max. Recommended Current [A]
5.9 A
Voltage
Breakdown Voltage
6325 volts minimum at room temperature
Temperature Range
Operating Temp Range:
200°C
Mechanical Characteristics
Approximate Length:
Turns Per Linear Inch:
Turns Per Square Inch:
Bulk Cable Weight:
80 ft
14.9
222
12.5 lbs/1000ft
Standards
UL AWM Style:
Military Specification:
Other Specification:
N/A
J-W-1177/14
NEMA-MW-35-C (Heavy)
Applicable Environmental and Other Programs
EU Directive 2000/53/EC (ELV):
EU Directive 2003/96/EC (BFR):
EU Directive 2011/65/EU (ROHS II):
EU Directive 2012/19/EU (WEEE):
EU Directive 2015/863/EU:
EU Directive Compliance:
EU CE Mark:
EU RoHS Compliance Date (yyyy-mm-dd):
CA Prop 65 (CJ for Wire & Cable):
MII Order #39 (China RoHS):
Yes
Yes
Yes
Yes
Yes
EU Directive 2003/11/EC (BFR)
Yes
2004-01-01
Yes
Yes
Flammability, LS0H, Toxicity Testing
UL voltage rating:
N/A
Plenum/Non-Plenum
Plenum (Y/N):
No
Part Number
Variants
Item # Color
8073
None
