2SC5755(TE85L,F) Overview

TRANSISTOR NPN 10V 2A TSM

2SC5755(TE85L,F) Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Reach Compliance Codeunknow
Base Number Matches1
2SC5755
TOSHIBA Transistor
Silicon NPN Epitaxial Type
2SC5755
High-Speed Switching Applications
DC-DC Converter Applications
Strobe Applications
High DC current gain: h
FE
= 400 to 1000 (I
C
= 0.2 A)
Low collector-emitter saturation voltage: V
CE (sat)
= 0.12 V (max)
High-speed switching: t
f
= 25 ns (typ.)
Unit: mm
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power
dissipation
Junction temperature
Storage temperature range
DC
t
=
10 s
DC
Pulse
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CP
I
B
P
C
(Note 1)
T
j
T
stg
Rating
20
10
7
2
3.5
200
500
750
150
−55
to 150
Unit
V
V
V
A
mA
mW
°C
°C
JEDEC
JEITA
TOSHIBA
2-3S1A
Weight: 0.01 g (typ.)
Note 1: Mounted on an FR4 board (glass epoxy, 1.6 mm thick, Cu area: 645 mm
2
)
Note 2: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly
even if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute
maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
1
2009-03-23
