AM2966DCB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> AM2966DCB

AM2966DCB: Description0.2A 2 CHANNEL, BUF OR INV BASED PRPHL DRVR, CDIP20, HERMETIC SEALED, CERDIP-20; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size837KB，7 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

AM2966DCB Overview

0.2A 2 CHANNEL, BUF OR INV BASED PRPHL DRVR, CDIP20, HERMETIC SEALED, CERDIP-20

AM2966DCB Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	DIP,
Contacts	20
Reach Compliance Code	unknown
Built-in protection	TRANSIENT
Interface integrated circuit type	BUFFER OR INVERTER BASED PERIPHERAL DRIVER
JESD-30 code	R-CDIP-T20
JESD-609 code	e0
length	24.4475 mm
Number of functions	2
Number of terminals	20
Maximum operating temperature	70 °C
Minimum operating temperature
Output current flow direction	SOURCE AND SINK
Nominal output peak current	0.2 A
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	COMMERCIAL
Maximum seat height	5.08 mm
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	NO
technology	BIPOLAR
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Disconnect time	0.035 µs
connection time	0.035 µs
width	7.62 mm
