KSA1182
PNP EPITAXIAL SILICON TRANSISTOR
LOW FREQUENCY POWER AMPLIFIER
•
Complement to KSC2859
SOT-23
ABSOLUTE MAXIMUM RATINGS (T
A
=25°C)
°
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Collector Dissipation
Junction Temperature
Storage Temperature
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
C
T
J
T
STG
Rating
-35
-30
-5
-500
150
150
-55 ~ 150
Unit
V
V
V
mA
mW
°C
°C
1. Base 2. Emitter 3. Collector
ELECTRICAL CHARACTERISTICS (T
A
=25°C)
°
Characteristic
Collector Cut-off Current
Emitter Cut-off Current
DC Current Gain
Collector-Emitter Saturation Voltage
Base-Emitter On Voltage
Current Gain-Bandwidth Product
Output Capacitance
Symbol
I
CBO
I
EBO
h
FE1
h
FE2
V
CE
(sat)
V
BE
(on)
f
T
C
OB
Test Condition
V
CB
= -35, I
E
=0
V
EB
= -5V, I
C
=0
V
CE
= -1V, I
C
= -100mA
V
CE
= -6V, I
C
= -400mA
I
C
= -100mA, I
B
= -10mA
I
C
= -100mA, V
CE
= -1V
I
C
= -20mA, V
CE
= -6V
V
CB
= -6V, I
E
= 0
f=1MHz
Min
Typ
Max
-0.1
-0.1
240
-0.1
-0.8
200
13
-0.25
-1.0
Unit
µA
µA
70
25
V
V
MHz
pF
h
FE
CLASSIFICATION
Classification
h
FE
(1)
O
70-140
Y
120-240
Rev. B
©
1999 Fairchild Semiconductor Corporation
KSA1182
PNP EPITAXIAL SILICON TRANSISTOR
