ES51F5G30DN-44.736-G

ES51F5

Series

• Temperature Compensated

Crystal Oscillators (TCXO)

• Clipped Sinewave Output

• +5.0V Supply Voltage

• Internal Mechanical Trim Function

• External Voltage Control Option

• Custom Lead Length & Gull Wing Options

• 14 pin DIP Metal Package

NOTES

ES51F5

H 8.3

L 20.3

W 13.0

OSCILLATOR

__________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

_________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

_________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

_________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________

ELECTRICAL SPECIFICATIONS

Frequency Range

Operating Temperature Range

Storage Temperature Range

Supply Voltage (V

DD

)

Input Current

Frequency Stability

9.600MHz to 44.736MHz

See Table 1

-55°C to 125°C

5.0V

DC

±5%

10mA Maximum

±1.0ppm (at Nominal V

DD

and V

C

, at 25°C)

See Table 1 (at Nominal V

DD

and V

C

)

±0.3ppm Maximum

±0.2ppm Maximum

±1ppm / year Maximum

1.0V

p-p

Minimum Clipped Sinewave

10kOhms//10pF

0.0V

DC

to V

DD

2.5V

DC

±2.0V

DC

±7ppm Minimum, ±20ppm Maximum

±10% Maximum

±3ppm Minimum (Top Access)

10kOhms Typical

-70dBc/Hz Typical

-100dBc/Hz Typical

-130dBc/Hz Typical

-140dBc/Hz Typical

-145dBc/Hz Typical

VOLTAGE

CLASS

REV

.

DATE

Measured at Steady State at 25°C, at Nominal V

DD

, at

Nominal V

C

vs. Initial Frequency Tolerance

vs. Operating Temperature Range

vs. Input Voltage (V

DD

±5%)

vs. Load (±10%)

Aging (at 25°C)

Output Voltage

Load Drive Capability

Control Voltage Range

Control Voltage (External)

Frequency Deviation

Linearity

Internal Trim

Input Impedance

Phase Noise (at 19.440MHz)

Positive Transfer Characteristic

Referenced to F

O

at V

C

= 2.5V

DC

, V

DD

= 5.0V

DC

Measured at 25°C, V

DD

=5.0V

DC

, V

C

=2.5V

DC

Measured at 25°C, at Nominal V

DD

, at Nominal V

C

at 10Hz Offset

at 100Hz Offset

at 1kHz Offset

at 10kHz Offset

at 100kHz Offset

SERIES

PACKAGE

MANUFACTURER

CATEGORY

ECLIPTEK CORP.

OSCILLATOR

ES51F5

14-PIN DIP

5.0V

OS3C

06/04

800-ECLIPTEK www.ecliptek.com for latest revision

Specifications subject to change without notice.

PART NUMBERING GUIDE

ES51F5 G 15 A V - 12.800M - G

INITIAL TOLERANCE

G=±1.0ppm Maximum

FREQUENCY STABILITY

Two Digit Code Per Table 1

OPERATING TEMP. RANGE

One Letter Code Per Table 1

AVAILABLE OPTIONS

Blank=None

CB=Cut Leads to 2.540 ±0.500 (0.100” ±0.020”)

CC=Cut Leads to 3.175 ±0.500 (0.125” ±0.020”)

CD=Cut Leads to 3.810 ±0.500 (0.150” ±0.020”)

CE=Cut Leads to 4.445 ±0.500 (0.175” ±0.020”)

G=Full Size Gull Wing

FREQUENCY

EXTERNAL TRIM

N=None (No Connection on Pin 1)

V=Voltage Control on Pin 1

MECHANICAL DIMENSIONS

ALL DIMENSIONS IN MILLIMETERS

MARKING SPECIFICATIONS

Line 1: ECLIPTEK

Line 2: XX.XXX M

M=MHz

Frequency (5 Digits Maximum + Decimal)

Line 3: XX Y ZZ

Week of Year

Last Digit of Year

Ecliptek Manufacturing Identifier

Note: Pin 1 shall be designated with a dot

Pin 1: Voltage Control or No Connect

Pin 7: Case Ground

Pin 8: Output

Pin 14: Supply Voltage

ENVIRONMENTAL/MECHANICAL SPECIFICATIONS

Characteristic

Fine Leak Test

Gross Leak Test

Mechanical Shock

Vibration

Lead Integrity

Solderability

Temperature Cycling

Resistance to Soldering Heat

Resistance to Solvents

Specification

MIL-STD-883, Method 1014, Condition A (Internal Crystal Only)

MIL-STD-883, Method 1014, Condition C (Internal Crystal Only)

MIL-STD-202, Method 213, Condition C

MIL-STD-883, Method 2007, Condition A

MIL-STD-883, Method 2004

MIL-STD-883, Method 2002

MIL-STD-883, Method 1010

MIL-STD-883, Method 210

MIL-STD-883, Method 215

MANUFACTURER

CATEGORY

SERIES

PACKAGE

VOLTAGE

CLASS

REV

.

DATE

ECLIPTEK CORP.

OSCILLATOR

ES51F5

14 pin DIP

5.0V

OS3C

06/04

800-ECLIPTEK www.ecliptek.com for latest revision

Specifications subject to change without notice.
