EFF-1.6AP datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Circuit protection> Circuit protection> EFF-1.6AP

EFF-1.6AP: DescriptionElectric Fuse, Fast Blow, 1.6A, 250VAC, 50A (IR), Through Hole, ROHS COMPLIANT; CategoryCircuit protection Circuit protection; File Size142KB，2 Pages; ManufacturerCooper Industries; Environmental Compliance

Download Datasheet Parametric View All

EFF-1.6AP Overview

Electric Fuse, Fast Blow, 1.6A, 250VAC, 50A (IR), Through Hole, ROHS COMPLIANT

EFF-1.6AP Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Cooper Industries
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
Fusing characteristics	FAST
body height	8.2 mm
Body length or diameter	8.35 mm
Circuit protection type	ELECTRIC FUSE
Joule integral nominal	1 J
Manufacturer's serial number	EFF
Installation features	THROUGH HOLE
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
method of packing	AMMO PACK
physical size	8.35mm x 8.2mm
Rated breaking capacity	50 A
Rated current	1.6 A
Rated voltage (AC)	250 V
Guideline	CSA; SEMKO; UL; VDE
surface mount	NO
Terminal shape	PIN WIRE

Preview

Download Datasheet

View All

Radial Lead Micro Fuse

EFF Series, Fast Acting

Description

• Fast acting micro fuse

• Base and cap material is a thermoplastic, UL 94-V0

• Leads are tin-lead plated copper alloy

Electrical Characteristics

150%

Rated Current

250mA to 5A

All are 250V AC

Min.

1 hr.

210%

Max.

30 min.

275%

Min.

10 ms.

Max.

3 sec.

400%

Min.

3 ms.

Max.

300 ms.

1000%

Max.

20 ms.

Dimensional Data

Agency Information

• Semco Certificate VDE License: 250mA to 5A / 35A or

whichever is greater @ 250VAC

• UL Recognized File No. E19180, CSA Acceptance File

No. LR701159; 250mA to 5A / 50A @ 250VAC

• RoHS Compliant

Environmental Data

• Soldering Heat Resistance: 260°, 10 sec. per IEC 68-2-20

• Vibration Resistance: MIL-STD-202, Method 201,

10-55Hz x 3 axis/ no load

• Shock Resistance: MIL-STD-202, Method 213,

Condition I (Sawtooth)

• Moisture Resistance: MIL-STD-202F, Method 106

• Salt Spray: MIL-STD-202, Method 101,

Condition B (48 hrs)

• Operating Temperature: -55°C to +125°C

Ordering

• Specify product code and packaging code

F500MA 250V

FUSE

LEAD

Short Lead

Dimensions

mm (inches)

Short Lead

∅

8.35 ± 0.1 (0.329)

7.7 ± 0.1 (0.303)

4.3 ± 0.3 (0.169)

—

0.5 min. (0.020)

0.6 ± 0.1 (0.024)

Long Lead

8.35 ± 0.1 (0.329)

7.7 ± 0.1 (0.303)

—

18.8 ± 0.3 (0.740)

0.5 min. (0.020)

0.6 ± 0.1 (0.024)

Long Lead

5.08 ± 0.1 (0.200) 5.08 ± 0.1 (0.200)

SPECIFICATIONS

Product

Code

EFF-250mA

EFF-315mA

EFF-400mA

EFF-500mA

EFF-630mA

EFF-800mA

EFF-1

EFF-1.25

EFF-1.6

EFF-2

EFF-2.5

EFF-3.15

EFF-4

EFF-5

EFF-6.3

Ampere

Rating

250mA

315mA

400mA

500mA

630mA

800mA

1.25A

1.6A

2.5A

3.15A

6.3A

Typical Cold

Resistance

(ohm)

0.45

0.34

0.25

0.19

0.091

0.071

0.055

0.043

0.034

0.026

0.02

0.016

0.012

0.01

0.008

Volt-drop

@ 100%

(Volt) max.

0.254

0.246

0.239

0.232

0.106

0.103

0.1

0.097

0.094

0.091

0.088

0.086

0.083

0.081

0.078

Melting I

< 10 mSec

Sec)

0.029

0.05

0.08

0.15

0.12

0.21

0.36

0.61

1.1

1.8

3.1

5.3

Melting I

@ 10

Sec)

0.027

0.05

0.08

0.13

0.22

0.36

0.59

1.7

2.7

4.5

Maximum

Power

Dissipation (W)

0.15

0.18

0.22

0.27

0.15

0.19

0.23

0.28

0.35

0.42

0.51

0.62

0.77

0.93

1.14

Voltage Drop measured at 100% of rated current.

Melting I

t measured at 10X current rating
