Prosine 1000/1800 Sine Wave Inverters
Provides 1000 and 1800 watts of sine wave AC power from a DC source
Offering superior quality true sine wave output, the Prosine 1000 and 1800 stand-alone inverters are
ideally suited for electrical systems that already have a quality multistage battery charger. Designed for
recreational and industrial applications, their 120-volt, 60 Hz AC power output is capable of handling
both heavy duty and smaller, multiple AC loads. Prosine inverters include a backlit LCD display panel,
which can be mounted remotely.
LR 86581
UL 458
CSA 107.10
CSA/NRTL certified to UL & CSA standards
Product Features
1000 and 1800 watt inverters (1500 and 2900 watt surge capability)
True sine wave AC output (crystal controlled)
Removable LCD display can be mounted remotely for control and monitoring
Unique DC terminals offer 180-degree connections for easy installation in tight places
Powersave mode draws only 1.5 watts under no load
Two year warranty
Protection Features
Over temperature shutdown and automatic overload protection
Over voltage and under voltage protection
Short circuit and AC backfeed protection
Options
Available in 12 and 24 volt models
Models available with GFCI AC outlet or AC hardwire terminal strip for permanent installation into
an electrical system (optional 15 A transfer switch available with hardwire option)
Remote interface kit for remote mounting of display module
Xantrex Technology Inc.
Headquarters
8999 Nelson Way
Burnaby, British Columbia
Canada V5A 4B5
800 670 0707 Toll Free
604 420 1591 Fax
5916 195th Street NE
Arlington, Washington
USA 98223
800 446 6180 Toll Free
360 925 5143 Fax
Ultra-clean true sine wave power
With less than 3% total harmonic distortion, Prosine 1000 and 1800 inverters deliver true sine wave
output that is identical to AC power supplied by your utility. This clean output makes Prosine inverters
ideal for handling sensitive loads and improves AC equipment performance. Expect trouble-free true
sine wave electricity for televisions, audio systems, variable speed tools, and more.
Light and compact
Prosine inverters are lighter and more compact than other inverters with similar power ratings
because they use high-frequency switching technology in the power conversion process.
www.xantrex.com
© 2004 Xantrex Technology Inc. All rights reserved. Xantrex is a registered trademark of Xantrex International. Printed in Canada
Smart choice for power
1000 Watt and 1800 Watt Sine Wave Inverters
Electrical Specifications
Models
Output power
Surge rating
Output current (peak)
Output voltage (at no load)
Output voltage (over full load
and battery voltage range)
Output frequency
Output waveform
Peak efficiency (12 V/24 V)
No load power draw (search mode)
No load power draw (idle mode)
Input voltage range (12 V/24 V)
Transfer relay rating
(hardwire/transfer relay models)
Transfer time AC to inverter
and inverter to AC
Prosine 1000
1000 watts
1500 watts
25 A
120 VAC +/-3%
120 VAC RMS -10%/+4%
60+/-0.05 (crystal controlled)
True sine wave (<3% THD)
89% / 90%
<1.5 W
<22 W
10 − 16 VDC / 20 − 32 VDC
15 A
Max 2 cycles (typically 1 cycle)
<2.5 seconds with Powersave “ON”
Prosine 1800
1800 watts
2900 watts
45 A
120 VAC +/-3%
120 VAC RMS -10%/+4%
60+/-0.05 (crystal controlled)
True sine wave (<3% THD)
89% / 90%
<1.5 W
<22 W
10 − 16 VDC / 20 − 32 VDC
15 A
Max 2 cycles (typically 1 cycle)
<2.5 seconds with Powersave “ON”
General Specifications
Operating temperature range
Storage temperature range
AC output types
32°F − 140°F (0°C − 60°C)
-22°F − 158°F (-30°C − 70°C)
Dual GFCI receptacle
Hardwire
Hardwire with transfer relay
LCD display panel
Removable; can be mounted remotely
(requires remote interface kit - see part number section)
Displays DC volts, amps and output power
Recommended DC fuse
12 V: 150 A or 175 A*
24 V: 70 A or 90 A*
*Depending on applicable installation codes
Dimensions (H x W x D)
Weight
Warranty
Part numbers
4.5 x 11.0 x 15.4” (115 x 280 x 390 mm)
14.5 lb (6.5 kg)
Two year
806-1000 (12 V w/GFCI outlets)
806-1001 (12 V w/AC hardwire)
806-1002 (12 V w/AC hardwire & transfer switch)
806-1050 (24 V w/GFCI outlets)
806-1051 (24 V w/AC hardwire)
806-1052 (24 V w/AC hardwire & transfer switch)
808-1800 (Remote interface kit)
32°F − 140°F (0°C − 60°C)
-22°F − 158°F (-30°C − 70°C)
Dual GFCI receptacle
Hardwire
Hardwire with transfer relay
Removable; can be mounted remotely
(requires remote interface kit - see part number section)
Displays DC volts, amps and output power
12 V: 225 A or 300 A*
24 V: 100 A or 150 A*
*Depending on applicable installation codes
4.5 x 11.0 x 15.4” (115 x 280 x 390 mm)
16.5 lb (7.5 kg)
Two year
806-1800 (12 V w/GFCI outlets)
806-1801 (12 V w/AC hardwire)
806-1802 (12 V w/AC hardwire & transfer switch)
806-1850 (24 V w/GFCI outlets)
806-1851 (24 V w/AC hardwire)
806-1852 (24 V w/AC hardwire & transfer switch)
808-1800 (Remote interface kit)
Regulatory Approvals
CSA/NRTL
certified to CSA 107.1, UL 458 (including Marine supplement) and UL 1741 standards
KKK-A-1822D:
Federal specification for use on ambulances
Designed to meet
ABYC
E8, E9, A25 for marine applications
Note: Specifications subject to change without notice.
