Panel Mount Indicator,
Mounting Hole 8mm, Recessed Bezel
with Resistor, IP67
= Gasket
=
Spring
washer
= Screw
nut M8, wrench size 10
All dimensions are in mm
Electrical and optical data are measured at an ambient temperature of T
A
= 25°C
Part No.
Satin Chrome Bezel
WL-19050251
WL-19050252
WL-19050253
WL-19050257
WL-1905025W
WL-19050351
WL-19050352
WL-19050353
WL-19050357
WL-1905035W
WL-19050451
WL-19050452
WL-19050453
WL-19050457
WL-1905045W
Black Chrome Bezel
WL-19051251
WL-19051252
WL-19051253
WL-19051257
WL-1905125W
WL-19051351
WL-19051352
WL-19051353
WL-19051357
WL-1905135W
WL-19051451
WL-19051452
WL-19051453
WL-19051457
WL-1905145W
1)
2)
3)
4)
Color
green
yellow
red
blue
white
green
yellow
red
blue
white
green
yellow
red
blue
white
green
yellow
red
blue
white
green
yellow
red
blue
white
green
yellow
red
blue
white
Voltage
V
OP
[V] DC
12
12
12
12
12
24
24
24
24
24
28
28
28
28
28
12
12
12
12
12
24
24
24
24
24
28
28
28
28
28
Current
I
OP
typ.
[mA] DC
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
Maximum panel thickness: 6.5mm
Storage temperature T
STG
: -25°C - +80°C
Ambient temperature T
A
: -20°C - +60°C
Voltage tolerance
V
OP
: ±10%
Lumi. Intensity LED
I
V
typ.
[mcd]
40
40
80
90
450
40
40
80
90
450
40
40
80
90
450
40
40
80
90
450
40
40
80
90
450
40
40
80
90
450
Dominant
Wavelength
λ
D
[nm]
568
588
625
466
*
568
588
625
466
*
568
588
625
466
*
568
588
625
466
*
568
588
625
466
*
568
588
625
466
*
*Chromaticity coordinates X = 0.31 Y = 0.32.
Degree of protection: IP67 in accordance to DIN EN 60529. Gap between LED and bezel and gap between bezel and frontplate
sealed to IP67 when using the supplied gasket.
Mounting hole 8 + 0.2mm
Connection is by solder tab terminals 2.8 x 0.8mm.
Due to production tolerances, color temperature variations may be detected within individual consignments.
ND
EB
EB
10/10/06
10/10/06
10/11/06
Panel Mount Indicators
8mm Recessed Bezel
714.545.5560
Fax: 714.545.6093
Drawn
Checked
Approved
11555 Coley River Circle
Fountain Valley, CA 92708
Datasheet:
WL-1905XX5X
Rev:
www.wamcoinc.com
info@wamcoinc.com
