WT0805ML030L Overview

Multilayer Ceramic Transient Voltage Suppressor Low Capacity

Preview

Download Datasheet

View All

ARISTORS

Transient

Multilayer Ceramic Transient

This product is not recommended

Voltage Suppressor

for new designs. Please refer to

Low Capacity

Littelfuse series MLA.

TVS 0805 SMD

Specifications

Packaging

Material

Tape and Reel

7 inch reel (3.000 pcs.)

Body:

Terminals:

Ceramic (ZnO)

Ni/Sn plated (code “P”)

Ag/Pt/Pd non plated

(code “N” on request)

Features

Thin layer, high precise techniques

Lead free

Bi-directional clamping

Standard and low capacity

Available with Nickel/tin end termination

Temperature

Operating Temperature

-55 to +125°C

Solderability

Applications

Dimensions (mm)

acc. to IEC 60068-2-58

235°C, 2s

260ºC, 10 sec. (IEC 60068-2-58)

280ºC, 5 sec. (IEC 60068-2-58)

<0.5ns

0.40–0.25

WebLinks

2.00–0.20

1.20

1.25–0.15

Circuit board and ESD, EFT

Protection of:

• I/O ports

• Keyboards

• LCD‘s

• Sensors

Soldering Heat Resistance

Time

Response Time

(α

Temperature coefficient (

V) of clamping

voltage (Vc) @ specified test current

<0.01%/°C

Further infos see:

www.wickmanngroup.com

Further technical infos see technical

varistor file:

www.wickmanngroup.com/download/

techvaristor.pdf

Power dissipation

0.1W max.

Standards

IEC 61000-4-2

MIL-STD-883C

Maximum Ratings (125°C)

Type

max. cont.

working

voltage

M(DC)

M(AC)

(V)

WT0805ML030L

WT0805ML050L

WT0805ML090L

WT0805ML120L

WT0805ML140L

WT0805ML180L

WT0805ML220L

WT0805ML260L

WT0805ML300L

3,3

5,5

9,0

12,0

14,0

18,0

22,0

26,0

30,0

2,5

4,0

6,0

9,0

11,0

14,0

17,0

20,0

25,0

Specifications (25°C)

typ.

capacitance

1KHz

typ.

(pF)

2.080

790

650

560

445

330

320

330

220

max.

non-repetitive

surge current

(8/20

µs)

(A)

max. non-repetitive max. clamping

nominal voltage

surge energy

voltage at spec.

at 1mA (DC)

(10/1000

µs)

current

test current

(8/20

µs)

N(DC)min.

N(DC)max.

(J)

(V@A)

(V)

0,10

10,0 @ 2

15,5 @ 2

20,0 @ 2

25,0 @ 2

30,0 @ 2

40,0 @ 2

44,0 @ 2

58,0 @ 2

65,0 @ 2

3,8

7,1

10,0

14,0

16,0

22,0

24,3

29,5

35,0

7,0

9,8

14,5

18,5

21,0

28,0

30,0

38,0

43,0

typ.

inductance

1MHz

typ.

(pF)

1.900

720

550

480

380

290

280

285

190

typ.

(nH)

1,5

Order

Information

050915

Qty.

Order-

Number

Type

WT0805ML140 L

Terminal

Terminal Code Packaging

Specifications are subject

to change without notice
