PANEL METER
▣ Specifications
Model
Power supply
Power consumption
Display method
12-24 VDC/AC
MT4N
100-240 VAC
DC: 3W, AC: 5VA
5VA
7 Segment LCD Display, Character height: 9mm
23℃ ± 5℃ ☞ DC Type: F.S.±0.1% rdg±2digit / AC Type: F.S.±0.3% rdg±3digit
DC/AC Type: Within F.S.±0.3% rdg±3digit only for Current 5A terminal
-10℃ to 50℃ ☞ DC/AC Type: F.S.±0.5% rdg±3digit
DC Voltage/Current, AC Voltage/Current, AC Frequency
110% F.S. for input spec.
Practical oversampling using successive approximation ADC
50ms(DC), 16.6ms(AC)(1/12,000)
-1999 to 9999(4 Digit)
Relay output ☞ Contact capacity: 125VAC 0.3A, 30VDC 1A/Contact composition: N.O(1a)
NPN/PNP Open Collector output ☞ 12-24VDC ±2V 50mA Max.(Load resistance)
RS485 communication output
☞ Baud rate: 1200/2400/4800/9600, Transmission method: 2 wires half duplex, Tuning
method: Sub-synchronization, Protocol: Modbus type
DC4-20mA output ☞ Resolution: 12,000 division(Load resistance max. 600Ω)
Selectable RMS or AVG
●
●
●
●
▣ Parameter
Parameter
IN-T
IN-R
DISP
STND
FREQ
SCAL
H-SC
L-SC
DOT
D-UNT
Display
Input type
Input range
Display
Standard
Frequency
Scale
High scale
Low scale
Dot
Display unit lamp
Function
Selectable RMS/AVG in AC type
Input range selection
Display type selection
Standard scale range
Frequency display
Scale range
Set max. value of display range
Set min. value of display range
Set decimal point position
Set display unit
Correct High-limit gradient of display value
Correct Low-limit gradient of display value
Set display index of frequency mode
Select output mode of OUT1
Select output mode of OUT2
Select hysteresis of OUT1
Select hysteresis of OUT2
Set startup compensation time
Note
Available AC type only.
-
Selectable:
STND
/
SCAL
/
FREQ
Display max. display value of
STND
Available AC type only.
These are displayed in
SCAL
only and set
max/min. display value(-1999 to 9999).
It is displayed in
SCAL/FREQ
only and set the position.
Set range: mV / V / mA / A / Hz / off
STND/SCALCorrection
range: 0.100 to 5.000
FREQ
Correction range: 0.100 to 9.999
Correction range: -99 to 99
Set range: 10
-2
/10
-1
/10
0
/10
1
OFF/ HI/ LO
/
HL/ HL-G
OFF/ HI/ LO
/
HL/ HL-G
Within 1 to F.S. 10%(Variable depending
on set of input range and prescale.)
Set range: 0.0 to 99.9 sec.
MT4N SERIES
M
A
N
U
A
L
: Upgrade feature
Display accuracy
Input
Max. allowable input
A/D conversion method
Sampling cycle
Max. display range
Preset output
Sub output
(Transmission output)
PA1
(Parameter 1)
INB.H
Input bias high
INB.L
Input bias low
INB.E
Input bias exponent
OU1.T
Out1 type
OU2.T
Out2 type
HYS.1
Out1 hysteresis
HYS.2
Out2 hysteresis
Startup ompensation
STA.T
time
PEK.T
Peak time
DIS.T
Display time
COLR
Color
PA2
(Parameter 2)
ZERO
EVIN
FS-H
FS-L
ADRS
BPS
PRTY
STP
RSY.T
LOC
OU1.H
OU1.L
PA0
(Parameter 0)
OU2.H
OU2.L
H.PEK
L.PEK
Thank you very much for selecting Autonics products.
For your safety, please read the following before using.
▣ Caution for your safety
※Please keep these instructions and review them before using this unit.
AC measuring function
Frequency measuring
function
Hold function
※1
Insulation resistance
Measurement range: 0.100 to 9999Hz(Differ according to decimal point position)
※Please observe the cautions that follow;
Warning
Serious injury may result if instructions are not followed.
Caution
Product may be damaged, or injury may result if instructions are not followed.
※The following is an explanation of the symbols used in the operation manual.
Caution: Injury or danger may occur under special conditions.
Warning
1.In case of using this unit with machinery(Nuclear power control, medical equipment, vehicle, train, airplane,
combustion apparatus, entertainment or safety device etc), it is required to install fail-safe device.
It may cause a fire, human injury or property loss.
2.It must be mounted on panel.
It may give an electric shock.
3.Do not connect, inspect or repair terminals when it is power on.
It may give an electric shock.
4.Do not disassemble or modify this unit. If needs, please contact us.
It may cause a fire and give an electric shock.
5.Please check the number of terminal when connecting power or measured input.
It may cause a fire.
Includes(Outer hold function)
Min. 20㏁(at 500VDC megger)
1000VAC for 1 minute
2000VAC for 1 minute
Dielectric strength
(Between external terminal and case)
(Between external terminal and case)
Noise strength
±2kV the square wave noise(pulse width: 1㎲) by the noise simulator
Mechanical 0.75mm amplitude at frequency of 10 to 55Hz in each of X, Y, Z direction for 2 hours
Vibration
Malfunction 0.5mm amplitude at frequency of 10 to 55Hz in each of X, Y, Z direction for 10 minutes
Mechanical 100m/s
2
(Approx. 10G) in X, Y, Z directions for 3 times
Shock
Malfunction 300m/s
2
(Approx. 30G) in X, Y, Z directions for 3 times
Ambient
-10 to 50℃, Storage: -20 to 60℃
Environ- temperature
ment
Storage
35 to 85%RH, Storage: 35 to 85%RH
humidity
Insulation type
※2
Approval
Unit weight
Approx. 64g
-
Set monitoring delay time for peak value(sec) Set range: 00 to 30 sec.
Set sampling time(sec)
0.1 to 5.0 sec.(Variable by 0.1 sec.)
Select color
RED
/
GRN
/
YEL
/
R-G
/
G-R
No: Enable/disable zero adjustment key
Zero key
Enable zero adjustment key
Yes: Enable zero adjustment key
Hold: Use external terminal as Hold terminal
Zero: Use external terminal as zero adjustment terminal
Event input
Set external terminal(11, 12) function
※It is enable to use in option mode.
Full scale high
Set High-limit value output position of PV output Min. set range: Min. 10% F.S.
Full scale low
Set Low-limit value output position of PV output Max. set range: Max.
FS-H
10%
Address
Set communication address
Set range: 01 to 99
Bit per second
Set baud rate(bps)
Selectable:1200/2400/4800/9600
Parity bit
Set parity bit
Selectable: None/ Even / Odd
Stop bit
Set stop bit
Set range: 1/2
Response wating time Set response wating time
Set range: 5 to 99
Lock
Enable lock status
Selectable:
OFF/LOC1/LOC2/LOC3
Set the range within display range of
OUT1 high preset
Set value of OUT1 High-limit output
STND/SCAL.
OUT1 low preset
Set value of OUT1 Low-limit output
For MT4N-DV/DA Type, set range of
OUT2 high preset
Set value of OUT2 High-limit output
OU1.H/OU2.H
and
OU1.L/OU2.L
is within -5
OUT2 low preset
Set value of OUT2 Low-limit output
to 110%.
High peak
Max. value by data monitoring
key is pressed, it will be returned
to initial status.
Low peak
Min. value by data monitoring
Caution
1.This unit shall not be used outdoors.
It might shorten the life cycle of the product or give an electric shock.
Use this product indoors only. Do not use the product outdoors or at locations subject to the
temperatures or humidity outside.(Example: rain, dirty, frost, sunlight, condensation, etc.)
2.When connecting wire, use AWG 20(0.50㎟) be used and tighten screw bolt on terminal block
with 0.74 to 0.90N.m strength.
It may cause a malfunction or fire due to contact failure.
3.Please observe the rated specification.
It might shorten the life cycle of the product and cause a fire.
4.Do not use beyond of the rated switching capacity of relay contact.
It may cause insulation failure, contact melt, contact failure, relay broken and fire etc.
5.In cleaning the unit, do not use water or an oil-based detergent.
It may cause a fire and give an electric shock.
6.Do not use this unit in place where flammable or explosive gas, humidity, direct ray of the
light, radiant heat, vibration or impact, etc. exists.
It may cause a fire or explosion.
7.Do not inflow dust or wire dregs into the unit.
It may cause a fire or mechanical malfunction.
8.Please wire properly after checking the polarity of measuring terminals.
It may cause a fire or explosion.
※
1:
" " Mark indicated that equipment protected throughout by double insulation or reinforced insulation.
※
2:
The indicator has no Hold function.
※ Environment resistance is rated at no freezing or condensation.
▣ Parameter setting
RUN
MODE
key
▣ Specification of measured input and range
Type
Measured input
and range
0-50V
0-10V
0-5V
0-1V
0-250mV
0-50mV
0-500mA
DC
Ampere
0-200mA
0-50mA
4-20mA
0-5mA
0-2mA
0-250V
0-125V
0-50V
0-25V
0-5V
0-2.5V
0-5A
0-2.5A
0-500mA
0-250mA
0-100mA
0-50mA
[50V]
[10V]
[5V]
[1V]
[250mV]
[50mV]
[500mA]
[200mA]
[50mA]
[4-20mA]
[5mA]
[2mA]
[250V]
[125V]
[50V]
[25V]
[5V]
[2.5V]
[5A]
[2.5A]
[500mA]
[250mA]
[100mA]
[50mA]
Input
impedance
434.35㏀
434.35㏀
43.35㏀
43.35㏀
2.15㏀
2.15㏀
0.1Ω
0.1Ω
1.1Ω
1.1Ω
11.1Ω
11.1Ω
1.109㏁
1.109㏁
222㏀
222㏀
22㏀
22㏀
0.01Ω
0.01Ω
0.1Ω
0.1Ω
0.5Ω
0.5Ω
Standard [STND]
Display rang [Fixed]
0.00 to 50.00(Fixed)
0.00 to 10.00(Fixed)
0.000 to 5.000(Fixed)
0.000 to 1.000(Fixed)
0.0 to 250.0(Fixed)
0.00 to 50.00(Fixed)
0.0 to 500.0(Fixed)
0.0 to 200.0(Fixed)
0.00 to 50.00(Fixed)
4.00 to 20.00(Fixed)
0.000 to 5.000(Fixed)
0.000 to 2.000(Fixed)
0.0 to 250.0(Fixed)
0.0 to 125.0(Fixed)
0.00 to 50.00(Fixed)
0.00 to 25.00(Fixed)
0.000 to 5.000(Fixed)
0.000 to 2.500(Fixed)
0.000 to 5.000(Fixed)
0.000 to 2.500(Fixed)
0.0 to 500.0(Fixed)
0.0 to 250.0(Fixed)
0.0 to 100.0(Fixed)
0.00 to 50.00(Fixed)
Praescale [SCAL]
Display range [Variable]
2 sec.
※ Press
MODE
key for 2 sec. in RUN mode, [
PA1](Parameter
1) is displayed.
※ Press
MODE
key for 4 sec. in RUN mode, [
PA2]
is displayed after [
PA1].
When press
MODE
key is pressed continually, it stops displaying at [
PA2].
※ It is advanced to current display parameter releasing
MODE
key at [
PA1]
or [
PA2].
※ Press
MODE
key for 3 sec., it is returned to RUN at any position.
※ If any key is not touched for 60 sec. in each parameter, it will return to RUN mode.
※ After return to RUN mode, press
MODE
key within 2 sec., it will return to
previous parameter.(Refer to the below descriptions for set parameter.)
PA1
MODE
key
2 sec.
PA2
-1999 to 9999(Variable)
-199.9 to 999.9(Variable)
-19.99 to 99.99(Variable)
-1.999 to 9.999(Variable)
(Display position will be
different depending on
decimal point position.)
※Please wire proper terminal
to its max. input voltage
within 30 to 100% of input
terminal.
When it is higher than
input voltage, it may cause
breakdown of terminal and
over display range and
the accuracy is decreased
when it is connected to
the terminal under 30%.
DC
Volt
▣ Change the parameter
setting value
1.Advance to the parameter to be changed when
press
MODE
key continuously in RUN mode and
release
MODE
key at the parameter.(Refer to "▣
Parameter setting")
2.When press
MODE
key in each parameter, the
initial mode of the parameter is displayed.(Refer
to the description of each parameter.)
,
keys in display mode.
3.When press one of ,
Ex)
Mode
Setting
value
▣ Parameter 0
RUN
MODE
▣ Ordering information
MT 4
N
DV
E N
Control output
N
0
1
2
3
4
E
4
DV
DA
AV
AA
N
4
MT
Without output function
Relay output(2 Contacts)
NPN Open collector output(OUT1,GO,OUT2)
PNP Open collector output(OUT1,GO,OUT2)
Relay(OUT1)+PV transmission(DC4-20mA)output
Relay(OUT2)+RS485 communication output
12-24VDC/AC
100-240VAC
DC Volt
DC Ampere
AC Volt
AC Ampere
DIN W48×H24㎜
9999(4 Digit)
Multi Meter
AC
Volt
IN-R
Press one
250V
flashes every 0.5 sec.
Saved setting value
Set High-limit preset value of
OU1.T.
(It is not displayed when
OU1.T
mode
MODE
value of PA2 is
OFF.)
keys.
※Change the value by
Set Low-limit preset value of
OU1.T.
OU1.L
(It is not displayed when
OU1.T
mode
MODE
value of PA2 is
OFF.)
※Change the value by
keys.
OU1.H
OU2.H
4.Change the set value by
or
key when setting
value is flashed.
Ex) Change AC type measured input from 250V to 125V.
Mode
Setting
value
Set High-limit preset value of
OU2.T.
(It is not displayed when
OU2.T
mode
MODE
value of PA2 is
OFF.)
keys.
※Change the value by
Set Low-limit preset value of
OU2.T
(It is not displayed when
OU2.T
mode
MODE
value of PA2 is
OFF.)
※Change the value by
keys.
It displays High peak value in RUN mode
and
keys are pressed, it is
MODE
reset.
It displays Low peak value in RUN mode
and
keys are pressed, it is
MODE
reset.
OU2.L
Power supply
AC
Ampere
IN-R
DISP
Press one
250V
Setting
value MODE
125V
H.PEk
L.PEk
Input
▣ Monitoring peak display value function
[PA 0:
H.PEK/ L.PEKmode,
PA 2:
PEK.Tmode
]
It monitors Max./Min. value of display value based on current display value and then display the data in
H.PEK
mode and
L.PEK
mode of parameter 0. Set delay time(0 to 30 sec.) in
PEK.T
mode of parameter 2 in order to avoid
caused by initial overcurrent or overvoltage, when monitoring the peak value. Delay time is 0 to 30 sec. and it starts
to monitor the peak value after set time.
keys are pressed at
H.PEK
and
L.PEK
mode of parameter 0, it will be initialized.
When
※ Monitoring function is not indicated when setting the
PEK.T
of parameter 2 as "0".
Size
Digit
Item
5. When press
MODE
key to complete the change and
it is advanced to the next mode after flashes 2 times.
6. When press
MODE
key for 3 sec. after change, it
returns to RUN mode.
If
PEK.T
monitoring delay time in PA2 is '00',
H.PEK
and
L.PEK
are not displayed.
<Measured input specification for each model>
Model
Measured input range
MT4N-DV
50V 10V 5V 1V 250mV 50mV 50V
500mA 200mA 50mA 4-20mA 5mA
MT4N-DA
2mA 500mA
MT4N-AV
250V 125V 50V 25V 5V 2.5V 250V
SA 25A 500mA 250mA 100mA 50mA
MT4N-AA
5A
▣ Parameter 1
PA1
Select measured input specification.
IN-R
(Refer to "▣Specification of
measured input and range".)
▣ Front panel identification
▣ Panel cut-out
Min. 55
(Unit: mm)
OUT1: Preset output of OUT1
GO: Preset Go output of OUT1/OUT2
OUT2: Preset output of OUT2
MODE
: MODE key
: Shift key
mV, V Unit
Min. 37
: Down key
mA, A Unit
: Up key
Hz Unit
▣ Current output(DC4-20mA)
Scale adjustment function
[ PA 2:
FS-H/ FS-Lmode
]
It sets current output for preset display value at the output
current 4-20mA DC.
It sets display value for 4mA in
FS.L
and 20mA in
FS.H
and set range between
FS-H
and
FS-L
should be 10%
F.S.(When it set as under 10% F.S., it changed as over
10% F.S. automatically.)Preset display value is fixed to
output as 4mA at under
FS-Land
20mA at over
FS-H.
Output
20mA
▣ Measuring AC frequency
function
[ PA 1:
DISP
mode ]
It measures input signal frequency when it is an AC input
using fixed decimal point[PA1:
DOT
mode]. Measuring
range can be changed by setting and measuring range
of decimal point position is as below chart. It is available
to adjust upper gradient in [PA 1:
INB.H
mode] and [PA
1:
INB.E
mode]. In order to measure frequency normally,
input signal, over 10% F.S. of measuring range, should be
supplied. Please wire the proper measuring terminal.
①Measuring range
Decimal point
0.000
0.00
0.0
0
position
Measurement 0.100 to 0.10 to 0.1 to
1 to
range
9.999Hz 99.99Hz 999.9Hz 9999Hz
MODE
DISP
STND
↔
SCAL↔ FREQ
and
FREQ.
MODE
Set display type for measured input as
It is only available for AC type.
Select measuring type for AC input type.
22.2
+0.3
-0
45
+0.6
-0
MODE
IN-T
Select
RM5
↔
AU6
STND
It shows max. display
<When
DISP
is
STND>
▣ Terminal connection
●
MODE
MT4N-DV-□□
●
MT4N-DA-□□
value of standard
MODE
specification.
Set display value for max.
Display value is fixed.
H-SC
input of measured input.
MODE
MODE
DOT
<When
DISP
is
SCAL>
Set decimal point position.
0↔ 0.0↔ 0.00↔ 0.000
DOT
<When
DISP
is
FREQ>
Set frequency measuring range.
(Refer to "▣ Measuring AC
frequency function" .)
1
2
3
5V/1V
4
5
6
1
2
3
5mA
/2mA
4
5
6
L-SC
D.UNT
MODE
Set display value for min.
input of measured input.
Set display unit.
Set range:mV/V/mA/A/Hz/off
Adjust High-limit display value
gradient for max. input.
Adjust Low-limit display value
deviation for min. input.
MODE
250mV
/50mV
50V/10V
●
MT4N-AV-□□
SOURCE
12-24VDC/AC
100-240VAC
50mA/4-20mA
500mA/200mA
●
MT4N-AA-□□
SOURCE
12-24VDC/AC
100-240VAC
4mA
Min. setting range
10% F.S.
1
2
3
5V/
2.5mV
50V/25V
4
5
6
1
2
3
500mA/250mA
5A/2.5A
4
5
6
FS-L
FS-H
Display value
100mA
/50mA
SOURCE
12-24VDC/AC
100-240VAC
●
0.100 to 5000Hz: Display accuracy error within
±0.3%F.S.±2Digit
5000 to 9999Hz: Display accuracy error within
±1%F.S.±3Digit
②
INB.H:
0.100 to 9.999 (Gradient adjustment of high value)
③
INB.E:10-2, 10-1, 10 0, 10 1
(Index adjustment of
INB.H)
●
●
INB.H
INB.L
INB.H
INB.E
MODE
MODE
Set range:
0.100
to
5.000
MODE
Set range:
0.100
to
9.999
Adjust High-limit display value
gradient for max. input.
Set index for frequency display.
Set range:10-2↔10-1
↔10
0↔10 1
250V/125V
<Option>
●
Relay output [MT4N-□□-□0]
SOURCE
12-24VDC/AC
100-240VAC
▣ Error correction function
[ PA 1:
INB.H/ INB.Lmode
]
It corrects display value error of measured input.
INB.L:±99
(Adjust deviation of low value)
INB.H:
5.000 to 0.100(Correct gradient(%) of high value)
Display value=(Measured value ×
INB.H)+ INB.L
Ex) Low value correction
When there is an application where there is a residual
voltage of 1.2V, but a 0V display is desired, then it
is possible by adjusting the
INB.L
parameter setting
to 12(offset correcting value or equal to 1.2V without
decimal) that the desired display value of 0 can be
achieved.
Ex) High value correction
When there is an application where the high actual value
of display is 501 and exceeds the 500V display range,
then it is possible by adjusting the
INB.H
parameter
setting to 0.998(calculated by desired value of 500/actual
value of 501), that the desired value can be achieved.
※ The offset correction range of
INB.L
is within -99 to
99 for D
-0
, D
-1
digit regardless of decimal point.
▣ Zero adjustment function
It adjusts the display value of the optional configured
input value as zero by force, zero point error can be
adjusted with 3 ways as below.
When zero point adjustment with front key and
Hold terminal is finished normally, zero point
of measuring terminal is displayed and the
adjusted value is saved in
INB.L
automatically.
Input
Oper-
correction Front key
ation
value
Input external
signal
MODE
Set range:
-99
to
99
▣ Parameter 2
PA2
OU1.T
Select Preset output mode of OUT1 as
OFF↔ HI↔ LO↔ HL↔ HL-G
MODE But, it is only displayed in OUT1 output
included model.
Select Preset output mode of OUT2 as
OFF↔ HI↔ LO↔ HL↔ HL-G
MODE But, it is only displayed in OUT2 output
included model.
Select Preset hysteresis of OUT1 within 10%
of F.S. But, it is not displayed when
OU1.T
MODE mode is
OFF.
Select Preset hysteresis of OUT2 within
10% of F.S. But, it is not displayed when
MODE
OU2.Tmode
is
OFF.
Set startup compensation time.
Set range is 0.0 to 99.9 sec.
Set monitoring delay time within 00 to 30 sec.
ZERO
NPN Open Collector output [MT4N-□□-□1]
Enable zero adjustment by front key operation
to select
YES.
Press both + keys simul-
taneously in 3 sec. The deviation value is saved in
MODE
INB.L
automatically.
Select between hold input by terminal 11, 12
and zero set by external signal.
●
HOLD:
Hold display value
MODE
●
ZERO:
Zero adjustment by external signal
7
OUT1
●
8
9
10 11 12
OUT2
HOLD/ZERO
●
7
OUT1
8
GO
9
OUT2
10 11 12
HOLD/ZERO
EVIN
OU2.T
FS-H
PNP Open Collector output [MT4N-□□-□2]
Relay+Current(DC4-20mA) output [MT4N-□□-□3]
7
OUT1
●
8
GO
9
OUT2
10 11 12
HOLD/ZERO
7
8
9
10 11 12
OUT1
HOLD/ZERO
DC4-20mA
Relay+RS485 communication output [MT4N-□□-□4]
PA1
: Direct
input
correction
Des-
value
cription
method
at
INB.
Lmode
Press both
,
keys for 3
sec. at the
measuring
mode.
Short-circuit
external Hold
terminal no.11,
12 over min.50m.
※It is enable to
use in option
mode.
HYS.1
Set High-limit value, 20mADC output position of PV output.
※When input range and prescale mode are
changed, the set value of
FS-H
and
FS-L
is
MODE
change automatically as max/min. value of input
range.
Set Low-limit value, 4mADC output position
FS-L
of PV output.
MODE
HYS.2
STA.T
ADRS
MODE
Set address of RS485 communication output
within 01 to 99.
Set baud rate of RS485 communication
output within
9600↔4800↔2400↔1200.
Set parity bit.
Set range: None / Even / Odd
Set stop bit.
Set range: 1/2
Set response waiting time.
Set range: 5 to 99
Enable Lock function with 4 mode,
OFF↔ LOC1↔ LOC2↔ LOC3↔ OFF
.
7
B(-)
8
A(+)
9
10 11 12
OUT1
HOLD/ZERO
※Refer to description [▣ Error correction function],
[▣ Error indication function] and [▣ Parameter 2]
for function and error.
BPS
MODE
MODE
▣ Gradient correction function
[ PA 1:
INB.H
mode ]
(Figure1)
Display value
αY
α Time
Y
βY
0
β Time
PEK.T
MODE
PRTY
MODE
▣ Prescale function
[PA1:
H-SC/ L-SC
mode]
This function is to display setting(-1999 to 9999) of particular High/Low-limit value in order to display
High/Low-limit value of measured input. If measured inputs are 'a' and 'b' and particular values are 'A'
and 'B', it will display a=A, b=B as below graphs.
Display
B
A
a
b
Input value
Display
B
A
a
b
Input value
A
b
Display
B
B
Display
A
a
A
Display
B
a
b
Input value
b
A
Display
B
b
It corrects a gradient of prescale value and display value.
(Figure 1)Display value Y can be adjusted as α, β times against X input value by
correction function [
INB.H
] and used as correction function of max. display value
[
H-SC
]. Adjustment range is 0.100 to 5.000 and multiply current gradient by the
value.
DIS.T
MODE
Execute variable set display period by 0.1
sec. within 0.1 to 5.0 sec.
Select color with 5 modes.
RED↔ GRN↔ YEL↔ R-G↔ G-R
●
RED, GRN, YEL:
Display with 1 color.
●
R-G, G-R
: Color is changed when error is occurred.
Ex)
R-G
: Red is standard and green when error is
occurred.
※ Color is changed only when error in"▣ Error
display function" is occurred excluding 'over'.
STP
MODE
Input value
Input value
Input value
Ex) To display "3.000" in DC 200mV input for measured input specification as 0 to 1V,
①Select 0-1VDC for measured input in Parameter 1
②Standard specification in input: 0-1VDC and 1.000 therefore it has to be 15.000(
H-SC)
for 1VDC(Input) in order to display 3.000 for 200mVDC(input).
But it is unable due to setting range is 9.999.
③In this case, please check below chart. Please set as
INB.H× H-SC
= 15.000
15.000
12.000
9.000
6.000
3.000
1.000
Setting
method
①
②
③
④
⑤
COLR
MODE
RSM.T
MODE
X
Input value
LOC
MODE
Display value
▣ Error display function
Display
Description
Flashes when measured input is exceeded
HHHH
the max.allowable input(110%)
Flashes when measured input is exceeded
LLLL
the min.allowable input(-10%)
D-HH
Flashes when display input is exceeded
H-SC
setting value
▣ Initialization function
It initializes parameter setting state. Press
+ + keys simultaneously for over 5 sec. in
RUN status, it returns to factory default value.
Ex)
RUN
+ + Press
for over 5 sec.
H-SC
Unavailable
7.500
5.000
3.750
3.000
L-SC
0.000
0.000
0.000
0.000
0.000
INB.H
Remark
OFF
Disable Lock function
LOC2
Lock parameter 1,2
LOC1
Lock parameter 1
LOC3
Lock parameter 0,1,2
Display value for
measured input
0.2 0.4 0.6 0.8 1V Input value
1.000
-
2.000
3.000 In this case, any setting
methods display same
4.000
display value.
5.000
▣ Caution for using
1. Allowable installation environment
①If shall be used indoor ②Altitude Max. 2,000m ③Pollution Degree 3 ④Installation Category
II
2. Use compression terminal(M3, Max. 6.0mm) to connect AC power.
Max.
3. Separate from high-tension line, power line to avoid inductive noise.
0.6mm
4. Install power switch or circuit breaker to on / off the power at once.
5. The switch or circuit breaker should be installed nearby users for safety.
6. Avoid to use the unit nearby machinery with high frequency noise, such as high frequency welder / sewing machine and high capacity SCR
controller etc.
●
Using line filter
●
Using varistor
7. "HHHH" or "LLLL" is displayed, off the power and check
lines.
Install it closely from DPM
8. Noise inflowing from power line can cause serious problem
HI
110/
for D.P.M.(Digital Panel Meter) of AC power. It is hard
D.P.M. INPUT
110/
to install protection circuit in the small unit even there is
D.P.M. 220VAC
LOW
220VAC
condenser to avoid noise between lines at primary of power
transformer. Use noise absorber circuit such as line filter,
Earth ground
varistor at external lines when abnormal voltage is occurred
●
Using Single shield wire
by power relay, magnet switch, high frequency equipment are
●
Using double shield wire
operated in same lines.
HI
HI
+
+
9. Input line : Use shield wire when measured input line is
Vin
Vin
D.P.M.
D.P.M.
extended or in a place with noise and open the non-used
-
-
LOW
LOW
terminals.
※It may cause malfunction if above instructions are not followed.
D-LL
Flashes when display input is exceeded
L-SC
setting value
F-HH
value of measuring range
OVER
Flashes when it exceeds zero range(±99)
Flashes when input frequency is exceeded the max. display
IN1 T
NO
YES
MODE
▣ Preset output mode
[ PA 2:
OU1.T
/
OU2.T
mode ]
Mode
Output operation
No output
OUT1 output
OUT1.H
No output
Operation
OFF
※ Zero adjusting error is returning to measuring mode after
[
OVER]
flashes twice.
※ Refer to "▣ Measuring AC frequency function" for frequency
measuring range.
HI
OUT1 output
Hysterisis
Period ON: Display value≥OUT1.H
Period OFF: Display value≤OUT1.H-Hys
Period ON: Display value≤OUT1.L
Period OFF: Display value≥OUT1.L+HYS
Period ON: Display value≤OUT1.L
or Display value≥OUT1.H
Period OFF: Display value≥OUT.L+Hys or
Display value≤OUT.H+Hys
Period ON: OUT1.L≤Display value≤OUT1.H+Hys
Period OFF: Display value≤OUT.L+Hys or
Display value≥OUT.H+Hys
▣ Display cycle delay function
[PA 2:
DIS.T
mode]
In some applications the measured input may fluctuate which in turn causes the display to fluctuate. By
adjusting the display cycle delay function time in the
DIS.T
mode in parameter 2, the operator can adjust
the display time within a range of 0.1 sec to 5 sec. For example, if the operator sets the display cycle time
to 4.0 sec., the display value displayed will be the average input value over 4 sec. and also will show any
changes if any every 4 sec.
LO
OUT1.L
OUT1 output
HL
OUT1.H
OUT1.L
OUT1 output
▣ Main products
■
■
■
■
■
■
■
■
■
■
■
■
■
■
Proximity sensors
■ Counters
Area sensors
■ Timers
Photoelectric sensors
■ Display units
Fiber optic sensors
■ Panel meters
Door/Door side sensors
■ Pressure sensors
Rotary encoders
■ Power controllers
Sensor controllers
■ Graphic/Logic panels
Tachometer/Pulse(Rate) meters
■ Temperature controllers
Temperature/Humidity transducers
Switching power supplies
Stepping motors/drivers/motion controllers
Field network devices
Laser marking system(CO₂ Nd:YAG)
,
Laser welding/soldering system
http://www.autonics.com
Satisfiable Partner For Factory Automation
■HEAD QUARTERS :
41-5. Yongdang-dong, Yangsan-si, Gyeongnam, 626-847,
Korea
■OVERSEAS SALES :
Bldg. 402 3rd FL., Bucheon Techno Park, 193, Yakdae-dong,
Wonmi-gu, Bucheon-si, Gyeonggi-do, 420-734, Korea
TEL : 82-32-610-2730 / FAX : 82-32-329-0728
■E-mail :
sales@autonics.com
▣ Startup compensation timer function
[ PA 2:
STA.T
mode]
This time function limits the operation of an output until the measured input(overvoltage or inrush
current) is stable at moment of power on. All outputs are off during startup compensation time
setting after power is applied.
Setting range: 00.0 to 99.9 (Unit: sec.) Factory default: 00.0
HL-G
OUT1.H
OUT1.L
OUT1 output
※ The above specifications are subject to change without notice.
※ Set output mode separately for each OUT1/OUT2.
※ OUT1/OUT2 are operated individually depending on output operation mode.
※ Setting value mode of parameter group 0 is displayed depending on output operation mode.
※ GO outputs when the period both OUT1/OUT2 are off.(NPN/PNP Open collector output type)
The proposal of a product improvement
and development :product@autonics.com
EP-KE-77-0012G
Analog electronics
京公网安备 11010802033920号
EEWORLD
