Specification
BT45229
BTHQ128064AVD1-STF-12-LED02YG-COG
Doc. No.:
COG-BTD12864-44
Version
October
2010
DOCUMENT REVISION HISTORY
DOCUMENT
DATE
DESCRIPTION
REVISION
FROM
TO
A 2010.10.07 First Release.
Based on:
a.) VL-QUA-012B REV.Y 2010.12.10
According to VL-QUA-012B, LCD
size is small because Unit Per
Laminate=24 which is more than
6pcs/Laminate.
CHANGED
BY
LI WEI
CHECKED
BY
CHI SHAO BO
2
CONTENTS
Page No.
1.
2.
3.
4.
4.1
4.2
5.
5.1
5.2
5.3
5.4
5.5
6.
6.1
6.2
7.
8.
GENERAL DESCRIPTION
MECHANICAL SPECIFICATIONS
INTERFACE SIGNALS
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL MAXIMUM RATINGS – FOR IC ONLY
ENVIRONMENTAL CONDITION
ELECTRICAL SPECIFICATIONS
TYPICAL ELECTRICAL CHARACTERISTICS
TIMING SPECIFICATIONS
COMMAND TABLE
INITIAL CODE SETTING (FOR REFERENCE ONLY)
REFERENCE CIRCUIT
ELECTRO-OPTICAL CHARACTERISTICS
ISO PLOT
OPTICAL CHARACTERISTICS DEFINITION
LCD COSMETIC CONDITIONS
REMARK
4
4
7
9
9
10
11
11
12
15
16
16
17
17
18
19
19
3
Specification
of
LCD Module Type
Model No.: COG-BTD12864-44
1. General Description
•
•
•
•
•
•
•
•
2.
128 x 64 Dots STN Positive Yellow Transflective Dot Matrix LCD Module.
Viewing Angle: 12 o’clock direction.
Driving duty: 1/65 Duty, 1/7 bias.
‘SITRONIX’ ST7565P (COG) LCD controller/Driver or equivalent.
Logic voltage: 3.3V.
FPC connection.
Yellow-green LED02 backlight.
“RoHS” Compliance.
Mechanical Specifications
The mechanical detail is shown in Fig. 1 and summarized in Table 1 below.
Table 1
Parameter
Outline dimensions
Viewing area
Active area
Display format
Dot size
Dot spacing
Dot pitch
Weight
Specifications
55.6(W) x 70.2(H) x 4.345(D) (Included FPC. Excluded pins)
50.60(W) x 31.0(H)
46.577(W) x 27.697(H)
128(W) x 64(H)
0.349(W) x 0.418(H)
0.015(W) x 0.015(H)
0.364(W) x 0.433(H)
Approx: 14
Unit
mm
mm
mm
dots
mm
mm
mm
gram
4
Figure 1: Module Specification
5
