BATRON
COG-BTHQ12864-05
MAY/2005
PAGE 2 OF 16
DOCUMENT REVISION HISTORY
DOCUMENT
REVISION
FROM
TO
A
DATE
2005.05.05
DESCRIPTION
CHANGED
BY
CHECKED
BY
VIVIAN
LUO
First Release.
CHEN HUI
Based on
JUAN
a.) Test Specification:
VL-TS-COG-BTHQ12864-05 Rev. A,
2005.05.05.
b.) VL-QUA-012A REV. R,
2004.03.20.
According to VL-QUA-012A,
LCD size is small because Unit Per
Laminate=14 which is more than
6pcs/Laminate.
BATRON
COG-BTHQ12864-05
MAY/2005
PAGE 3 OF 16
CONTENTS
Page No.
1.
2.
3.
4.
4.1
4.2
5.
5.1
5.2
5.3
6.
GENERAL DESCRIPTION
MECHANICAL SPECIFICATIONS
INTERFACE SIGNALS
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL MAXIMUM RATINGS – FOR IC ONLY
ENVIRONMENTAL CONDITIONS
ELECTRICAL SPECIFICATIONS
TYPICAL ELECTRICAL CHARACTERISTICS
TIMING SPECIFICATIONS
INSTRUCTION SET
REFERENCE APPLICATION CIRCUIT (8080) EXAMPLE
4
4
7
9
9
9
10
10
11
14
15
BATRON
COG-BTHQ12864-05
MAY/2005
PAGE 4 OF 16
Specification
of
LCD Module Type
Model No.: COG-BTHQ12864-05
1. General Description
128 x 64 dots STN Positive Yellow Transflective Dot Matrix LCD Module.
Viewing Angle: 6 o’clock direction.
Driving scheme: 1/65 duty, 1/7 bias.
‘Epson’ SED1565D0B (COG) Dot Matrix LCD Driver.
8080 Series MPU interface (default).
6800 Series MPU interface (Optional).
FPC connection.
Yellow green LED02 backlight.
2.
Mechanical Specifications
The mechanical detail is shown in Fig. 1 and summarized in Table 1 below.
Table 1
Parameter
Outline dimensions
View area
Active area
Display format
Dot size
Dot spacing
Dot pitch
Weight
Specifications
89.7(W) x 49.8(H) x 6.0(D)(Exclude FPC & gate)
89.7(W) x 149.8(H) x 6.0(D)(Include FPC. Exclude gate)
89.7(W) x 150.0(H) x 6.0(D)(Include FPC and gate)
66.8 MIN.(W) x 35.5 MIN. (H)
63.985(W) x 31.985(H)
128 (W) x 64(H)
0.485(W) x 0.485(H)
0.015(W) x 0.015(H)
0.500(W) x 0.500(H)
56
Unit
mm
mm
mm
dots
mm
mm
mm
gram
Power technology
