REVISION J
DO NOT
SCALE FROM
THIS PRINT
.0988 2.508 REF
(No OF POSITIONS x .0250[.635]) + .6025[15.304] REF
C
BSS-XXX-01-X-D-EMX
No OF POSITIONS (PER ROW)
-025, -050, -075,
*-100, *125, *-150
* SEE NOTE 7
LEAD STYLE
-01
PLATING SPECIFICATION
-L: 10µ" SELECTIVE GOLD IN CONTACT
AREA, MATTE TIN ON TAILS
-F: 3µ" SELECTIVE GOLD IN CONTACT
AREA, MATTE TIN ON TAILS
-H: 30µ" GOLD IN CONTACT AREA,
3µ" GOLD ON TAIL
EDGE MOUNT THICKNESS
-EM2: .064[1.63] .004 PCB(USE BSS-XXX-01-D-EM2
& C-162-01-X-2)
-EM3: (USE BSS-XXX-01-D-EM3
& C-162-02-X-2)
(No OF POSITIONS x .0250[.635])
+ .1725[4.382] REF
(No OF POSITIONS -1) x .0250[.635]
02
SEE NOTE 6
.285 7.24
REF
01
.245 6.223
REF
ROW SPECIFICATION
-D: DOUBLE (USE BSS-XXX-01-D-EMX)
BSS-XXX-01-D-EM2
BSS-XXX-01-D-EM3
C-162-02-X
.175 4.45
REF
"A"
.135 3.43
REF
C-162-01-X
.2530 6.426
C
.120 3.05 REF
C
"A"
.0060 0.152
C
C
2 MAX SWAY
((TYP))
.0660±.0030 1.676±0.076
.0920±.0030 2.337±0.076
SECTION "A-A"
EDGE MOUNT THICKNESS
-EM2: .064[1.63] .004 PCB
SECTION "A-A"
EDGE MOUNT THICKNESS
-EM3:
SEE NOTE 6
(DIFFERENT AS SHOWN, OTHERWISE
SAME AS -EM2 PCB THICKNESS)
.1538 3.905
.100 2.54
REF
.040 1.02 REF
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. CONTACT RETENTION: 4 OZ MIN.
3. DELETED.
4. PARTS ARE "MOLD TO POSITION".
5. MAX VARIANCE OF .002.
6. -EM3 IS NOT A STANDARD OFFERING; AVAILABLE AS AN ASP
ONLY. PLEASE CONTACT SAMTEC INTERCONNECT PROCESSING
GROUP WITH ORDER INQUIRIES.
7. FOR NEW APPLICATIONS REQUIRING THESE POSITIONS. PLEASE
CONTACT SAMTEC INTERCONNECT GROUP.
.140 3.56 REF
PACKAGING VIEW
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01[.3]
.XXX: .005[.13]
.XXXX: .0020[.051]
ANGLES
2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
TUBE: PT-1-24-02-38
PLUG: TP-03
INSULATOR: VECTRA E130i, COLOR: BLACK
CONTACT: PHOS BRONZE, 510 SPRING TEMPER
THICKNESS: .0060
F:\DWG\MISC\MKTG\BSS-XXX-01-X-D-EMX-MKT.SLDDRW
.635mm EDGE MOUNT MI SOCKET ASSEMBLY
DWG. NO.
BSS-XXX-01-X-D-EMX
5/26/2000
SHEET
1
OF
1
BY:
DEAN P
