Cross Reference Guide
BR9210 / SBR9210*
* Part number for additional environmental screening.
Performance Data
Frequency
Gain
Noise Figure
P
1dB
3
rd
Order Intercept
2
nd
Order Intercept
VSWR
Reverse Isolation
Power Supply
Operating Temperature
0.1 - 200.0 MHz
29.0 dB Typical
27.5 dB Min
4.5 dB Typical
6.0 dB Max
7.0 dBm Typical
5.0 dBm Min
19.0 dBm Typical
33.0 dBm Typical
1.2/2.0 Input Typ/Max
1.5/2.0 Output Typ/Max
-41.0 dB Typical
-39.0 dB Min
15.0 Volts
35.0 mA
-55.0 - 85.0 °C
Package Drawing
Gain
dB
Frequency (MHz)
Noise Figure
dB
Frequency (MHz)
P
1dB
Compression Point
dBm
Frequency (MHz)
Reverse Isolation
dB
Frequency (MHz)
Input VSWR
Frequency (MHz)
Output VSWR
Frequency (MHz)
S-Parameters
Frequency S11 Mag S11 Ang S21 Mag S21 Ang S12 Mag S12 Ang S22 Mag S22 Ang
5.0
50.0
100.0
150.0
200.0
0.010
0.020
0.020
0.030
0.040
-17.00
-31.00
-31.00
-32.00
-28.00
28.830
28.720
28.920
29.140
29.350
-2.00
-22.00
-45.00
-68.00
-91.00
0.010
0.010
0.010
0.010
0.010
-1.00
-16.00
21.00
19.00
26.00
0.130
0.120
0.110
0.080
0.050
-2.00
-5.00
-12.00
-11.00
6.00
Absolute Maximum Conditions
Maximum Operating Temperature
Maximum Case Temperature
Continuous RF Input Power
Maximum Peak Power
(3 µsec max)
-55.0 - 100.0 °C
125.0 °C
6.0 dBm
0.5 W
Maximum Storage Temperature
Maximum Supply Voltage
Short Term RF Input Power
(1 minute max)
-62.0 - 125.0 °C
18.0 Volts
50.0 mW
