BUK9507-30B
N-channel TrenchMOS logic level FET
Rev. 02 — 31 January 2011
Product data sheet
1. Product profile
1.1 General description
Logic level N-channel enhancement mode Field-Effect Transistor (FET) in a plastic
package using TrenchMOS technology. This product has been designed and qualified to
the appropriate AEC standard for use in automotive critical applications.
1.2 Features and benefits
Low conduction losses due to low
on-state resistance
Q101 compliant
Suitable for logic level gate drive
sources
Suitable for thermally demanding
environments due to 175 °C rating
1.3 Applications
12 V loads
Automotive systems
General purpose power switching
Motors, lamps and solenoids
1.4 Quick reference data
Table 1.
Symbol
V
DS
I
D
P
tot
R
DSon
Quick reference data
Parameter
drain-source voltage
drain current
total power dissipation
drain-source on-state
resistance
Conditions
T
j
≥
25 °C; T
j
≤
175 °C
V
GS
= 5 V; T
mb
= 25 °C;
see
Figure 1;
see
Figure 3
T
mb
= 25 °C; see
Figure 2
V
GS
= 10 V; I
D
= 25 A;
T
j
= 25 °C
V
GS
= 5 V; I
D
= 25 A;
T
j
= 25 °C; see
Figure 11;
see
Figure 12
[1]
Min
-
-
-
-
-
Typ
-
-
-
4.4
5.9
Max Unit
30
75
157
5
7
V
A
W
mΩ
mΩ
Static characteristics
NXP Semiconductors
BUK9507-30B
N-channel TrenchMOS logic level FET
Quick reference data
…continued
Parameter
non-repetitive
drain-source avalanche
energy
gate-drain charge
Conditions
I
D
= 75 A; V
sup
≤
30 V;
R
GS
= 50
Ω;
V
GS
= 5 V;
T
j(init)
= 25 °C; unclamped
V
GS
= 5 V; I
D
= 25 A;
V
DS
= 24 V; T
j
= 25 °C;
see
Figure 13
Min
-
Typ
-
Max Unit
327
mJ
Table 1.
Symbol
E
DS(AL)S
Avalanche ruggedness
Dynamic characteristics
Q
GD
-
13
-
nC
[1]
Continuous current is limited by package.
2. Pinning information
Table 2.
Pin
1
3
3
mb
Pinning information
Symbol Description
G
D
S
D
gate
drain
source
mounting base; connected to drain
mbb076
Simplified outline
mb
Graphic symbol
D
G
S
1 2 3
SOT78A (TO-220AB)
3. Ordering information
Table 3.
Ordering information
Package
Name
BUK9507-30B
TO-220AB
Description
plastic single-ended package; heatsink mounted; 1 mounting
hole; 3-lead TO-220AB
Version
SOT78A
Type number
BUK9507-30B
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2011. All rights reserved.
Product data sheet
Rev. 02 — 31 January 2011
2 of 14
NXP Semiconductors
BUK9507-30B
N-channel TrenchMOS logic level FET
4. Limiting values
Table 4.
Symbol
V
DS
V
DGR
V
GS
I
D
Limiting values
Parameter
drain-source voltage
drain-gate voltage
gate-source voltage
drain current
T
mb
= 25 °C; V
GS
= 5 V; see
Figure 1;
see
Figure 3
T
mb
= 100 °C; V
GS
= 5 V; see
Figure 1
T
mb
= 25 °C; V
GS
= 5 V; see
Figure 1;
see
Figure 3
I
DM
P
tot
T
stg
T
j
I
S
I
SM
E
DS(AL)S
peak drain current
total power dissipation
storage temperature
junction temperature
source current
peak source current
non-repetitive drain-source
avalanche energy
T
mb
= 25 °C
pulsed; t
p
≤
10 µs; T
mb
= 25 °C
I
D
= 75 A; V
sup
≤
30 V; R
GS
= 50
Ω;
V
GS
= 5 V;
T
j(init)
= 25 °C; unclamped
[1]
[2]
[1]
In accordance with the Absolute Maximum Rating System (IEC 60134).
Conditions
T
j
≥
25 °C; T
j
≤
175 °C
R
GS
= 20 kΩ
Min
-
-
-15
-
-
-
-
-
-55
-55
-
-
-
-
Max
30
30
15
108
75
75
435
157
175
175
108
75
435
327
Unit
V
V
V
A
A
A
A
W
°C
°C
A
A
A
mJ
[1]
[2]
T
mb
= 25 °C; pulsed; t
p
≤
10 µs; see
Figure 3
T
mb
= 25 °C; see
Figure 2
Source-drain diode
Avalanche ruggedness
[1]
[2]
Current is limited by power dissipation chip rating.
Continuous current is limited by package.
BUK9507-30B
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2011. All rights reserved.
Product data sheet
Rev. 02 — 31 January 2011
3 of 14
NXP Semiconductors
BUK9507-30B
N-channel TrenchMOS logic level FET
120
I
D
(A)
90
03nn21
120
P
der
(%)
80
03na19
60
Capped at 75 A due to package
40
30
0
0
50
100
150
200
T
mb
(
°
C)
0
0
50
100
150
T
mb
(°C)
200
V
GS
≥
5 V
Fig 1.
Normalized total power dissipation as a
function of mounting base temperature
10
3
I
D
(A)
10
2
Fig 2.
Normalized total power dissipation as a
function of mounting base temperature
03nn19
Limit R
DSon
= V
DS
/ I
D
t
p
= 10
μ
s
100
μ
s
1 ms
DC
10
Capped at 75 A due to package
10 ms
100 ms
1
10
−1
1
10
V
DS
(V)
10
2
Fig 3.
Safe operating area; continuous and peak drain currents as a function of drain-source voltage
BUK9507-30B
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2011. All rights reserved.
Product data sheet
Rev. 02 — 31 January 2011
4 of 14
NXP Semiconductors
BUK9507-30B
N-channel TrenchMOS logic level FET
5. Thermal characteristics
Table 5.
Symbol
R
th(j-mb)
R
th(j-a)
Thermal characteristics
Parameter
thermal resistance from junction to mounting
base
thermal resistance from junction to ambient
Conditions
see
Figure 4
vertical in still air
Min
-
-
Typ
-
60
Max
0.95
-
Unit
K/W
K/W
1
03nn20
δ
= 0.5
Z
th(j-mb)
(K/W)
10
−1
0.2
0.1
0.05
0.02
10
−2
P
δ
=
t
p
T
single shot
t
p
t
T
10
−3
10
−6
10
−5
10
−4
10
−3
10
−2
10
−1
t
p
(s)
1
Fig 4.
Transient thermal impedance from junction to mounting base as a function of pulse duration
BUK9507-30B
All information provided in this document is subject to legal disclaimers.
© NXP B.V. 2011. All rights reserved.
Product data sheet
Rev. 02 — 31 January 2011
5 of 14
