2SC5084O(TE85L)

Description
TRANSISTOR,BJT,NPN,12V V(BR)CEO,80MA I(C),SC-59
CategoryDiscrete semiconductor    The transistor
File Size460KB,7 Pages
ManufacturerToshiba Semiconductor
Websitehttp://toshiba-semicon-storage.com/
Download Datasheet Parametric Compare View All

2SC5084O(TE85L) Overview

TRANSISTOR,BJT,NPN,12V V(BR)CEO,80MA I(C),SC-59

2SC5084O(TE85L) Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
package instruction,
Reach Compliance Codeunknow
Maximum collector current (IC)0.08 A
ConfigurationSingle
Minimum DC current gain (hFE)80
Maximum operating temperature125 °C
Polarity/channel typeNPN
Maximum power dissipation(Abs)0.15 W
surface mountYES
Nominal transition frequency (fT)5000 MHz
Base Number Matches1
2SC5084
TOSHIBA Transistor Silicon NPN Epitaxial Planar Type
2SC5084
VHF~UHF Band Low Noise Amplifier Applications
Low noise figure, high gain.
NF = 1.1dB, |S
21e
|
2
= 11dB (f = 1 GHz)
Unit: mm
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Base current
Collector current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
B
I
C
P
C
T
j
T
stg
Rating
20
12
3
40
80
150
125
−55~125
Unit
V
V
V
mA
mA
mW
°C
°C
Note: Using continuously under heavy loads (e.g. the application of high
temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the
reliability significantly even if the operating conditions (i.e.
operating temperature/current/voltage, etc.) are within the
absolute maximum ratings.
Please design the appropriate reliability upon reviewing the
Toshiba Semiconductor Reliability Handbook (“Handling
Precautions”/“Derating Concept and Methods”) and individual
reliability data (i.e. reliability test report and estimated failure rate, etc).
JEDEC
JEITA
TOSHIBA
SC-59
2-3F1A
Weight: 0.012 g (typ.)
Microwave Characteristics
(Ta
=
25°C)
Characteristics
Transition frequency
Insertion gain
Symbol
f
T
⎪S
21e
(1)
⎪S
21e
(2)
NF (1)
NF (2)
2
2
Test Condition
V
CE
=
10 V, I
C
=
20 mA
V
CE
=
10 V, I
C
=
20 mA, f
=
500 MHz
V
CE
=
10 V, I
C
=
20 mA, f
=
1 GHz
V
CE
=
10 V, I
C
=
5 mA, f
=
500 MHz
V
CE
=
10 V, I
C
=
5 mA, f
=
1 GHz
Min
5
7.5
Typ.
7
16.5
11
1
1.1
Max
2
Unit
GHz
dB
Noise figure
dB
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
DC current gain
Output capacitance
Reverse transfer capacitance
Symbol
I
CBO
I
EBO
h
FE
(Note 1)
C
ob
C
re
Test Condition
V
CB
=
10 V, I
E
=
0
V
EB
=
1 V, I
C
=
0
V
CE
=
10 V, I
C
=
20 mA
V
CB
=
10 V, I
E
=
0, f
=
1 MHz (Note 2)
Min
80
Typ.
1.0
0.65
Max
1
1
240
1.15
pF
pF
Unit
μA
μA
Note 1: h
FE
classification O: 80~160, Y: 120~240
Note 2: C
re
is measured by 3 terminal method with capacitance bridge.
1
2007-11-01

2SC5084O(TE85L) Related Products

2SC5084O(TE85L) 2SC5084Y(TE85L,F)
Description TRANSISTOR,BJT,NPN,12V V(BR)CEO,80MA I(C),SC-59 TRANSISTOR,BJT,NPN,12V V(BR)CEO,80MA I(C),SC-59
Is it Rohs certified? incompatible conform to
Reach Compliance Code unknow unknow
Maximum collector current (IC) 0.08 A 0.08 A
Configuration Single Single
Minimum DC current gain (hFE) 80 120
Maximum operating temperature 125 °C 125 °C
Polarity/channel type NPN NPN
Maximum power dissipation(Abs) 0.15 W 0.15 W
surface mount YES YES
Nominal transition frequency (fT) 5000 MHz 5000 MHz
Base Number Matches 1 1
