HP11-100-18 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> HP11-100-18

HP11-100-18: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 5W, Hybrid,; CategoryPower/power management The power supply circuit; File Size822KB，2 Pages; ManufacturerSemiconductor Circuits Inc; Environmental Compliance

Download Datasheet Parametric View All

HP11-100-18 Overview

DC-DC Regulated Power Supply Module, 1 Output, 5W, Hybrid,

HP11-100-18 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Semiconductor Circuits Inc
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Efficiency (main output)	60%
Maximum input voltage	36 V
Minimum input voltage	9 V
Nominal input voltage	18 V
JESD-30 code	S-XDMA-P4
Maximum grid adjustment rate	0.25%
Maximum load regulation	1%
Number of functions	1
Output times	1
Number of terminals	4
Maximum operating temperature	71 °C
Minimum operating temperature	-25 °C
Maximum output voltage	5.05 V
Minimum output voltage	4.95 V
Nominal output voltage	5 V
Package body material	UNSPECIFIED
Package shape	SQUARE
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Protect	CURRENT; OUTPUT OVER VOLTAGE
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	COMMERCIAL EXTENDED
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	5 W
Fine-tuning/adjustable output	NO

Preview

Download Datasheet

View All

8765432121098765432109876543210987654321

OUTPUT

GENERAL

INPUT

ENVIRONMENTAL

Voltage Tolerance

Ripple and Noise (PARD)

Short Circuit Protection

Temperature Coefficient

I/O Isolation

Switching Frequency

All specifications are typical at nominal line and full load at 25°C unless

otherwise noted and are subject to change without notice.

Reflected Ripple

Filtering

Voltage Range

Operating Temperature

Storage Temperature

Cooling

Regulation:

Line

Load Single

Load Dual

Efficiency

DP Series

HA/HP Series

± 1%

10mV pk-pk (typ)

30mV pk-pk (max)

Current Limit

0.02% / °C

Fixed

Wide

0.01%

0.25%

0.1%

1.0%

0.01%

1.0%

68% (typ) Fixed Input

75% (typ) Wide Input

500 Vdc

50kHz (typ) Fixed Input

200kHz (typ) Wide Input

4.5-5.5Vdc

9-36Vdc

20-72Vdc

<10mA pk-pk

All Models

-25°C to +71°C No Derating

-25°C to +105°C

Free-air Convection

The H Series is ideally suited for

sensitive applications in digital and

analog requiring low noise, i.e. tele-

communications, process control,

automatic and portable test equipment.

Applications

he HA/HP series features the

latest in MOSFET design, state

of the art surface mount technol-

ogy, and offers a 4:1 ultra-wide input

range, and efficiencies greater than

75% (typ). Features include Pi input

filter to reduce input reflected ripple,

continuous short circuit protection, and

excellent line and load regulation of

±0.25% for line and ±1.0% load.

Additional standard features include,

500 Vdc I/O isolation, and an operating

temperature range of -25°C to +71°C

with no derating. All models are pack-

aged in a six-sided shielded miniature

case measuring only 2.0” x 2.0” x

0.375” high.

Surface mount technology

MOSFET design

4:1 ultra wide input range

Continuous short circuit

protection

Six-sided shielding

Regulated outputs

Single/Dual Outputs

5 to 7.5 Watts
