REMEC
Double Balanced Mixer
Communications Band
Electrical Specifications
Parameter
SSB Conversion
loss:
(2) (3)
Isolation
LO to RF:
LO to IF:
RF to IF:
IF to RF:
Input 1-dB
Compression Point:
Input Third Order
Intercept Point:
LO Power:
(1)
RF 3.5-15.0 GHz
LO 3.5-15.0 GHz
IF DC-4000 MHz
:
Conditions
RF(GHz)
3.7-14.5
3.7-14.5
3.5-15.0
LO(GHz)
3.7-14.5
3.7-14.5
3.5-15.0
3.5-15.0
3.5-15.0
DC-2000
DC-4000
3.5-15.0
3.5-15.0
DC-4000
IF(MHz)
DC-500
DC-2000
DC-4000
Min
Specifications
Typical
5.0 dB
5.5 dB
7.5 dB
35 dB
30 dB
23 dB
+20 dBm
+14 dBm
+1 dBm
+4 dBm
+8 dBm
+12 dBm
+11 dBm
+14 dBm
+18 dBm
+22 dBm
+7 dBm
+10 dBm
+13 dBm
+18 dBm
MC53
MC54
MC56
MC57
MC53
MC54
MC56
MC57
MC53
MC54
MC56
MC57
Max
7.0 dB
8.5 dB
9.5 dB
MC5xSMx-7
MC5xSMx-14
LO Power
3 = +7 dBm
4 = +10 dBm
6 = +13 dBm
7 = +18 dBm
26 dB
21 dB
3.5-15.0
D = No Cover
H = With Cover
3.5-15.0
3.5-15.0
DC-4000
(4)
3.5-15.0
3.5-15.0
DC-4000
Notes:
1. Specifications are guaranteed when tested as a downconverter in a 50 Ohm system at +25°C with the
nominal LO power. Specifications indicated as typical are not guaranteed.
2. Noise figure is typically within ±0.5 dB of conversion loss.
3. Conversion loss typically degrades less than 0.5 dB at +100°C and improves less than 0.5 dB at -55°C.
4. Usable LO drives are up to 2 dB below and 3 dB above nominal.
5. See Application note M112, for aid in selecting the outline and for mounting and installation information.
MC5xSMD-7
Outline: SMMC4A: AS SHOWN
SMMC4B: RF & LO REVERSED
Typical
Performance
at 25°C
MC5xSMH-7
MC5xSMx-7:
AS SHOWN
MC5xSMx-14: RF & LO REVERSED
Outline: SMMT4A: AS SHOWN
SMMT4B: RF & LO REVERSED
NOTE: See PC board footprint - FP1 on page 3-61
All dimensions are in inches and [mm].
Specifications subject to change without notice.
3-13
